- Diameter : 12 Inch
- Sensitivity : 96.1 dB
- Impedance : 8 Ohm
- Frequency Response : 52.8 Hz
- Peak Power Handling : 1200 Watts
- Top Mount Depth : 5.26 Inches
- RMS Power Handling : 600 Watts
Features:
- 3.5" High Temperature Voice Coil: A large, heat-resistant voice coil provides exceptional power handling and durability, ensuring consistent, distortion-free sound even under intense use.
- High Strength Ferrite Oxide Magnet: This robust ferrite magnet boosts speaker sensitivity and output, delivering deep, punchy bass and clear midrange frequencies.
- Treated Paper Cone with Cloth Surround: The treated paper cone offers warm, natural sound reproduction, while the cloth surround enhances durability and precise cone control.
- Die-Cast Aluminum Basket: A rigid, anti-resonant die-cast aluminum frame minimizes vibrations and preserves clean, accurate audio performance.
- EVA Mounting Gasket: A high-density EVA gasket ensures a tight, vibration-dampening seal between the speaker and mounting surface for secure, noise-free installation.
- Compression Speaker Terminals: Heavy-duty compression terminals provide quick, secure, and reliable connections for hassle-free installation and optimal signal transfer.
Specifications:
- Dynamic Power Handling: 1200 Watts
- Nominal Power Handling: 600 Watts
- Impedance: 8-Ohms Voice Coil
- Resonant Frequency (fs): 52.8 Hz
- D.C. Voice Coil Resistance (Re): 8-Ohms
- Mechanical Quality Factor (Qms): 2.94
- Electrical Quality Factor (Qes): 0.44
- Total Quality Factor (Qts): 0.38
- Equivalent Air Volume to Cms (Vas): 44.9 L
- Mass of Diaphragm/Coil (Mms): 77.4 g
- Force Factor (BL): 17.7
- Sound Pressure Level (SPL): 96.1dB
Dimensions
- Outside Diameter: 12.36"/ 314 mm
- Cutout Diameter: 11.02"/ 280 mm
- Mounting Depth: 5.26"/ 133.50 mm
- UPC: 811536039101
- Weight: 0
