Musway D8v4 8-Channel 70W RMS x 8 at 4 Ohm, Class-D Full Range Car Amplifier with 10-Channel Digital Sound Processor Output - German Engineered
We are a Musway authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • D8v4 8-Channel Amplifier with 10-Channel Digital Sound Processor Output
- • 1.5 m USB Cable
- • 20-pole Cable Adapter (Speaker Outputs)
- • 20-pole Cable Adapter (High Level Inputs, REM In- and Outputs)
- • 8-pole Cable Adapter (Pre-Amplifier In- and Outputs)
- • 40 A Replacement Fuse
- • 3 mm Hex Key
- • Owner's Manual
Seamless Integration & Premium Audio Quality for Unmatched Performance
Enjoy seamless integration and top-tier protection with EPS® high-level input, effortless start-stop compatibility, and premium audio quality powered by Burr-Brown converters and Analog Devices DSP for crystal-clear performance every drive.
Unleash Precision Sound with Advanced DSP Technology and Unmatched Clarity
Take full control of your sound with advanced dual 32-bit DSP technology, enjoy soft-clipping protection at 2 Ohms, and experience crystal-clear audio clarity with a 90 dB signal-to-noise ratio and wide frequency response from 15 Hz to 22 kHz.
Precision Audio Control & Wireless Flexibility
Experience precision audio with ultra-low 0.1% THD, enjoy wireless streaming with optional Bluetooth® dongles, and fine-tune your system on the fly using the DRC1 remote with OLED display for complete DSP control.
Features:
- Error Protection System (EPS®): High level input with built-in safety features
- Start-Stop Compatibility: Auto turn-on functionality for modern vehicles
- Premium Audio Processing: Burr-Brown converters (PCM3168A) and Analog Devices DSP (ADAU1452)
- Advanced DSP Control: Dual 32-bit, 330 MHz DSP managed via PC or smartphone app
- Soft-Clipping Protection: Power attenuation during 2 Ohm operation
- High Signal Clarity: 90 dB signal-to-noise ratio
- Wide Frequency Response: 15 Hz – 22 kHz (-3dB)
- Low Distortion Output: 0.1% THD at 1 kHz, 4 Ohms, 90% power
- Wireless Streaming Option: Supports Bluetooth® USB dongles (BTS, BTS-HD & BTA2)
- Optional Remote Control: DRC1 digital remote with OLED display for DSP adjustments
Musway DSP Software for Windows:
Specifications:
POWER SUPPLY
- Voltage: 7.6 – 17.3 VDC
- Idle Current: 1.5 A
- Switched Off: <0.1 mA
- Remote IN: 9 – 15 VDC (1 mA)
- Remote OUT: 11 – 15 VDC (200 mA)
- Fuse: 40 A
AMPLIFIER STAGE
- Distortion (THD, 1 kHz @ 4 Ω, 10 W): 0.01 %
- Bandwidth (-3 dB, 2 V RMS, 4 Ω): 15 Hz – 22 kHz
- S/N Ratio (@ A-weighted, 1 V, Max Power): 95 dB A
- Damping Factor (@ 1 kHz, 2 V RMS, 4 Ω): >70
- Input Sensitivity: 3.5 – 10 or 18 V RMS (High-level), 1.5 – 4.5 V RMS (Low-level)
- Input Impedance: 13 Ω (High-level), 47 kΩ (Low-level)
Output Power @ 13.8 VDC, 1% THD
- 8 × 125 W RMS @ 2 Ω (DHR*)
- 8 × 70 / 100 W RMS @ 4 / 2 Ω
Output Power Bridged @ 13.8 VDC, 1% THD
SIGNAL OUTPUTS
- RCA OUT CH9 / CH10: 4 V RMS Max.
- UPC:
- Weight: 5
- Authorized Internet Dealer
Warranty: 3 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 3 Year(s) from the original date of purchase with proper return authorization.
