Pioneer DMH-342EX 2-DIN 6.8" Digital Media Receiver with Capacitive Touchscreen, Amazon Alexa when Paired with Pioneer Vozsis App, Bluetooth®, Back-up Camera Ready
We are a Pioneer authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • Digital receiver w/ fixed 6.8" touchscreen monitor (10A fuse)
- • Wiring harness
- • Remote control (CXE9605)
- • CR2025 3V lithium battery (installed in remote)
- • 1.5m USB Extension Cable Type A(M) to Type A(F)
- • Microphone w/ visor-bracket (attached 10' cable terminated by a right-angled 2.5mm connector)
- • (6) Installation Screws
- • Quick Start Guide
- • (1) year Warranty Sheet
- • Installation Manual
Why Choose Pioneer DMH-342EX Digital Multimedia Video Receiver?
Turn Every Drive Into a Smart Entertainment Hub
If you’re upgrading your car audio setup, the Pioneer DMH-342EX isn’t just a head unit it’s your full digital command center. With WebLink Cast smartphone integration, you can connect your iPhone or Android via USB and unlock apps like YouTube, Yelp, and Zomato right on your dashboard. Even better, the full mirroring and app control feature turns your receiver into an extension of your phone, giving you a smooth, intuitive experience every time you hit the road (with parking brake safety lock, of course). It’s like bringing your phone’s world straight into your dash clean, simple, and powerful.
Entertainment That Never Leaves the Drive
Long drives get way better with the DMH-342EX’s WebLink entertainment suite. You’ve got MusicPlayer for your stored tracks, VideoPlayer for your personal media, YouTube for endless content, and ShoutCast for global internet radio all in one interface. Need something more interactive? Yelp and Zomato help you discover food spots and services on the go. And with Amazon Alexa voice control, you can ask for music, directions, weather updates, or even control smart devices at home all hands-free, just through your voice and the touchscreen system.
Serious Sound, Smart Connectivity, Clean Control
This unit doesn’t just look smart it performs like a proper audio upgrade. With advanced Bluetooth 4.2, you get crystal-clear hands-free calls, full phonebook access, and seamless music streaming. Plug in via USB for high-resolution FLAC playback up to 24-bit/192kHz, while also charging your device at the same time. And when it comes to tuning, you’ve got full control: a 13-band EQ, bass boost, crossover filters, MOSFET power section, and premium DAC all work together to deliver clean, punchy, customizable sound that fits your style perfectly.
Frequently Asked Questions (FAQ)
- • Why does the screen stay black even though the receiver powers on?
A black screen can result from incorrect display settings, loose wiring, or a software glitch. Restart the receiver and verify that the wiring harness is properly connected.
- • Why won't Android Auto launch when I connect my phone?
This is often caused by an incompatible USB cable, outdated phone software, or Android Auto settings. Use a high-quality data cable and confirm Android Auto is enabled on your smartphone.
- • Why can't I watch videos through the receiver?
Video playback is disabled while the vehicle is moving as a built-in safety feature. The parking brake wire must be installed correctly for supported video functions when the vehicle is parked.
- • Why does Bluetooth take a long time to reconnect?
Slow reconnection may occur if multiple devices are paired or if the phone's Bluetooth service is delayed. Removing unused paired devices and updating your phone can improve connection speed.
- • Why do my touch controls sometimes respond slowly?
Background processes, outdated firmware, or temporary software issues can affect touchscreen responsiveness. Restarting the receiver and installing firmware updates can improve performance.
- • Why doesn't the receiver automatically switch to the backup camera?
The reverse trigger wire may be connected incorrectly or the camera input may be disabled. Verify the reverse signal wiring and enable the camera feature in the settings menu.
- • Can I customize the sound for different types of music?
Yes. The receiver includes audio adjustments such as equalizer controls, balance, fader, and crossover settings for personalized sound tuning.
- • Why won't my USB flash drive be recognized?
Unsupported file systems, incompatible file formats, or damaged USB drives can prevent detection. Formatting the drive correctly and using supported media files usually resolves the issue.
- • Why do phone calls sound quiet through my car speakers?
Low Bluetooth call volume or microphone placement can affect call clarity. Increase the call volume during a conversation and position the microphone closer to the driver.
- • Can I add an external amplifier to improve sound quality?
Yes. The receiver includes preamp outputs that allow connection to aftermarket amplifiers for increased power and improved audio performance.
- DIN : 2
- Display Size : 6.8 Inch
- Bluetooth : Yes
- Aux Input : Yes
- MP3 Playback : Yes
- WMA Playback : Yes
- Rear View Camera Input : Yes
Features:
- WebLink Cast Smartphone Integration (iOS & Android): Seamlessly connect compatible smartphones via USB using the WebLink Host app (iOS 13.4+ / Android 7.0+), enabling access to select apps like YouTube, Yelp, Zomato, and more directly on the receiver’s touchscreen interface.
- Full Mirroring & App Control Experience: Mirror and control your compatible smartphone through the Pioneer DMH-342EX display, giving you an intuitive in-car extension of your mobile device (operation requires parking brake engagement for safety).
- WebLink Entertainment Suite: Enjoy built-in WebLink apps including MusicPlayer for stored media browsing, VideoPlayer for local videos and photos, YouTube access for online content, ShoutCast internet radio, plus Yelp and Zomato for location-based discovery.
- Amazon Alexa Voice Control Integration: Access Alexa via WebLink by pairing your smartphone through USB and Bluetooth, enabling voice commands for music playback, calls, smart home control, news, and weather updates through supported apps.
- Advanced Bluetooth 4.2 Connectivity: Supports hands-free calling with wideband speech clarity, phonebook transfer (up to 1000 contacts), call history access, and wireless audio streaming (A2DP/AVRCP) with full playback control from the head unit.
- High-Quality USB Media Playback & Charging: Plays USB mass storage devices with support for music, video, and photo files, including high-resolution FLAC audio up to 24-bit/192kHz, while simultaneously charging connected devices (5V/1.5A).
- Premium Audio Performance & Tuning Control: Equipped with a 24-bit/192kHz DAC, MOSFET amplifier section, 13-band graphic EQ, bass boost, loudness control, and high/low-pass crossovers for precise sound customization and powerful output.
- Built-in AM/FM Supertuner IIID with RDS: Delivers enhanced radio reception with reduced interference, improved stereo separation, and RDS support for displaying station, artist, and song information where available.
- Rear Camera & Video Support: Includes rearview camera input with automatic reverse switching and manual camera view mode, plus AV input/output for external displays and expanded multimedia setups.
- Responsive 6.75” Capacitive Touchscreen Interface: Features a high-resolution multi-touch display with smartphone-like gestures, customizable wallpaper, adjustable illumination colors, and intuitive on-screen control.
- Smart Safety & Parking Brake Integration: Certain video and app functions are restricted while driving to ensure safety, activating only when the parking brake is engaged.
- Flexible Installation & Steering Wheel Control Support: Includes wireless remote control, OEM steering wheel control compatibility (with adapter), and full integration flexibility for a clean, factory-style installation experience.
Specifications:
- RMS Power Output (CTA-2006): 14 watts
- RMS Power (Manufacturer): 22 watts
- Display Size: 6.75-inch touchscreen
- Screen Type: Capacitive (swipe-enabled)
- Preamp Voltage: 2V
- Preamp Outputs: 5-channel output system
- Subwoofer Preamp Output: Yes
- Bluetooth Version: 4.2 built-in
- Smartphone Compatibility: iPhone 6S and newer, Android supported
- Voice Control: Alexa enabled
- USB Port: Rear USB with 1.5A charging support
- Audio Formats Supported: MP3, WMA, AAC, FLAC, WAV
- High-Resolution Audio: FLAC up to 192kHz
- EQ System: 13-band equalizer
- Backup Camera Input: Yes (rear camera support)
- Radio System: FM with RDS, seek/scan function
- Dimensions (Chassis): 5.605” D x 7.015” W x 3.945” H
- UPC: 884938479196
- Weight: 9
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
Do you own this product?
Write a review!
-
I'm tellin' ya, I'm lovin' this thing! It fits right in my car, and it's a cinch to use. It hooks up to my phone real quick, and the sound is just awesome. Gettin' that Bluetooth going? Piece of cake. Glad I got rid of my old stereo.
-
Fits in my Mustang. Though its not a Carplay receiver, it still has good features like Amazon Alexa. Sound is great as well, and the display is clear and responsive. Hooked up all my speakers with it and the built in amp has some great power. I think I don’t have to buy a new amp for my speakers yet as the stereo can do the job.
-
Needed to replace a head unit that died, this unit doesn’t have all of whistles and bells of the previous unit but it works well where the old one is a paper weight now.
-
A good basic unit. It doesnt have gps but it works through IPhone.
