Diamond Audio DMD Series 6-Channel Full Range Digital Amplifier
We are a Diamond Audio authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
• (1) 6-Channel Full Range Digital Amplifier
• Owner's Manual
DMD Series Amplifiers
DMD series amplifiers from Diamond Audio provides best in class performance for the value, period! Providing substantial power in a very small footprint heat sink, DMD series amplifiers is the solution for any budget-friendly mobile audio sound system. DMD series comprises a total of five amplifier models: one 4-channel, three mono-channel and one 6-channel amplifiers to select from.
IR chipset technology
DMD series power is generated from the latest IR chipset technology and its manufacturing process utilizes innovative SMD technology and circuit design while built on 4-layer FR4 PC boards. It features balanced differential inputs for noise-free operation regardless of the source, subsonic filter, bass boost, and LED lit logo indicating power/ protection status mode. Audio precision quality control verification provides high performance and reliability unmatched by other competitors!
Maximum Power : 1100 Watts
Low Frequency Response : 50-500 Hz
High Frequency Response : 50-500 Hz
Number of Channels : 6
Frequency Response : 10-20000 Hz
Built In Crossovers : Yes
RMS Power Output : 125x4+250x2 Watts
Channel Separation : Yes
Amplifier Class : D
Fuse Rating : 30x3 A
6 Channel Full Range Digital Amplifier
350W x 2CH @ 1Ω (CH5 & CH6 Only)
125W x 4CH + 250W x 2CH @ 2Ω / 80W x 4CH + 125W x 2CH
4Ω RMS Power Output
250W x 2CH + 500W x 1CH @ 4Ω RMS Bridged Power Output
700W x 1CH @ 2Ω RMS Bridged Power Output (CH5 & CH6 Only)
Input Sensitivity: 0.2-10 Volt
Selectable X-Over: LPF / FULL / HPF
Crossover Filter : 50-500Hz, 12dB Per Octave Slope
Frequency Response: 10-20KHz
Signal to Noise Ratio: > 90dB
Overall Operation Efficiency: >86%
Selectable REM / VOX / DC Turn On Modes
Selectable 2CH / 6CH Input Modes
Dimensions: 9.76" x 6.85" x 1.9" / 248.1 x 174 x 48.4 mm
