Rockford Fosgate T1S2-10S Power Series 10" 500W RMS (1000W Peak Power Handling) 2 Ohm, Single Voice Coil Shallow-Mount Component Car Subwoofer for Sealed Enclosures
We are a Rockford Fosgate authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
-
- • 10" 1-Ohm Single Voice Coil Shallow-Mount Component Car Subwoofer
- • Aluminum Trim Ring (installed)
- • (12) 1-5/8" Allen Head Screws
- • 4mm Allen Head Bit
- • Owner's Manual
Why Choose Rockford Fosgate T1S2-10S Component Car Subwoofer?
Unmatched Durability and Precision
Experience long-lasting performance with our Supercritical Synthetic Organic Polymer Surround, engineered for elasticity and resilience. Enjoy crystal-clear audio from a Linear Carbon Fiber/PMI/Glass Fiber Cone with Aluminum Dust Cap, designed for strength and lightweight accuracy. Benefit from a Chemically Bonded Co-Molded Surround that ensures a secure, enduring structure, while Symmetrical Ultra-Flexible Braided Flat Tinsel Leads provide reliability under the most demanding conditions.
Engineered for Extreme Performance
Achieve unmatched control and stability with Dual Nomex Progressive Spiders with Stitched Tinsel Leads, designed for superior power handling. The Dual Wound Single 2.5" Pure Copper Voice Coil maximizes thermal and electrical efficiency for relentless performance. Experience powerful output with the High Temp, High Energy Neodymium Motor Structure, delivering exceptional magnetic strength and heat resistance. Plus, the Diecast Aluminum Frame with Integrated Heat Sink Fins ensures lasting durability and optimal cooling under extreme conditions.
Designed for Style, Strength, and Smart Installation
Elevate your setup with the Detachable Die-Cast Aluminum Trim Ring, delivering a sleek, premium look and flexible installation options. Add extra protection with the Optional Protective Grille Insert, keeping your cone and surround safe in any environment. Enjoy secure, corrosion-resistant wiring with Custom 10 AWG Slot-Loaded Brass Push Spring Terminals, precision-engineered for ultimate reliability. Plus, these subs are optimized for Compact Sealed Enclosures, providing maximum output without sacrificing valuable space.
Frequently Asked Questions (FAQ)
- • Why isn't the bass as strong as expected?
Check the enclosure volume, amplifier output, polarity, and gain settings. The wrong box can noticeably reduce bass performance and overall output.
- • What amplifier power should I use?
Use an amplifier matched to the subwoofer's RMS rating and 2-ohm load. Clean power and proper gain settings help deliver strong performance.
- • Why does it sound weak in a shallow enclosure?
Limited airspace can affect low-frequency response. Make sure the enclosure meets the recommended volume and is properly sealed.
- • Will it fit under my vehicle's seat?
The shallow design suits space-limited installations, but mounting depth and magnet clearance still need to be checked carefully.
- • Why does the bass distort at higher volume?
Clipping, excessive gain, or insufficient clean power can cause distortion. Lower the gain and verify the amplifier is properly matched.
- • Why does the vehicle rattle when the bass hits?
Strong output can vibrate trim, panels, and enclosure hardware. Tighten loose parts and add sound-deadening material where needed.
- • Why does the cone move but produce little bass?
Check polarity, enclosure sealing, amplifier output, and crossover settings. Phase cancellation can make the bass sound noticeably weaker.
- • Why does it sound better in another enclosure?
Enclosure volume, construction, and tuning strongly affect bass response. Use a box designed around the woofer's specifications for best results.
- • Why does it get hot during extended use?
Some heat is normal, but excessive heat can indicate overdriving or clipping. Reduce the gain and volume if it becomes unusually hot.
- • What should I check if it suddenly stops working?
Check the amplifier, fuse, speaker wiring, terminals, impedance, and audio signal. Test each connection before replacing the subwoofer.
- Diameter : 10 Inch
- Sensitivity : 82 dB
- Impedance : 1 Ohm
- Frequency Response : 27-250 Hz
- Peak Power Handling : 1000 Watts
- Top Mount Depth : 3.01 Inches
- Shallow Mount : Yes Inch
- Number of Voice Coils : Single
- Suggested Ported Box Volume : 0.5-0.75 Cubic ft.
- Mounting Depth : 3.01 Inches
- RMS Power Handling : 500 Watts
Features:
- Supercritical Synthetic Organic Polymer Surround: Delivers exceptional durability and elasticity for high-performance sound.
- Linear Carbon Fiber/PMI/Glass Fiber Cone with Aluminum Dust Cap: Ensures rigidity, lightweight design, and accurate sound reproduction.
- Chemically Bonded Co-Molded Surround: Provides a stronger, long-lasting attachment for maximum reliability.
- Symmetrical Ultra-Flexible Braided Flat Tinsel Leads: Designed to resist fatigue for consistent performance under extreme conditions.
- Dual Nomex Progressive Spiders with Stitched Tinsel Leads: Improves stability, control, and power handling.
- Dual Wound Single 2.5" Pure Copper Voice Coil: Features interior and exterior coils for enhanced thermal and electrical performance.
- High Temp, High Energy Neodymium Motor Structure: Offers strong magnetic force and heat resistance for superior output.
- Diecast Aluminum Frame with Integrated Heat Sink Fins: Provides structural integrity and efficient heat dissipation.
- Detachable Die-Cast Aluminum Trim Ring: Adds a sleek aesthetic and installation flexibility.
- Optional Protective Grille Insert: Available for added cone and surround protection.
- Custom 10 AWG Slot-Loaded Brass Push Spring Terminals: Tin-plated for corrosion resistance and secure connections.
- Optimized for Compact Sealed Enclosures: Designed to deliver maximum output in minimal space.
Specifications:
- Size: 10-inch
- Impedance (Ohms): 2
- Cone Material: Carbon/PMI/Glass Fiber
- Surround Material: Synthetic Polymer
- Basket Material: Cast Aluminum
- Grille: None included
- Free-Air: No
- Dual Voice Coil: No
- Sensitivity: 82 dB at 1 watt
- Frequency Response: 27 – 250 Hz
- Max RMS Power Handling: 500 W
- Peak Power Handling (Watts): 1000 W
- Top Mount Depth (inches): 3.06
- Bottom Mount Depth (inches): N/A
- Cutout Diameter or Length (inches): 9.13
- Frame Width: 10.86
- Frame Length: 10.86
- Vas (liters): 13.1
- Fs (Hz): 42
- Qts: 0.95
- Xmax (millimeters): 15
- UPC: 780687366797
- Weight: 12
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
