Cerwin Vega  CVPM1001D

CVP Mini Series 1000W Max Power, Class-D Mono Subwoofer Car Amplifier

Item #84136

Product Highlights

  • CVP Mini Series
  • 1000W Max Power
  • Class-D Mono
  • Subwoofer Car Amplifier

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Sorry, this product is no longer available.
Checkout other products listed below

Huge Saving on Other items:



Huge Saving on Other items:


CVP Performance series products make owning a Cerwin-Vega Mobile sound system very affordable for those that are budget-conscious. With a numerous amount of mono and multi-channel amplifiers to select from at a tremendous value for the performance, enjoy the LOUD sound experience with CVP Performance series products. The right price, the right power, the right products!


SPECIFICATIONS


  • Maximum Power : 1000 Watts
  • Number of Channels : 1
  • Frequency Response : 10-45000 Hz
  • Amplifier Class : D
  • Fuse Rating : 30x2 A
  • Promo : Yes

FEATURES


What's Inside?

  • 1 1000W Monoblock Class D Subwoofer Amplifier



Features:

  • Latest High-Efficiency Class D Topology
  • ULTRA Compact Size
  • Fully Variable Crossovers (12dB per octave)
  • Handles HI and LO level input to 12V
  • 2 Ω Stable for Mono Block
  • 4/2 Ω Stable Stereo/4Ω Mono for 4 Channel
  • Proprietary Vega Bass Boost EQ Up To 12dB
  • CVP MINI 1-Channel
  • MINI 1-Channel
  • 500W x 1 @ 2Ω RMS
  • 350W x 1@ 4Ω RMS
  • 15-500Hz Frequency Response
  • IRS2092 Main Power Chip
  • Low Pass Crossover 30Hz~500Hz
  • 12dB Crossovers Slope



Specifications:

  • MAX Power Rating: 1000W MAX
  • RMS Bridge (mono 2Ω): 500W x 1 @ 2Ω RMS
  • RMS Bridge (mono 4Ω): 310W x 1 @ 4Ω RMS
  • Types: Full Range, Class D
  • Power Supply: PWM
  • Power Supply (Threshold): 10 – 17DVC
  • Idle Current: (0.7A)
  • Distortion - THD (1KHz@4Ω): ?1%
  • Distortion - S/N Ratio (A weight @ 1W): -85dBA
  • Distortion - S/N Ratio (A weight @ FP): -101.1dBA
  • Input Sensitivity - Hi/Low Input Level: 0.15V – 6.0V
  • Input Impedance - Low Input Level: 20 KΩ
  • Output Impedance: 0.0297Ω
  • Damping Factor (50Hz@4Ω): >70
  • Bandwidth (-3dB): 10Hz-45KHz
  • Crossover (-12 dB/ Oct) Variable High-Pass: N/A
  • Crossover (-12 dB/ Oct) Variable Low-Pass: 35Hz-500Hz
  • Crossover (-12 dB/ Oct) Variable Sub-Sonic: N/A
  • FUSE Ratings - ATC: 2 x 30A
  • Dimension - Length x Width x Height - Inches(mm): 7.64 x 3.7 1.47 (194 x 95 x 37.3)



  • UPC: 847169054075
  • Weight: 6
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.

Do you own this product?

Write a review!
  • Its mini but it surely packs some punch. The bass coming from the amp is clean, and for the price, its really got some great value in it.

    AudioPhil
    4/10/2024
