Diamond Audio  DMD652

Diamond DMD Series 6.5" 200W Peak Power Handling, 4-Ohms, 2-Way Coaxial Speakers

Item #80704

Product Highlights

  • 6.5" coaxial speakers
  • 200W peak power
  • 4-ohm load
  • 2-way sound design
  • Clear highs and mids

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Sorry, this product is no longer available.
Checkout other products listed below

Huge Saving on Other items:



Huge Saving on Other items:


Diamond Audio DMD652 -Diamond DMD Series 6.5" 200W Peak Power Handling, 4-Ohms, 2-Way Coaxial Speakers


We are a Diamond Audio authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • (2) Speakers
  • • Mounting Brackets/Hardware
  • • Foam Gasket
  • • Owner's Manual
Premium Sound and Value for OEM Upgrades

Diamond DMD series speakers offer unparalleled sound quality and value in the industry. As the entry-level option from Diamond Audio, these speakers are engineered to high standards while maintaining an affordable price point. Leveraging advanced technology from higher-end Diamond products, the DMD series benefits from shared crossover components for enhanced sound quality and silk dome tweeters that deliver warm, natural tones. With features like a high-strength ABS injection-molded frame, a 20mm silk dome tweeter, a reinforced polypropylene cone, an FEA optimized high-power ferrite motor, and a separate optimized crossover module, the DMD series represents the best in class for OEM upgrades.


SPECIFICATIONS


  • Diameter : 6.5 Inch
  • Sensitivity : 86 dB
  • Impedance : 4 Ohm
  • Frequency Response : 69-20000 Hz
  • Peak Power Handling : 200 Watts
  • Design : 2 Way
  • RMS Power Handling : 100 Watts

FEATURES


Features:

  • Integrated 12dB/Octave Crossover
  • FEA Optimized High-Power Ferrite Motor
  • Klippel DA-Optimized Motor and Suspension Symmetry
  • Separate Optimized Crossover Module for Component System
  • High-Strength ABS Injection Molded Frame with Integral Terminals
  • Chemically-Treated Voice Coils
  • Cross-Flow Design Basket Frame



Specifications:

  • Series: DMD Series
  • Priced Per: Pair
  • Number of Speakers: 2
  • Speaker Size: 6-1/2"
  • Design: 2-way Coaxial
  • Color: Black
  • Hi-Res Certified: No
  • Illumination: None
  • Speaker Grilles: Yes
  • Includes Damping Kit: No

Tweeter:

  • Tweeter Design: Dome
  • Tweeter Size: 1"
  • Tweeter Composition: Silk
  • 20mm Silk Dome Tweeter

Woofer:

  • Woofer Composition: Polypropylene with reinforced stamped pattern
  • Woofer Surround: Rubber
  • Midrange Cone Material: Reinforced Polypropylene
  • Midrange Basket Material: Composite ABS

Power Handling:

  • Peak Power Handling: 100 watts each, 200 watts per pair
  • RMS Power Handling: 50 watts each, 100 watts per pair

Performance:

  • Sensitivity: 86 dB (dB @ 1 watt/1 meter), 87 dB
  • Frequency Response: 69 Hz - 20 kHz
  • Impedance: 4 ohms

Mounting:

  • Shallow Mount Installation: No
  • Top-Mount Depth: 2.26"
  • Mounting Depth: 2.26"
  • Cutout Dimensions: 5.53"
  • Total Diameter: 6.51"
  • Mounting Diameter: 5.53"
  • Magnet Diameter: 3.43"
  • UPC: 0847169034978
  • Weight: 8
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
