Wet Sounds REVO 15 XXX V4-B REVO-XXX Series 15" 2000W RMS (4000W Peak Power Handling) 2 Ohms, Dual Voice Coil Marine Subwoofer Xtreme Performance SPL Subwoofer
We are a Wet Sounds authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 15" REVO-XXX Series Dual Voice Coil Marine Subwoofer
- • Owner's Manual
Why Choose Wet Sounds REVO 15 XXX V4-B Marine Subwoofer?
Unrivaled 15" Marine SPL Power
The REVO 15-XXX V4-B is the world’s first purpose-built 15” SPL marine subwoofer, delivering massive, earth-shaking bass for serious audiophiles. Engineered with advanced CAD and full Finite Element Analysis, it ensures precision performance and extreme durability, handling 2000W RMS (4000W peak) to dominate any marine environment.
High-Performance Marine Bass, Built to Last
Featuring a premium polypropylene/carbon/glass fiber hybrid cone, this subwoofer delivers superior strength and minimal distortion. Equipped with a high-roll Santoprene rubber surround, fiberglass former, and dual 5" voice coils for maximum reliability, it also integrates a multi-part cooling system with T-yoke heat sink and peripheral/pole piece venting to keep temperatures low during high-power use.
Secure Connections, Maximum Bass Output
Screw-down gold-plated terminals and a high-power magnet provide corrosion-resistant, reliable performance. With a top-mount depth of 10.5" and a 15.4" cutout diameter, this subwoofer is optimized for Free Air or enclosure use, delivering high-output bass for demanding marine setups.
Frequently Asked Questions (FAQ)
- • What amplifier should I use with this subwoofer?
A high-power amplifier delivering up to 2,000 watts RMS is recommended for this dual 2-ohm subwoofer. Make sure the amplifier matches the final voice coil impedance.
- • Why does the bass sound weak after installation?
Incorrect enclosure volume, port tuning, or amplifier settings can reduce bass output. Use the recommended enclosure design and check the amplifier settings.
- • Why does the bass distort at high volume?
Amplifier clipping or excessive gain can cause distortion during high-output playback. Lower the gain and ensure the amplifier delivers clean power.
- • Why isn't the subwoofer producing any sound?
Check the amplifier power, signal, fuse, and speaker wiring for loose connections. Verify both voice coils are wired correctly for the amplifier.
- • What enclosure size should I use?
The recommended ported enclosure provides approximately 3 cubic feet of net air space. The recommended tuning frequency is around 40 Hz.
- • Why does the enclosure rattle during heavy bass?
High output and heavy cone movement can expose weak enclosure joints or insufficient bracing. Reinforce the enclosure and tighten all mounting hardware.
- • Why is the cone moving excessively?
Excessive gain, unsuitable frequencies, or incorrect enclosure tuning can increase cone excursion. Check the amplifier settings and use proper filtering.
- • Will it fit in my existing installation space?
The mounting depth is 10.57 inches and the required cutout is approximately 14 inches. Measure the mounting area and allow enough clearance before installation.
- • Do I need extra bracing for the installation?
The heavy, high-power driver requires a strong mounting surface for secure installation. Reinforcing flexible panels can help reduce unwanted vibration.
- • Can it be used in a marine environment?
The driver uses marine-grade materials including a corrosion-resistant cast aluminum frame and Santoprene surround. Proper mounting and regular inspection remain important.
- Diameter : 15 Inch
- Sensitivity : 89 dB
- Impedance : 2 Ohm
- RMS Power Range : 2000 Watts
- Peak Power Handling : 4000 Watts
- Color : Black
- Mounting Depth : 6.53 Inches
Features:
- Extreme SPL Performance: The REVO 15-XXX V4-B is the first purpose-built 15” SPL marine subwoofer in the world, delivering massive bass for serious audiophiles.
- Advanced Acoustical Engineering: Designed from the ground up using CAD and full Finite Element Analysis, ensuring durability and precision performance in extreme conditions.
- High-Power Handling: Capable of 2000W RMS and 4000W peak, producing deep, earth-shaking bass that dominates any marine environment.
- Premium Composite Cone: Features a high-stiffness matte black polypropylene/carbon fiber/glass fiber hybrid cone for superior strength and minimal distortion.
- Durable Surround & Voice Coil: Equipped with a high-roll thermoformed Santoprene rubber surround, fiberglass former, and dual 5-inch voice coils for maximum reliability.
- Integrated Cooling System: Multi-part cooling system with T-yoke heat sink and combination peripheral/pole piece venting reduces voice coil temperature during high-power use.
- Gold-Plated Terminals & Heavy-Duty Magnet: Screw-down binding posts and a high-power magnetic system ensure secure connections and long-lasting performance.
- Flexible Installation & Compatibility: Optimized for infinite baffle or enclosure use, with a top-mount depth of 10.5" and cutout diameter of 15.4", perfect for high-output marine setups.
Specifications:
- Subwoofer Size: 15 inches
- Series: REVO XXX V4-B
- Impedance: Dual 2 ohms
- RMS Power: 2000W
- Peak Power: 4000W
- SPL Sensitivity: 89 dB
- Frequency Response: Fs 35 Hz
- Cone Material: Polypropylene / Carbon Fiber / Glass Fiber Composite
- Surround: Thermoformed Santoprene Rubber
- Voice Coil: Dual 5 inches
- Magnet System: Heavy-duty magnetic system
- Mounting Depth: 10.5 inches
- Diameter: 15.4 inches
- Xmax: 23 mm
- Sd: 855.3 cm²
- Mms: 484 g
- Vas: 24 liters
- Qts: 0.38 | Qes: 0.40 | Qms: 6.00
- Le: 0.7 mH | Bl: 17.4 T*m
- Application Type: Enclosure / Marine SPL
- UPC: 814820022254
- Weight: 30
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
