- Diameter : 10 Inch
- Sensitivity : 91.5 dB
- Impedance : 8 Ohm
- Frequency Response : 58.6 Hz
- Peak Power Handling : 1200 Watts
- Top Mount Depth : 4.56 Inches
- RMS Power Handling : 600 Watts
Features:
- 3.5" High Temperature Voice Coil with Shorting Ring: This large, heat-resistant voice coil ensures excellent power handling and reduces distortion for smooth, precise sound even during high-output sessions.
- High Strength Ferrite Oxide Magnet: A powerful ferrite magnet enhances sensitivity and output, delivering strong, reliable performance with deep, controlled bass and clear mids.
- Treated Paper Cone with Cloth Surround: The treated paper cone produces rich, natural audio, while the cloth surround improves durability and allows for controlled, accurate cone movement.
- Die-Cast Aluminum Basket: A sturdy, anti-resonant die-cast aluminum frame eliminates unwanted vibrations, preserving audio clarity and ensuring long-lasting, rugged performance.
- EVA Mounting Gasket: This high-density EVA gasket provides a secure, vibration-absorbing seal for a clean, noise-free installation.
- Compression Speaker Terminals: Heavy-duty compression terminals ensure quick, reliable, and high-conductivity connections for easy setup and consistent performance.
Specifications:
- Dynamic Power Handling: 1200 Watts
- Nominal Power Handling: 600 Watts
- Impedance: 8Ω Voice Coil
- Resonant Frequency (fs): 58.6 Hz
- D.C. Voice Coil Resistance (Re): 8-Ohms
- Mechanical Quality Factor (Qms): 3.39
- Electrical Quality Factor (Qes): 0.50
- Total Quality Factor (Qts): 0.43
- Equivalent Air Volume to Cms (Vas): 22.8 L
- Mass of Diaphragm/Coil (Mms): 58.6 g
- Force Factor (BL): 15.3
- Sound Pressure Level (SPL): 91.5dB
Dimensions:
- Outside Diameter: 10.28"/ 261 mm
- Cutout Diameter: 9.06"/ 230 mm
- Mounting Depth: 4.56"/ 115 mm
- UPC: 811536039095
- Weight: 0
