DB Drive WDX PRO1000.4 WDX PRO Series 4-Channel 75W RMS x 4 at 4 Ohm, Class-D Full Range Car Amplifier
We are a DB Drive authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
Powerful 300W x 4 Class D Amp with Premium Audio Clarity & Smart Crossover
Unleash powerful, crystal-clear sound with our 300W x 4 Channel Class D Amplifier, delivering clean, efficient power to multiple speakers. Enjoy pure, noise-free audio thanks to premium Audiophile RCA Connectors designed for flawless signal transmission. With Adaptive Crossover Technology, your system automatically balances frequencies for smooth, distortion-free performance every time you hit play.
Efficient Power & Easy Installation with Heavy-Duty Connections
Experience powerful, full-range sound with advanced Class D technology that maximizes energy efficiency while minimizing heat and power use. The direct connect speaker terminals provide easy, secure wiring for a clean and hassle-free installation. Plus, heavy-duty 4 gauge power wire inputs ensure your amplifier gets the consistent current it needs for reliable, high-performance audio.
Smart Protection & Thermal Management for Reliable, High-Performance Audio
Keep your audio system safe and running smoothly with the built-in Audio Protection Circuit that guards against electrical faults and overloads. The Signal Evaluation Status Indicator provides real-time alerts to prevent distortion and ensure optimal sound quality. Plus, the smart Collective Heat Management system effectively dissipates heat to maintain consistent, reliable performance even during extended use.
- Maximum Power : 300 Watts
- Number of Channels : 4
- Frequency Response : 15-20000 Hz
- Amplifier Class : D
Features:
- 300W x 4 Channel Class D Amplifier: A compact, powerful amplifier that delivers up to 300 watts per channel across four channels, ideal for driving multiple speakers with clean, efficient power.
- ATC - Audiophile RCA Connectors: Premium-grade RCA connectors designed for high-fidelity signal transmission, reducing noise and signal loss for crystal-clear audio quality.
- ACT - Adaptive Crossover Technology: Smart crossover technology that automatically adjusts frequency ranges for your connected speakers, ensuring balanced, distortion-free sound.
- High-Efficiency Full Range Class D Technology: An advanced amplifier design that offers superior energy efficiency while delivering powerful, full-range sound with less heat and power consumption.
- Direct Connect Speaker Terminals: User-friendly, secure terminals that allow direct, reliable connections between your amplifier and speaker wires for a cleaner, more efficient setup.
- 4 Gauge Power Wire Inputs: Heavy-duty power inputs that accept thick 4-gauge wires, supporting higher current flow for consistent, reliable amplifier performance.
- APC - Audio Protection Circuit: A built-in safety system that protects the amplifier and speakers from electrical faults, overloads, and short circuits to extend system life.
- SESI - Signal Evaluation Status Indicator: A visual indicator that monitors and displays the amplifier’s signal status, alerting you to issues like clipping or distortion for real-time protection and adjustments.
- CHM - Collective Heat Management: An intelligent thermal management system that evenly distributes and dissipates heat, preventing overheating and maintaining consistent performance.
Specifications:
- 4 x 75 Watts @ 4 ohms
- 4 x 150 Watts @ 2 ohms
- 4 x 300 Watts @ 1 ohm
- 4 ohms (Bridged): 2 x 1500 Watts
- Working Voltage: 12-15 Volts
- Frequency Response: 15 Hz - 20000 Hz
- Signal to Noise Ratio: 96dB
- ACT - Variable Crossover HP/BP/LP
- Damping Factor: ≥200
- Low-Level Input: 6V - 0.2mV
- Ch 1/2 High Pass Filter Variable: 15 Hz - 6000 Hz
- Ch 1/2 Low Pass Filter Variable: 50 Hz - 2000 Hz
- Ch 3/4 High Pass Filter Variable: 15 Hz - 6000 Hz
- Ch 3/4 Low Pass Filter Variable: 50 Hz - 2000 Hz
- Minimum working Impedance: 1 ohm stereo / 2 Ohms bridged
- UPC: 811536038517
- Weight: 0
