MX Series 6-Channel Full Range Class D Amplifier 180Wx6 @ 2 Ohms-13.8V – 360Wx3 @ 4 Ohms Bridged-13.8V
We are a Musway authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 1 - SIX.100 6-Channel Full Range Class D Amplifier
- • 1 - Owner’s Manual
- • 1 - External ANL Mini Fuse holder
- • 1 - 80-amp Mini ANL Fuse
- • 2 - High Level Output Harness
- • 2 - High Level Input Harness with EPS
- • 2 - Low Level (RCA) Input Harness
- • 1 - RLC Knob
- • 1 - RLC Cable 16.5'
- • 1 - RLC Breakaway Cable 1'
- • 1 - Mounting Hardware
SIX.100 Incredibly Versatile 6-Channel Amplifier
A car amplifier designed to power up a huge vehicle audio system, the Musway SIX.100 allows you to connect up to six speakers while delivering high-quality and powerful full-range frequency performance that audiophiles enjoy. The amplifier also enables you to bridge two of its channels if you are planning to use a subwoofer, resulting in a 5-way setup.
Equipped With 4-fold Laminated Circuit Boards
The Musway SIX.100 is equipped with 4-fold laminated circuit boards, allowing it to be designed as compactly as possible. It also comes with brushed aluminum heat sink and end panels, ensuring that the amplifier can stay cool even after long hours of use, especially at high volume levels.
Designed Effectively To Eliminate EMI Interference
It is designed effectively to eliminate EMI interference, which is necessary for compact amplifiers like the Musway SIX.100. With its Intelligent High-Level Input Error Protection System, the amplifier is protected from getting damaged, as it ensures that no errors occur in its diagnostic system.
Can Handle a Power Output of 110 Watts RMS
The Musway SIX.100 can handle a power output of 110 Watts RMS at 4 ohms per channel and 180 Watts RMS at 2 ohms per channel. This Class-D amplifier also has a frequency response of 4 Hz to 38 kHz and a sensitivity rate of 107 dB, allowing it to go seriously loud and deliver an extensive full-range frequency performance with less distortion at high volume levels.
Product Highlights:
- Start-Stop Ready
- EPS (Intelligent High Level Input Error Protection System)
- Utilizes 4-fold Laminated Circuit Boards that allows for Small Size and
- Effectively Suppresses EMI (RF) Interference which is a must with Full Range Class D Amplifiers
- Selectable Input Mode Switch: 2 Channel or 6 Channel Input
- High and Low-Level Inputs
- Brushed Aluminum Heat Sink and End Panels
- Auto Turn On via DC Offset or Signal Sensing
- Remote Level Controller is Included in the Box
Specifications:
- OUTPUT POWER RMS @ 13.8V:
- 6x110 W @ 4 Ohms
- 6x180 W @ 2 Ohms
- 3x392 W @ 4 Ohms bridged
- OUTPUT POWER RMS @ 14.4V:
- 6x120 W @ 4 Ohms
- 6x196 W @ 2 Ohms
- 3x392 W @ 4 Ohms bridged
- Frequency Range -3dB - 4-38000 Hz
- Damping Factor: > 150
- S/N ratio: 107 dB
- THD+N: <0.02%
- Input Sensitivity:
- Crossover Modes: Full - HP
- High Pass Filter: 50- 5000 Hz
- Channel 3/4
- Crossover Modes: Full - HP - LP/BP
- High Pass Filter: 10 - 500 Hz
- Low Pass Filter: 50 - 5000 Hz
- Bass Boost: 0-12dB @ 45 Hz
- Start-stop capability: 8.5V
- High Level Input with EPS: Yes
- Auto Turn On: Via DC or Signal
- Fuse Rating : 1 x 80A (external)
- Dimensions (H x L x W) 1.8” x 11.4” x 5.9”
- UPC: 6972502090039
- Weight: 8
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
