DB Drive  WDX15G5R.4

WDX G5R Series 15" 6000W Peak Power Handling 4-Ohm, Dual Voice Coil Car Subwoofer (sold individually)

Item #95501

Product Highlights

  • WDX G5R Series
  • 15" Car Subwoofer
  • 6000W Peak Power Handling
  • DVC 4-Ohm Impedance
  • Sold Individually

  Free 1-Year Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Sorry, this product is no longer available.
Checkout other products listed below

Huge Saving on Other items:



Huge Saving on Other items:


DB Drive WDX15G5R.4 WDX G5R Series 15" 3000W RMS (6000W Peak Power Handling) 4-Ohm, Dual Voice Coil Car Subwoofer (sold individually)


DB_Authorized_Banner

We are a DB Drive authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
DB_Drive_MatrixPlus
Feel the Bass. Not Just Hear It.

The DB Drive WDX15G5R.4 isn’t your average subwoofer—it’s built to hit hard and hit deep. With up to 6000 watts of peak power, this 15" monster brings chest-pounding bass that turns every drive into a full-body experience. Whether you're showing off at a meet or just want to feel every beat, this sub brings the kind of low-end that demands attention.

Built for Serious Systems

This isn’t just about loud—it’s about clean, controlled bass that hits exactly the way it should. The WDX15G5R.4 features a high-excursion motor, dual voice coils, and Y35 ferrite magnets for precision performance. A custom ribbed surround and aluminum basket keep everything stable, cool, and ready for whatever you throw at it.



DB_Drive_MatrixPlus
DB_Drive_MatrixPlus
Made to Take the Heat

Push it hard. It can handle it. From the custom-tooled dust caps to the high-temp coils and custom gasket that seals in the sound, this sub was built with hardcore durability in mind. It doesn’t just perform—it holds up. This is the kind of gear you build a system around.


SPECIFICATIONS


  • Diameter : 15 Inch
  • Maximum Power : 6000 Watts
  • Sensitivity : 85.7 dB
  • Impedance : 4 Ohm
  • Peak Power Handling : 6000 Watts
  • Number of Voice Coils : Dual
  • RMS Power Handling : 3000 Watts

FEATURES


Features:

  • 3.0" 4-Layer Anodized Aluminum High-Temperature Voice Coil: Enhanced heat dissipation for high-power performance and distortion-free sound.
  • Non-Pressed Paper Cone: Offers lightweight and flexible construction for improved sound quality.
  • Double-Stitched Reinforced Foam Surround: Provides enhanced durability and resilience, improving the speaker's lifespan.
  • Dual Poly-Cotton Dampeners: Reduces distortion for clearer sound reproduction.
  • Die-Cast Aluminum Vented Basket: Promotes better airflow, preventing overheating and improving overall performance.
  • Rubber Gasket Trim Ring: Ensures a secure and vibration-resistant seal for enhanced sound clarity.
  • Large Gauge Compression Terminals: Allows for high-current connections and improved signal transmission.
  • Protective Magnet Cover: Shields the magnet from damage and helps maintain sound quality.



Specifications:

  • Dynamic Power Handling: 6000 Watts
  • Nominal Power Handling: 3000 Watts
  • Impedance: Dual 4Ω Voice Coil
  • Resonant Frequency (fs): 30.713 Hz
  • D.C. Voice Coil Resistance (Re): 2 x 3.2Ω
  • Mechanical Quality Factor (Qms): 3.476
  • Electrical Quality Factor (Qes): 0.694
  • Total Quality Factor (Qts): 0.578
  • Equivalent Air Volume (Vas): 57.863 L
  • Mechanical Compliance of Suspension (CMS): 62.998 mm/N
  • Mass of Diaphragm/Coil (Mms): 426.261 g
  • Force Factor (BL): 27.547
  • Sound Pressure Level (SPL): 85.7 dB
  • UPC: 811536039521
  • Weight: 25
