- Diameter : 12 Inch
- Sensitivity : 93.9 dB
- Impedance : 8 Ohm
- Frequency Response : 5 Hz
- Peak Power Handling : 6000 Watts
- Top Mount Depth : 5.39 Inches
- RMS Power Handling : 3000 Watts
Features:
- 4.0" High Temperature Voice Coil with Shorting Ring: This oversized, heat-resistant voice coil allows for powerful, sustained performance at high volumes, while the shorting ring minimizes distortion for clean, precise sound.
- Neodymium Magnet for Higher Efficiency: A lightweight yet incredibly strong magnet increases sensitivity and efficiency, delivering louder, clearer audio with less energy draw.
- Treated Paper Cone with Cloth Surround: The treated paper cone ensures warm, natural sound reproduction, and the cloth surround enhances durability while providing precise control over cone movement.
- Extreme Output Capability: Engineered to handle massive sound pressure levels, this speaker delivers thunderous, distortion-free performance perfect for high-impact sound systems.
- Die-Cast Aluminum: The rigid, anti-resonant die-cast aluminum frame eliminates unwanted vibrations, preserving audio clarity and providing long-lasting structural support.
- EVA Mounting Gasket: A high-density EVA gasket creates a tight, vibration-dampening seal between the speaker and mounting surface, ensuring noise-free, secure installation.
- Compression Speaker Terminals: Heavy-duty compression terminals offer fast, secure connections and maximum signal transfer for reliable, hassle-free setup.
Specifications:
- Dynamic Power Handling: 6000 Watts
- Nominal Power Handling: 3000 Watts
- Impedance: 8-Ohms Voice Coil
- Resonant Frequency (fs): 59 Hz
- D.C. Voice Coil Resistance (Re): 8-Ohms
- Mechanical Quality Factor (Qms): 3.94
- Electrical Quality Factor (Qes): 0.42
- Total Quality Factor (Qts): 0.38
- Equivalent Air Volume to Cms (Vas): 32.6 L
- Mass of Diaphragm/Coil (Mms): 82.8 g
- Force Factor (BL): 19.5
- Sound Pressure Level (SPL): 93.9 dB
Dimensions:
- Outside Diameter: 12.32"/ 313 mm
- Cutout Diameter: 11.15"/ 283.12 mm
- Mounting Depth: 5.39"/ 137 mm
- UPC: 811536039088
- Weight: 0
