Hertz  VEN COMPACT V5C

5 Channel 115W RMS x 4 + 550W RMS x 1 at 2-Ohms Class A/B Marine Compact Amplifier

Item #89574

Condition:   Brand New

Product Highlights

  • 5 Channel Amplifier
  • 115W RMS x 4 at 2-Ohms
  • 550W RMS x 1 at 2-Ohms
  • Class A/B
  • Marine Compact Design

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.

$799.99

Reg. Price $849.99  Save $50.00
Add Extended Warranty
  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.

No Credit needed for acima logoLearn More

Hertz Authorized Dealer

Huge Saving on Other items:


Huge Saving on Other items:


Brand Banner

Hertz 5 Channel 115W RMS x 4 + 550W RMS x 1 at 2-Ohms Class A/B Marine Compact Amplifier


Alpine Banner for OCS

We are a Hertz authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • •5-Channel Class A/B amplifier
  • •Owner's Manual
Excellent Performance and Versatility

With Hi-Res certification, the amplifier also includes balanced fully-differential input circuitry for noise rejection, advanced preamp filter options, and comprehensive protection against short-circuit, overload, and thermal issues, providing superior sound quality and robust reliability.

Hertz Advanced Class D technology

The Venezia V5C is a compact five-channel marine amplifier delivering 80 W x 4 (4Ω) plus 330 W (4Ω) for the subwoofer, featuring Hertz Advanced Class D technology to maximize efficiency and minimize heat and electromagnetic radiation. Engineered for marine environments, it boasts IPX2 certification, Safe-Lock connections, and a fanless convection cooling system, ensuring durability against UV, salt-fog, vibrations, and temperature variations.


SPECIFICATIONS


  • Number of Channels : 5
  • Built In Crossovers : Yes
  • RMS Power Output : 115 Watts
  • Channel Separation : Yes
  • Amplifier Class : A/B

FEATURES


Features and Specifications:

  • Channels 5 - 3
  • POWER SUPPLY
  • Power supply voltage 9 ÷ 16 VDC
  • ldling current (power ON/OFF): 1.7 A / 0.05 mA
  • Consumption@ 1Ω, 14.4 VDC (Max Musical Power): 47 A
  • Remote In: 7 ÷ 15 VDC - 1 mA



AMPLIFIER STAGE

  • Distorsion - THD (100Hz @ 4Ω): <0,05%
  • Bandwidth: 10 ÷ 42 kHz
  • S/N Ratlo (A welghted @ 1 V): 100 dB
  • Damping factor (100Hz @ 4Ω) >130
  • Pre-ln sensitivity: 0.2 ÷ 5 VRMS
  • Pre-ln impedance: 10 kΩ
  • Load impedance (MIN)
  • @5Ch: 2Ω
  • @3Ch:  4Ω + 4Ω + 2Ω
  • Weight (kg/lb): 3.72 / 8.2
  • Adjustable Crossovers : yes



Output Power

  • OUTPUT POWER (RMS) @ 14.4 VDC, THD 1%
  • 5Ch 80 W x 4 (4Ω) + 330 x 1 (4Ω)
  • 5Ch 115 W x 4 (2Ω) + 550 W x 1 (2Ω)
  • 3Ch 230 W x 2 (4Ω) + 330 W x 1 (4Ω)
  • 3Ch 230 W x 2 (4Ω) + 550 W x 1 (2Ω)
  • Total Power 1010 W
  • UPC: 8018823139830
  • Weight: 9
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.
