PRV Audio 12W1600 PRO Series 12" 1600W RMS (3200W Peak Power Handling) at 8-Ohms, Midrange Car Speaker (Single)
We are a PRV Audio authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 12" PRO Series Midrange Car Speaker
- • Installation Accessories
- • Owner's Manual
High Impact Midbass That Hits With Authority
The PRV Audio 12W1600 is built for car audio enthusiasts who want serious low frequency punch with clean control. With 1600 watts continuous program power, it delivers strong midbass energy that stays tight even when pushed hard. Its high excursion design with 10.5 mm Xmax gives you deep bass movement with precision, so every hit feels powerful but still controlled instead of messy or distorted.
Built Strong for Heat, Pressure, and Nonstop Play
This speaker is engineered to handle real world abuse with confidence. The 4 inch split copper voice coil on a fiberglass former uses high temperature adhesives to maintain stability under heavy load, while the ventilated gap and forced airflow design help keep things cool during long sessions. A strong BL motor structure keeps cone movement accurate, giving you clean low frequency response even at higher volume levels where other drivers start to struggle.
Rugged Design Made for Tight and High Output Builds
From the reinforced glass fiber paper cone to the double spider and triple roll surround, everything is built for strength and stability under extreme conditions. This midbass driver works especially well in compact vented, sealed, and folded horn enclosures, making it a flexible choice for custom car audio setups. With PRO grade reliability and low distortion performance, the 12W1600 is ready for high SPL systems that need power, clarity, and long lasting durability in one solid package.
Frequently Asked Questions (FAQ)
- • Why does my PRV Audio 12W1600 not hit the low notes I expected?
The 12W1600 performs best when installed in an enclosure that matches its specifications. An incorrect box design or tuning can reduce low-frequency performance.
- • Can I use the PRV Audio 12W1600 in a sealed enclosure?
Yes. It can work in a sealed enclosure, but many users compare sealed and ported designs to achieve the bass response that best fits their listening preferences.
- • Why does my 12W1600 make a mechanical noise during heavy bass?
Mechanical noises are often caused by excessive cone excursion, amplifier clipping, or frequencies below the woofer's intended operating range. Proper crossover settings help prevent this issue.
- • Is the PRV Audio 12W1600 suitable for professional PA speaker cabinets?
Yes. It is commonly used in high-output PA and custom loudspeaker systems where powerful bass and efficiency are important.
- • Why does my speaker box flex when the PRV Audio 12W1600 is playing?
The woofer can generate enough output to expose weak enclosure panels. Adding internal bracing and using thicker materials can reduce enclosure flex.
- • Can I wire two PRV Audio 12W1600 woofers to one amplifier?
Yes, provided the combined impedance is compatible with the amplifier and it can deliver enough clean RMS power for both speakers.
- • Why does my amplifier clip before the PRV Audio 12W1600 reaches full output?
Incorrect gain settings, low system voltage, or an amplifier that cannot supply enough continuous power are common causes of early clipping.
- • Does the PRV Audio 12W1600 require a break in period?
Some users notice slight changes after several hours of playback, but enclosure design, crossover settings, and amplifier tuning have a much greater effect on performance.
- • Why does my bass sound uneven depending on where I stand?
Room acoustics, vehicle cabin acoustics, and enclosure placement can create peaks and dips in bass response. Repositioning the enclosure may improve overall bass consistency.
- • How can I get the strongest bass performance from the PRV Audio 12W1600?
Use a properly designed enclosure, match the woofer with a quality amplifier, apply the recommended crossover settings, and ensure the enclosure is airtight and well braced for maximum output.
- Diameter : 12 Inch
- Sensitivity : 94 dB
- Impedance : 8 Ohm
- Frequency Response : 55-2500 Hz
- Peak Power Handling : 3200 Watts
- RMS Power Handling : 1600 Watts
Features:
- High Power Midbass Output Engineered Design: Delivers strong and controlled low frequency performance with 1600 watts continuous program power for demanding car audio systems.
- Advanced 4 Inch Voice Coil Structure: Features a split copper wire voice coil on a fiberglass former with high temperature adhesives for superior thermal stability and durability.
- High Excursion Bass Capability: Provides 10.5 mm Xmax with up to 36 mm peak to peak excursion for deep bass reproduction with controlled movement.
- Efficient Ventilation Cooling System: Includes ventilated voice coil gap and forced airflow frame design to reduce heat buildup and minimize power compression.
- High BL Motor Control Performance: Engineered with a strong magnetic assembly to deliver precise cone control and improved low frequency accuracy.
- Reinforced Cone Construction Design: Uses a glass fiber reinforced paper cone with ribbed structure for improved rigidity and smooth response.
- Heavy Duty Suspension System: Features double spider and triple roll cloth surround for stability under high excursion and extreme playback conditions.
- Compact Enclosure Optimization: Designed for small vented, sealed, and folded horn applications where space efficiency and high output are required.
- Professional PRO Grade Reliability: Built for long term use in high SPL environments with low distortion and consistent performance under load.
Specifications:
- Nominal Diameter: 12″ (305 mm)
- Nominal impedance: 8 Ohm
- Nominal Power Handling: 800 Watts
- Continuous Program Power (RMS): 1600 Watts
- Max Peak Power: 3200 Watts
- Sensitivity 2.83V at 1m: 94 dB
- Frequency Response: 55 – 2,500 Hz
- Voice Coil Diameter: 4″ (100 mm)
- Voice Coil Wire: Copper
- Voice Coil Winding Depth: 27.0 mm
- Former Material: Glass Fiber
- Magnetic Gap Depth: 12.0 mm
- Frame Material: Die Cast Aluminum
- Overall Diameter: 12.40” (315 mm)
- Front Mount Baffle Cutout: 11.16” (283.4 mm)
- Mounting Depth: 5.51” ( 140 mm)
- Overall Depth: 6.04” (153.5 mm)
- UPC: 0602938022033
- Weight: 24.2
- Authorized Internet Dealer
Warranty: 1 Year Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 Year from the original date of purchase with proper return authorization.
