Diamond Audio  DMD52

Diamond DMD Series 5.25" 160W Peak Power Handling, 4-Ohms, 2-Way Coaxial Speakers

Item #80703

Product Highlights

  • Diamond DMD 5.25 speakers
  • 160W peak power handling
  • 4-ohm 2-way coaxial
  • High performance car audio
  • Durable speaker construction

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Sorry, this product is no longer available.
Checkout other products listed below

Huge Saving on Other items:



Huge Saving on Other items:


Diamond Audio DMD52 - Diamond DMD Series 5.25" 160W Peak Power Handling, 4-Ohms, 2-Way Coaxial Speakers


We are a Diamond Audio authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • (2) Speakers
  • • Mounting Brackets/Hardware
  • • Foam Gasket
  • • Owner's Manual
Affordable Performance and Reliability

Introducing the DMD Series Speakers from Diamond Audio – an excellent entry-level option for those seeking affordable value and dependable performance. Through ongoing research and development, these speakers have achieved notable enhancements, featuring chemically treated voice coils and cross-flow design basket frames that improve thermal heat dissipation. Designed for maximum value, the DMD Series includes a high-density NBR half-roll surround for improved linear performance, while the Klippel® DA optimized motor and suspension symmetry ensure tight and balanced sound reproduction, making them a great addition to any car audio system. Upgrade your audio setup today and experience the perfect combination of performance and value with Diamond Audio's DMD Series.


SPECIFICATIONS


  • Diameter : 5.25 Inch
  • Sensitivity : 86 dB
  • Impedance : 4 Ohm
  • Frequency Response : 70-20000 Hz
  • Peak Power Handling : 160 Watts
  • Design : 2 Way
  • RMS Power Handling : 80 Watts

FEATURES


Features:

  • Chemically-treated Voice Coils: Enhances thermal heat dissipation
  • Cross-flow Design Basket Frame: Improves thermal management and structural integrity
  • High-Density NBR Half-Roll Surround: Ensures greater linear performance
  • Klippel® DA Optimized Motor and Suspension Symmetry: Provides tight, balanced musical reproduction
  • 20mm PEI Dome Tweeter: Delivers clear high-frequency sound
  • Mounting Diameter: 4.62" / 117.5mm
  • Mounting Depth: 2.1" / 53.5mm



Specifications:

  • Series: DMD Series
  • Priced Per: Pair
  • Number of Speakers: 2
  • Speaker Size: 5-1/4"
  • Design: 2-way Coaxial
  • Color: Black
  • Hi-Res Certified: No
  • Speaker Grilles: No
  • Includes Damping Kit: No

Tweeter:

  • Tweeter Design: Dome
  • Tweeter Size: 0.79"
  • Tweeter Composition: Silk

Woofer:

  • Woofer Composition: Polypropylene

Power Handling:

  • Peak Power Handling: 80 watts each, 160 watts per pair
  • RMS Power Handling: 40 watts each, 80 watts per pair

Performance:

  • Sensitivity: 86 dB
  • Frequency Response: 70 - 20000 Hz
  • Impedance: 4 ohms

Mounting:

  • Shallow Mount Installation: No
  • Top-Mount Depth: 2.10"
  • Bottom-Mount Depth: 2.10"
  • Cutout Dimensions: 4.62"
  • UPC: 847169034930
  • Weight: 8
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
