Aunex AP-9EQ 9-Band Performance Equalizer, Pre-Amp Line Driver with Master Volume Control Knob, and Dual Input Source Selector
![]()
We are a Aunex authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • (1) Aunex AP-9EQ equalizer
- •Owner's Manual
Engineered to Deliver Precision Tuning
The Aunex AP-9EQ is a 9-band equalizer designed to fine-tune and enhance the audio performance of your car's sound system. With its advanced equalization capabilities, this unit allows you to adjust and shape the sound to your preferences, delivering a more personalized and immersive listening experience.
Featuring Nine Adjustable Bands
Featuring nine adjustable bands, the AP-9EQ provides precise control over the audio frequencies. You can boost or cut specific frequency ranges, such as bass, midrange, and treble, to achieve the desired tonal balance. This allows you to compensate for the acoustic characteristics of your vehicle's interior or customize the sound according to your musical preferences.
Includes a Built-in Subwoofer Crossover
The AP-9EQ also includes a built-in subwoofer crossover, allowing you to set the appropriate frequency range for your subwoofer. This ensures seamless integration between the subwoofer and the rest of the audio system, resulting in a more cohesive and balanced sound. Its compact size and user-friendly interface, the AP-9EQ is easy to install and operate. The unit features clearly labeled controls and indicators, making adjusting the equalization settings while on the go simple.
- Low Frequency Response : 50-150 Hz
- High Frequency Response : 10-60000 Hz
- Number Of Bands : 9
Features:
- 9-Band In-Dash Equalizer/Pre-Amp Line Driver
- Master Volume Control Knob
- Dual Input Source Selector
- Front, Rear, Subwoofer RCA Output Finish: Anodized with Texture Paint
- Low-Level RCA Input Compatible
- Rear 3.5mm Auxiliary Input
- Variable Subwoofer Level Control Knob
- Variable Subwoofer Frequency Knob
- Variable Fader Knob
Specifications:
- Total Outputs: 3
- Total Inputs: 2
- Output Voltage: 9 Volts Maximum
- Frequency Response: 10Hz - 60kHz
- 9 Band Eq. Center Freq: 80Hz, 120Hz, 200Hz, 500Hz, 1kHz, 3kHz, 6kHz, 10kHz, 15kHz
- Defeat/Boost: -18dB/+18dB
- Variable Sub. Freq: 50Hz - 150Hz
- THD + Noise: <0.2%
- S/N Ratio A-Weighted: >120dB
- Channel Separation: 87dB @ 1kHz
- Input Sensitivity: 250mV - 10V
- Input Impedance: 10.2k Ohms
- Operating Voltage: 9-18 Volts DC
- Dimensions: H x W x D: 1.0" x 7.0" x 4.2"
- Fuse Requirement: 2A (Included)
- UPC: 798418837386
- Weight: 6
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
