- Diameter : 12 Inch
- Sensitivity : 93.3 dB
- Impedance : 4 Ohm
- Frequency Response : 64.7 Hz
- Peak Power Handling : 4500 Watts
- Top Mount Depth : 5.39 Inches
- RMS Power Handling : 3000 Watts
Features:
- 4.0" High Temperature Voice Coil with Shorting Ring: This oversized, heat-resistant voice coil allows for higher power handling and extended play at high volumes, while the shorting ring minimizes distortion for smooth, accurate sound.
- Neodymium Magnet for Higher Efficiency: A powerful yet lightweight neodymium magnet boosts speaker sensitivity and efficiency, delivering louder, cleaner audio with less power consumption.
- Treated Paper Cone with Cloth Surround: The treated paper cone provides warm, natural sound reproduction, and the durable cloth surround ensures long-lasting performance and precise cone movement.
- Extreme Output Capability: Designed to handle massive sound pressure levels, this speaker delivers intense, distortion-free audio, perfect for high-performance sound systems.
- Die-Cast Aluminum: A rigid, die-cast aluminum frame eliminates unwanted vibrations and resonance, enhancing sound clarity and ensuring the speaker stays solid and reliable under pressure.
- EVA Mounting Gasket: This soft, high-density EVA gasket creates a tight, vibration-dampening seal for improved audio performance and secure, noise-free installation.
- Compression Speaker Terminals: Heavy-duty compression terminals provide secure, easy-to-use connections for reliable signal transfer and hassle-free wiring.
Specifications:
- Dynamic Power Handling: 4500 Watts
- Nominal Power Handling: 3000 Watts
- Impedance: 4-Ohms Voice Coil
- Resonant Frequency (fs): 64.7 Hz
- D.C. Voice Coil Resistance (Re): 4-Ohms
- Mechanical Quality Factor (Qms): 4.84
- Electrical Quality Factor (Qes): 0.36
- Total Quality Factor (Qts): 0.34
- Equivalent Air Volume to Cms (Vas): 18.7 L
- Mass of Diaphragm/Coil (Mms): 118.4 g
- Force Factor (BL): 19.3
- Sound Pressure Level (SPL): 93.3 dB
Dimensions:
- Outside Diameter: 12.32"/ 313 mm
- Cutout Diameter: 11.15"/ 283.12 mm
- Mounting Depth: 5.39"/ 137 mm
- UPC: 811536039064
- Weight: 0
