XS Power PWR-S6-1200 14V Lithium Titan 8 Batteries 6,000 Watts, 2,000 Max Amps, 1,000 CA
We are a XS Power authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 14V Lithium Titan 8 Batteries
- • Owner's Manual
Advanced 14V Lithium Titan8 Battery
The XS Power PWR-S6-1200 is a high-performance 14V Lithium Titan8 battery, delivering an impressive 6,000 watts of power with a maximum current output of 2,000 amps, making it well-suited for demanding high-performance applications and quick engine starting with 1,000 Cranking Amps.
Frequently Asked Questions (FAQ)
- • Why does my PWR-S6-1200 read higher than 12V?
The PWR-S6-1200 is built around a 14V electrical system, so its voltage is higher than a conventional 12V battery.
- • Can I connect it directly to my factory electronics?
Check your vehicle and accessories for 14V compatibility before installation, especially sensitive electronics designed strictly around 12V.
- • Why won't my alternator fully charge the battery?
A charging system not suited to the battery's 14V requirements may prevent proper charging, so verify alternator output and charging settings.
- • Why doesn't the battery fit my tray correctly?
The PWR-S6-1200 measures approximately 7.79 × 6.54 × 6.69 inches, so compare these dimensions and terminal orientation with your available space.
- • Why are my battery cables difficult to connect?
The battery uses M6 terminal hardware and right-side polarity, which may require appropriate cable routing or terminal adapters in some installations.
- • Can it handle a high-powered audio system?
Yes. Its 6,000W rating and 2,000A maximum output make it suited to demanding high-power applications.
- • Why does my amplifier still show voltage drops?
Check the alternator, grounds, cable size, and connections first; a high-output battery cannot compensate for an undersized charging or wiring system.
- • Does the PWR-S6-1200 recharge quickly?
Its LTO design supports very high charging current and rapid recharge when the charging system is properly matched.
- • Can I install the PWR-S6-1200 under the hood?
Yes. XS Power lists the S6 for cabin or under-hood installation, provided it is securely mounted and installed correctly.
- • What if the battery suddenly loses performance?
Check voltage, charging output, terminal connections, and parasitic loads before assuming the battery has failed. Real-world XS Power discussions also show why documenting voltage and battery condition can be useful if warranty service is needed.
Features:
- 14V Lithium Titan8 Battery: The XS Power PWR-S6-1200 is a high-performance battery utilizing advanced Lithium Titan8 technology.
- 6,000 Watts: This battery delivers an impressive power output of 6,000 watts, suitable for high-performance applications.
- 2,000 Max Amps: With a maximum current output of 2,000 amps, the PWR-S6-1200 ensures reliable and efficient power delivery.
- 1,000 CA (Cranking Amps): The battery is equipped with an impressive 1,000 Cranking Amps, making it ideal for quick and effective engine starting.
Specifications:
- Length: 7.79 in
- Height: 6.69 in
- Width: 6.54 in
- Voltage: 14V
- Wattage: 6,000
- MAX Amps: 2,000
- Energy Wh: 144
- CA: 1,000A
- CA Pb Eq: 1,500A
- Ah: 10
- Ah Pb Eq: 30
- M6 Terminal Hardware Included
- UPC: 692209055051
- Weight: 9
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
