XS Power XV2400 12V Lithium Titanate XV Series Batteries 1500 Watts, CA 670A, 1335 Max Amps - M6 Terminal Bolts Included
We are a XS Power authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 12V Lithium Titanate XV Series Batteries
- • Owner's Manual
Enhanced Performance for Demanding Applications
The XS Power XV2400 is a cutting-edge 12V Lithium Titanate battery, part of the XV Series, offering exceptional performance and superior energy efficiency. With 1500 watts of power, 670A Cranking Amps, and a maximum current output of 1335 amps, it's ideal for high-performance applications. The M6 terminal bolts included ensure easy and secure installation. Elevate your power solution with the XV2400 for exceptional energy performance.
Frequently Asked Questions (FAQ)
- • Why does my XV2400 crank the engine so much faster?
Owners have reported noticeably faster and stronger engine cranking after installing the XV2400. Its LTO construction provides high starting-current capability while weighing only about 5.6–6.9 lb, depending on the listed configuration.
- • Are the XV2400's cranking amps comparable to a 1,000-CCA lead-acid battery?
Not directly. The XV2400 is listed at 670 cranking amps, with a 1,000A lead-acid-equivalent figure. Owners specifically note that LTO cranking ratings should not be compared one-for-one with traditional CCA ratings.
- • Why do I need different terminals for my XV2400 installation?
The XV2400 uses threaded M6 terminal hardware, which may not match factory clamp-style cables. Users have reported ordering the appropriate terminals or adapters separately when their original battery cables require conventional posts.
- • Can my alternator put too much current into the XV2400?
This is an important concern. XS Power specifies the XV2400 for charging systems using alternators up to 150 amps. One forum user specifically raised concern about drawing too heavily from the alternator, while the product documentation limits the application to 150A or less.
- • What charging voltage should I see while the XV2400 is running?
For the 12V XV2400, XS Power specifies 13.8–14.0 volts when charging from an alternator or stator. If the charging voltage falls outside this range, check the regulator, alternator, grounds, and battery connections.
- • Why does the XV2400 have only 6Ah when it replaces a much larger AGM?
The XV2400 uses LTO technology, so its raw 6Ah specification should not be treated as equivalent to a conventional AGM's capacity. XS Power lists it as having a 20Ah AGM-equivalent rating, while its primary advantage is high-current starting performance and low weight.
- • Will the XV2400 work with my original Group 24 battery tray?
It is designed as a BCI Group 24 battery, but physical fit should still be checked. The published dimensions are approximately 10.24 × 6.65 × 8.31 inches, and terminal orientation and cable reach can affect installation even when the group size matches.
- • Can I use the XV2400 for a large car-audio system?
The XV2400 is rated for 1,500 watts, and XS Power specifically says it is not intended for high-amp audio systems above that level. For larger systems, the charging system and battery selection should be sized accordingly.
- • Does the XV2400 need to stay connected to a battery maintainer?
No. XS Power states that the XV2400 holds its charge and does not need to remain on a maintainer during normal storage. This can be useful for vehicles that sit unused for extended periods.
- • Could engine-bay heat damage my XV2400?
Yes. The XV2400 is rated for temperatures up to 140°F, and XS Power warns that prolonged exposure above that temperature can permanently damage the battery and affect the warranty. Owners considering under-hood installation have also discussed heat protection and XS Power's battery heat-wrap option.
Features:
- Perfect for stock charging systems
- Not intended for high amp audio systems (1,500W Max)
- Prolonged exposure to temperatures above 140 Degrees will void the warranty and may cause permanent damage to the battery or vehicle.
Specifications:
- Length: 10.24 in
- Height: 8.31 in
- Width: 6.65 in
- Voltage: 12V
- Wattage: 1,500
- MAX Amps: 1,335
- Energy Wh: 70
- CA: 670A
- CA Pb Eq: 1,000A
- Ah: 6
- Ah Pb Eq: 20
- UPC: 692209054726
- Weight: 7
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
