Wet Sounds REV 12 HD-B XZ TC3-F Revolution HD Series 12" 400W RMS (800 Peak Power Handling) 4 Ohms, Tower Speakers Horn Loaded Compression Driver (HDLC) with XZ-Black Grille and Stainless Steel Fixed Position Clamp for Tube Diameter 1 7/8” to 3” (Pair)
We are a Wet Sounds authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • (2) 12" Revolution HD Series Tower Speakers
- • XZ-Black Grille
- • Stainless Steel Fixed Position Clamp (Pair) for Tube Diameter 1 7/8” to 3”
- • (8) 1/2" Allen head screws (3mm)
- • Owner's Manual
Why Choose Wet Sounds REV 12 HD-B XZ TC3-F Marine Speakers?
High-Definition Audio Meets Eye-Catching Style
Experience full-range, powerful sound over water with the Wet Sounds 12" REV-TEC HD driver, delivering punchy mid-bass and smooth, detailed highs through a coaxial titanium horn-loaded compression driver. Built for rugged marine use with a thermoformed Santoprene rubber surround and featuring integrated front and rear RGB LED rings, these speakers combine exceptional audio performance with striking, customizable nighttime style.
Durable, High-Performance Marine Sound
Engineered with an advanced polymer composite cone, these speakers deliver clear, powerful audio that stands the test of time. Housed in a UV-protected, reinforced injection-molded enclosure with stainless steel hardware, they resist water, sun, vibration, and corrosion—built to perform reliably in any marine environment.
Customize Your Sound, Your Way
Choose from XZ, XW, and XS grilles in black or white to match your boat’s style, and take advantage of versatile mounting options including swivel, mini swivel, surface swivel, fixed, and X-Mount clamps. Sold in pairs with grilles and clamps separate, these speakers let you fully personalize both installation and appearance for the ultimate marine audio setup.
Frequently Asked Questions (FAQ)
- • Why does the sound distort at high volume?
Clipping, excessive gain, or insufficient amplifier power can cause distortion. Use a properly matched amplifier and adjust the gain carefully.
- • What amplifier power is recommended?
Each speaker is rated at 400 watts RMS and 4 ohms. Use an amplifier capable of delivering clean power without clipping.
- • Why is the bass weaker than expected?
These speakers emphasize powerful midbass and projection rather than deep subwoofer bass. Crossover settings, amplifier power, and tuning affect performance.
- • Why does one speaker sound quieter?
Check balance, amplifier channels, polarity, wiring, and connectors. Swapping amplifier channels can help determine whether the issue follows the speaker.
- • How do I stop the speaker from moving on the tower?
Make sure the TC3-F clamp matches the tower diameter and tighten all mounting hardware securely. Threadlocker can help prevent mounting bolts from loosening.
- • What should I check if there is no sound?
Inspect amplifier output, speaker wiring, connectors, fuses, source settings, and polarity. Loose or incorrect connections can prevent audio output.
- • Why are the RGB lights not working?
Check the RGB controller, power connection, connectors, and wiring. A compatible RGB controller is required to operate the integrated lighting.
- • Will the fixed clamp fit my boat tower?
The standard fixed clamp fits tower tubing from 1-7/8 to 3 inches. Measure your tower diameter before installation to confirm compatibility.
- • Why is there rattling when playing music loudly?
Inspect the clamp, mounting bolts, grille, and surrounding tower hardware. Loose components can vibrate noticeably when the speakers produce high output.
- • Can the speaker be difficult to install because of its size?
Yes. Each enclosure is approximately 11.93 inches wide, 15.30 inches deep, and weighs 19.84 pounds. Two-person installation is recommended.
- Diameter : 12 Inch
- Sensitivity : 91 dB
- Impedance : 4 Ohm
- Frequency Response : 58-20000 Hz
- Peak Power Handling : 800 Watts
- Color : Black
- RMS Power Handling : 400 Watts
Features:
- Wet Sounds 12" REV-TEC HD Driver: Delivers high-definition, full-range audio with powerful mid-bass and smooth highs for exceptional clarity over water.
- Coaxial Titanium Horn-Loaded Compression Driver (HLCD): Ensures crisp, detailed highs and remarkable audio fidelity.
- Integrated RGB LED Lighting: Front and rear multi-color LED rings with badge illumination enhance nighttime style on the water.
- Thermoformed Santoprene Rubber Surround: Provides durability and precise audio reproduction in harsh marine environments.
- Advanced Polymer Composite Cone: Combines strength and clarity for long-lasting, high-performance sound.
- Reinforced Injection-Molded Enclosure: UV-protected, marine-grade composite resists water, sun, and vibration.
- Stainless Steel Hardware: Corrosion-resistant for long-term reliability in marine conditions.
- Multiple Grille Styles: XZ, XW, and XS grilles in black or white for aesthetic customization.
- Versatile Mounting Options: Swivel Clamp, Mini Swivel Clamp, Surface Swivel Clamp (SXM), Fixed Clamp, Mini Fixed Clamp, Fixed SA Clamp, and X-Mount surface.
- Sold in Pairs: Grilles and clamps sold separately to allow customization of installation and appearance.
Specifications:
- Speaker Series: REV HD (Revolution HD Series)
- Speaker Size: 12 inches
- RMS Power: 400W per speaker
- Peak Power: 800W per speaker
- Impedance: 4Ω
- Frequency Response: 58 Hz – 20 kHz
- Sensitivity: 91 dB @ 1W/1m
- Driver Technology: Pro-Axial REV TEC™ HD driver with coaxial titanium horn-loaded compression driver
- Woofer Cone: Advanced polymer composite
- Surround: Thermoformed Santoprene rubber
- Enclosure: Reinforced, injection-molded, UV-protected composite
- Grille Styles: XZ, XW, XS (Black or White)
- Mounting Options: Swivel Clamp, Mini Swivel Clamp, Surface Swivel Clamp (SXM), Fixed Clamp, Mini Fixed Clamp, Fixed SA Clamp, X-Mount Surface
- RGB Lighting: Integrated front and rear LED rings
- Hardware: Stainless steel
- Hang Height: 13.36" (339.34 mm)
- Width: 11.93" (303.02 mm)
- Depth: 15.30" (388.62 mm)
- UPC:
- Weight: 15
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
