Nemesis Audio  UM-1600D

Ultra Micro Series 1600W Max Power, Class-D Mono Subwoofer Car Amplifier

Item #96299

Condition:   Brand New

Product Highlights

  • Ultra Micro Series
  • 1600W Max Power
  • Class-D Mono Subwoofer Car Amplifier

  Free 1-Year Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping.
60 DAYS Price change protection.

$249.99

Reg. Price $349.99  Save $100.00
Add Extended Warranty
  Free 1-Year Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping.
60 DAYS Price change protection.

No Credit needed for acima logo. Learn More

Nemesis Audio Authorized Dealer

Huge Saving on Other items:


Huge Saving on Other items:


Nemesis Audio

Nemesis Audio UM-1600D Ultra Micro Series 1600W RMS x 1 at 1 Ohm, Class-D Mono Subwoofer Car Amplifier


Nemesis Audio

We are a Nemesis Audio authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • Ultra Micro Series Class-D Mono Subwoofer Car Amplifier
  • • Owner's Manual
Delivers Crisp Clarity and Deep Bass

Unleash deep, powerful bass with up to 1600W max power at 1Ω and 800W RMS, featuring a wide 20Hz–500Hz frequency response and a flexible 50Hz–250Hz crossover range for precise subwoofer control and performance.

Precision Audio Control and Robust Protection

Delivering clean, high-quality bass with ultra-low < 0.3% THD and > 90 dB signal-to-noise ratio, this compact amplifier fits almost anywhere at just 188.7mm x 84.4mm x 40.5mm (7.43″ x 3.33″ x 1.6″), and offers wide input sensitivity from 0.25V to 10V for flexible installation.


SPECIFICATIONS


  • Maximum Power : 1600 Watts
  • Number of Channels : 1
  • Frequency Response : 20-500 Hz
  • RMS Power Output : 1x360 Watts
  • Amplifier Class : D

FEATURES


Features:

  • Ultra-Micro Class D Design: Delivers high-powered bass performance in a compact chassis that fits tight installation spaces
  • 800W RMS @ 1 Ohm: Provides strong power for high-performance subwoofer systems
  • 1600W Max Power: Produces up to 1600 watts of maximum output at 1 ohm
  • Flexible Impedance Output: Delivers 580W RMS @ 2 ohms and 360W RMS @ 4 ohms
  • Wide Frequency Response: Covers 20Hz–500Hz for powerful low-frequency performance
  • Adjustable Crossover: 50Hz–250Hz crossover range allows you to fine-tune the amplifier to your subwoofer
  • High Input Flexibility: 0.25V–10V input sensitivity works with a wide range of factory and aftermarket audio sources
  • Compact Installation: Measures only 7.43" × 3.33" × 1.6", making it ideal for space-limited builds



Specifications:

  • Type: 1-Channel / Monoblock Class D Amplifier
  • Max Power @ 1 Ohm: 1600W
  • RMS Power @ 1 Ohm: 800W
  • Max Power @ 2 Ohms: 1160W
  • RMS Power @ 2 Ohms: 580W
  • Max Power @ 4 Ohms: 720W
  • RMS Power @ 4 Ohms: 360W
  • Frequency Response: 20Hz–500Hz
  • Crossover Range: 50Hz–250Hz
  • Input Sensitivity: 0.25V–10V
  • Signal-to-Noise Ratio: >90dB
  • Total Harmonic Distortion (THD): <0.3%
  • Dimensions: 7.43" × 3.33" × 1.6" (188.7 × 84.4 × 40.5mm)
  • UPC:
  • Weight: 11
  • Authorized Internet Dealer
Warranty: 0 Months Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 0 Months from the original date of purchase with proper return authorization.
