Pioneer TS-A683FH A-Series 6"x8" 370W Peak Power Handling at 4 Ohms, 2-way Coaxial Car Speakers (Sold as pair)
We are a Pioneer authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • (2) 6"x8" A-Series 2-way Coaxial Car Speakers
- • (2) Bottom mount brackets
- • (2) 12" lengths of speaker wire (each has quick-slides on one end and bare wire on the other)
- • (8) 1" screws
- • Warranty information
- • Specifications on box
- • Owner's Manual
Why Choose Pioneer TS-A683FH Full Range Car Speakers?
Stronger Bass and Cleaner Sound You’ll Notice Right Away
The aramid fiber and mica-reinforced IMPP woofer provides rigid cone stability, delivering tight, punchy bass with minimal distortion at higher volumes. Its lightweight, fast-responding cone restores clarity and detail, making it an instant upgrade over muddy factory sound.
Wide Soundstage with Flexible Fit for Real Installations
PEI tweeters expand high-frequency dispersion for a wider, more immersive soundstage with natural vocal and instrumental clarity. Flexible 5x7 and 6x8 compatibility with an adaptive bottom-mount bracket simplifies installation in tight factory spaces.
Frequently Asked Questions (FAQ)
- • Why do the speakers sound louder but not clearer than my factory speakers?
This is often caused by the factory radio lacking enough clean power to drive aftermarket speakers properly. An external amplifier and proper EQ tuning can significantly improve clarity.
- • Will these fit behind my factory door panels?
Fitment depends on your vehicle's mounting depth and speaker opening dimensions. Verify your vehicle's specifications before installation to ensure a proper fit.
- • Why do I lose bass when I fade the sound to the front?
This usually indicates the rear speakers are producing most of the low frequencies or that the front speakers are wired out of phase. Check the wiring polarity and audio settings for proper balance.
- • Can I install these without adding an amplifier?
Yes. They work with most factory and aftermarket stereos, although an amplifier provides greater output and improved overall sound quality.
- • Why do the speakers make a rattling sound on certain songs?
Loose mounting hardware, vibrating door panels, or nearby trim pieces are common causes. Secure the installation and inspect surrounding panels for unwanted vibrations.
- • Why do the vocals seem distant compared to the music?
An aggressive equalizer setting or improper crossover adjustment can reduce vocal presence. Resetting the EQ and fine-tuning the audio settings usually restores a balanced sound.
- • Can I pair these speakers with a powered subwoofer?
Yes. Adding a powered subwoofer improves low-frequency performance and allows the speakers to focus on midrange and high-frequency reproduction.
- • Why does one speaker stop playing after it rains?
Moisture entering the door or corroded speaker connections can interrupt the audio signal. Inspect the wiring and ensure the moisture barrier inside the door is intact.
- • Is it normal for the speakers to sound different after a week of use?
Yes. Most aftermarket speakers benefit from a short break-in period, allowing the suspension to loosen naturally and produce smoother, more balanced sound.
- Diameter : 5x7/6x8 Inch
- Sensitivity : 90 dB
- Impedance : 4 Ohm
- Frequency Response : 34-49000 Hz
- Peak Power Handling : 370 Watts
- Design : 2 Way
- Woofer Composition : Aramid fiber reinforced IMPP
- RMS Power Handling : 85 Watts
Features:
- Aramid Fiber and Mica Reinforced IMPP Woofer Construction: Engineered with injection-molded polypropylene cones reinforced with aramid fiber and mica, delivering consistent cone thickness, enhanced rigidity, and improved linearity for accurate and low-distortion bass reproduction.
- Wide Soundstage PEI Tweeter Design: Utilizes Polyetherimide (PEI) tweeters that provide expanded sound dispersion, enabling improved imaging and a more immersive listening experience across the cabin.
- Flexible 5x7 and 6x8 Installation Compatibility: Designed primarily as 6x8 speakers while also supporting 5x7 applications, offering versatile fitment options for a broader range of vehicle factory speaker locations.
- Adaptive Bottom Mount Bracket System: Includes adjustable mounting brackets that allow installation flexibility by reducing depth or adjusting height, improving compatibility in tight or non-standard mounting spaces.
- Lightweight High-Rigidity Cone Engineering: Combines reduced mass with increased structural strength to enhance response speed, minimize distortion, and maintain sound clarity at higher output levels.
Specifications:
- System Type: Coaxial 2-way
- Sound Pressure Level (Sensitivity): 90 dB (+- 1.5dB)
- Frequency Range: 34 Hz to 49 kHz
- Continuous Power Handling (RMS): 85 Watts
- Maximum Peak Power Handling: 370 Watts
- Nominal Impedance: 4 ohms
- Woofer Diameter: 6" x 8"
- Woofer Cone Material: Aramid fiber reinforced IMPP
- Woofer Surround Material: Elastic Polymer
- Woofer Basket Material: Iron Plate Press
- Woofer Magnet Material: Ferrite
- Woofer Magnet Weight: 7.41 oz
- Woofer Voice Coil Bobbin: Glass Imide
- Woofer Voice Coil Wire: Copper
- Woofer Mounting Depth: 2-1/2" (Shallow basket)
- Tweeter Type: Polyetherimide (PEI) hard dome tweeter
- Tweeter Diameter: 20 mm
- Tweeter Diaphragm Material: Film (PEI)
- Tweeter Magnet Material: Neodymium
- Tweeter Magnet Weight: 0.17
- Warranty (must be purchased from an Authorized Pioneer Dealer): 1 year
- UPC: 884938509428
- Weight: 4
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
Do you own this product?
Write a review!
-
Love this upgrade on my F250. A huge improvement from the old stock speakers. Glad I was able to get rid of them already. The speakers got some good bass and vocals are so clear.
