- Diameter : 6.5 Inch
- Sensitivity : 91 dB
- Impedance : 4 Ohm
- Frequency Response : 40-49000 Hz
- Peak Power Handling : 340 Watts
- Design : 2 Way
- Woofer Composition : Aramid fiber reinforced IMPP
- Tweeter Composition : Component Polyetherimide (PEI) hard dome tweeter
- RMS Power Handling : 75 Watts
Features:
- 340 Watts Max Power (75 Watts Nominal)
- 20mm Polyetherimide (PEI) hard dome tweeter
- 40 Hz to 49 kHz Frequency Range
- 6-1/2" Aramid fiber reinforced Injection Molded Polypropylene (IMPP) cone construction
- Pioneer patented P.F.S.S. (Progressive Flex Suspension System) (U.S. Patent #20,120,106,777)
Specifications:
- System Type: Coaxial 2-way
- Sound Pressure Level (Sensitivity): 91 dB (+- 1.5dB)
- Frequency Range: 40 Hz to 49 kHz
- Continuous Power Handling (RMS): 75 Watts
- Maximum Peak Power Handling: 340 Watts
- Nominal Impedance: 4 ohms
- Woofer Diameter: 6-1/2"
- Woofer Cone Material: Aramid fiber reinforced IMPP
- Woofer Surround Material: Elastic Polymer
- Woofer Basket Material: Iron Plate Press
- Woofer Magnet Material: Ferrite
- Woofer Magnet Weight: 7.41 oz
- Woofer Voice Coil Bobbin: Glass Imide
- Woofer Voice Coil Wire: Copper
- Woofer Mounting Depth: 1-7/8" (Shallow basket)
- Tweeter Type: Component Polyetherimide (PEI) hard dome tweeter
- Tweeter Diameter: 20 mm
- Tweeter Diaphragm Material: Film (PEI)
- Tweeter Magnet Material: Neodymium
- Tweeter Magnet Weight: 0.17
- Warranty (must be purchased from an Authorized Pioneer Dealer): 1 year
- UPC:
- Weight: 4
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
