Diamond Audio  MICRO5V2 On Sale

MICROV2 Series 150WX4 + 350WX1 @2Ohms Full Range Class D 5-Channel Amplifier

Item #80597

Condition:   Brand New

Product Highlights

  • MICROV2 Series
  • 150W x 4 @ 2 Ohms
  • 350W x 1 @ 2 Ohms
  • Full Range Class D
  • 5-Channel Amplifier

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Special offer:

$384.29

Discount Already Applied!
Reg. Price $819.99  Save $435.70
In Stock
In Stock

Limited Stocks left!
Add Extended Warranty
Getting Delivery Estimate...
  Free 2-Years Warranty Included!

No Credit needed for acima logoLearn More

Diamond Audio Authorized Dealer

Huge Saving on Other items:


Huge Saving on Other items:



SPECIFICATIONS


  • Maximum Power : 950 Watts
  • Number of Channels : 5
  • Frequency Response : 20-30000 Hz
  • Amplifier Class : D
  • Fuse Rating : 60 A

FEATURES


Features:

  • Full Range Class D IR Chipset
  • DirectFET Power Mosfet Output Stage
  • SMD Technology on 4 layer Glass PC Board
  • ICAD circuit provides superior overload protection
  • Frequency response 20 Hz – 30kHz
  • Variable 12db crossovers
  • Bridgeable / 2ch-4ch switch control
  • BTR (BlueTooth Receiver enabled)
  • MICRO Bass boost +12DB @45Hz
  • Premium 8 and 4 gauge power connections
  • Multi channels / Mono channel



Specifications:

  • RMS Power (2 Ω): 150 W X 4/350 W X 1
  • RMS Power (4 Ω): 80 W X 4/200 W X 1
  • Bridged (mono 4 Ω): 300 W X 2/200 W X 1
  • Topology: Full Range Class D
  • Power Supply: Full PWM
  • Power Supply Threshold: 10.0DVC – 17.0DVC
  • Idle Current: (0.7A)
  • THD 4 (1KHz @4Ω): 0.5%
  • S-N Ratio (A-weighted @ 1W): -85dBA
  • S-N Ratio (A-weighted @ 1W): -101.1dBA
  • Input Sensitivity – Low Input Level: 200mV – 10.0V
  • Input Sensitivity – High Input Level: N/A
  • Input Impedance – Low Input Level: 20 KΩ
  • Impedance – High Input Level: 20 KΩ
  • Output Impedance: 0.018Ω
  • Damping Factor (50Hz @ 4Ω): >70
  • Bandwidth (-3dB): 10Hz-35Hz
  • Crossover (-12 dB/ Oct) – Variable High Pass: Flat or Fixed 70Hz
  • Crossover (-12 dB/ Oct) – Variable Low Pass: 40Hz-400Hz
  • Crossover (-12 dB/ Oct) – Variable Sub-Sonic: N/A
  • Fuse Rating (ATC): 60A
  • Dimensions- Length x Width x Height (inches): 10.65″ x 4.0″ x 1.46″
  • Dimensions- Length x Width x Height (mm): 270.5 x 103 x 37.2 mm
  • UPC: 0847169024177
  • Weight: 8
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
