Memphis Audio SE1200.4V2 Street Edge Series Version 2 85W x 4 RMS @2Ohms, 1200W Max Power 4-Channel Amplifier
We are a Memphis Audio authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 4-Channel Amplifier
- • Owner's Manual
Street Edge Amplifiers
Street Edge amplifiers were designed to be affordable without sacrificing performance. The stripped down styling of these amplifiers allowed more resources to be dedicated to achieving solid performance with big power ratings at an affordable price point. Street Edge 4-channel amplifiers were designed to be an affordable option to deliver power to your mids and highs.
Features an Led Power/protect Light
The Street Edge Series Class D 2-ohms Stable 4-Channel Amplifier delivers impressive audio performance with an RMS power rating of 60 watts x 4 channels at 4 ohms, 85 watts x 4 channels at 2 ohms, and a bridged power output of 170 watts x 2 channels at 4 ohms, resulting in a total power output of 240 watts. This amplifier features an LED Power/Protect Light, variable crossovers, and an extruded aluminum heatsink for efficient cooling. With an input sensitivity ranging from 0.15 to 16 volts, a frequency response of 10 to 30K Hz, and a low Total Harmonic Distortion (THD) of 0.1%, it ensures high-quality sound reproduction.
- Maximum Power : 1200 Watts
- Number of Channels : 4
- Frequency Response : 10-30000 Hz
- Built In Crossovers : Yes
- RMS Power Output : 85x4 Watts
- Channel Separation : Yes
- Fuse Rating : 20x2 A
Features:
- Street Edge Series Class D 2 ohms Stable 4-Channel Amplifier
- RMS Power Rating:
- 4 ohms: 60 watts x 4 channel
- 2 ohms: 85 watts x 4 channel
- Bridged: 170 watts x 2 channel @ 4 ohms
- Total power output: 240 watts
- LED Power/Protect Light
- Variable Crossovers
- Extruded Aluminum Heatsink
- Input sensitivity: 0.15 - 16 volts
- Frequency Response: 10 - 30K Hz
- Total Harmonic Distortion (THD): 0.1%
- Signal to Noise Ratio: 85 dB
- Variable high-pass filter: 120 - 3K Hz
- Variable low-pass filter: 50 - 250 Hz
- Variable Bass Boost: 0 - 12 dB
- Fuse Rating: 40A
- 8 AWG gauge amplifier wiring kit is recommended for installation
- Dimensions: 12.6" L x 8.07" W x 2" H
- Authorized Internet Dealer
- 1-year Manufacturer's Warranty
Specifications:
- RMS POWER 4Ω: 60 x 4
- RMS POWER 2Ω: 85 x 4
- BRIDGED/MONO POWER 4Ω: 170 x 2
- THD% 4Ω: <1%
- FREQ RESPONSE: 10Hz – 30kHz
- DIMENSIONS L xW x H: 12.6 x 8.07 x 2
- INPUT RANGE: 200mV -8V
- AMP KIT: 4GKIT
- Series: Street Edge Series
- Amplifier Class: D
- Number of Channels: 4-Channel
- Total RMS Power Output: 240 watts
- Maximum Input Gauge Size: 8 AWG
- Minimum Impedance Unbridged: 2 ohms
- Minimum Impedance Bridged : 4 ohms
- Frequency Response: 10 - 30K Hz
- THD at Rated RMS Power: 0.1%
- Speaker Level Inputs: Yes
- Built-in Crossover: Low-Pass (LP)
- High-Pass (HP): Full (AP)
- High-Pass Crossover Frequency: 120 - 3K Hz
- Low-Pass Crossover Frequency: 50 - 250 Hz
- Signal-to-Noise Ratio: 85 dB
- Bass Boost: 0 - 12 dB
- Fuse Rating: 20A x 2
- Total Fuse Rating: 40
- Sonic Certified Amplifier: Not Tested
- Low-Level Input Sensitivity: 0.15 - 16 volts
- UPC: 702588006039
- Weight: 6
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
