Kicker 52L7XS122 SoloXS L7XS Series 12" 3000W RMS at 2-Ohms, Dual Component Car Subwoofer
We are a Kicker authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • SoloXS L7XS Series 12" 3000W Dual Voice Coil Component Car Subwoofer
- • Owner's Manual
Why Choose Kicker 52L7XS122 Component Car Subwoofer?
Powerful Bass and Built To Last
The 12" Dual 2-Ohm SoloXS L7XS Series square subwoofer is designed for serious bass, handling 1,500–3,000 watts RMS of recommended amplifier power. Its double-pressed pulp cone and durable NBR surround deliver strong, controlled performance for demanding audio systems. A 3" aluminum voice coil former adds durability and helps this subwoofer handle high-power bass with confidence.
Built For Extreme Bass
Experience powerful low-end performance with 43.1 mm of linear excursion and a 705 oz. triple-stacked ferrite magnet motor built for serious output. Dual Conex meta-aramid fiber spiders, a custom rubber boot, and a cast-aluminum basket provide strength, protection, and maximum cooling during demanding play. Heavy-duty 8 AWG push and dual 4 AWG terminals deliver secure, reliable connections for high-powered car audio systems.
Deep Bass and Built To Perform
Dual high-strand tinsel leads provide reliable power delivery, while aerodynamic basket brace channels help reduce back pressure for smoother bass performance. With a 20–100 Hz frequency response, this subwoofer delivers deep, punchy low-end sound that brings your music to life. The 3 cu. ft. optimal ported enclosure, 10-1/8" mounting depth, and 11-1/16" cutout offer a practical setup for a powerful bass system.
Frequently Asked Questions (FAQ)
- • What is the Kicker 52L7XS122?
The Kicker 52L7XS122 is a 12-inch SoloXS L7XS Series square subwoofer with a dual 2-ohm voice coil and 3,000 watts RMS recommended amplifier power.
- • How much amplifier power does the 52L7XS122 need?
It is designed for 1,500–3,000 watts RMS of recommended amplifier power. Proper gain setting and tuning are important for strong output without clipping.
- • What impedance options does the 52L7XS122 provide?
The dual 2-ohm voice coils can be wired in parallel for a 1-ohm final load or series for a 4-ohm final load.
- • Can I run the 52L7XS122 at 1 ohm?
Yes. Wiring both 2-ohm voice coils in parallel produces a 1-ohm final impedance. Make sure your amplifier is rated for 1-ohm operation.
- • What enclosure does the 52L7XS122 need?
The recommended ported enclosure volume is 3 cubic feet. A properly designed enclosure and port help the subwoofer deliver deeper and more controlled bass.
- • Why does my 52L7XS122 sound weak?
Incorrect enclosure volume, port tuning, wiring, amplifier settings, or phase can reduce bass output. Check these areas before assuming the subwoofer has a problem.
- • How much space is needed for installation?
The subwoofer requires approximately an 11-1/16-inch cutout diameter and has a 10-1/8-inch top-mount depth. Measure your enclosure and vehicle space before installation.
- • Can my vehicle's electrical system handle 3,000 watts?
A high-power system can place significant demand on the vehicle's electrical system. Depending on the amplifier and vehicle, upgraded power wiring, battery capacity, or charging-system support may be needed.
- • Can I use a larger amplifier with the 52L7XS122?
A larger amplifier may be used with careful gain control, but excessive power or clipping can damage the subwoofer. For reliable performance, keep the delivered power within the recommended 3,000-watt RMS range.
- Diameter : 12 Inch
- Impedance : 2 Ohm
- Frequency Response : 20-100 Hz
- Top Mount Depth : 10-1/8 Inches
- Shallow Mount : No Inch
- Number of Voice Coils : Dual
- RMS Power Handling : 3000 Watts
Features:
- 12" Dual 2 ohm SoloXS L7XS Series Square Subwoofer
- Power Handling:
- Recommended Amplifier Power (RMS): 1500 - 3000 watts
- Double-pressed pulp Cone
- Nitrile Butadiene Rubber NBR Surround
- 3" Aluminum voice coil former
- 43.1 mm Xmax (Linear Excursion)
- 705 oz. Triple Stacked Ferrite magnet motor structure
- Custom rubber boot for oversized ferrite magnet
- Dual conex meta-aramid fiber spiders for superior strength
- Maximum cooling, cast-aluminum basket
- Single 8 AWG push terminal and dual 4 AWG terminal block
- Dual tinsel leads with considerably more strands than L7X
- Aerodynamic basket brace channels reduce back pressure
- Frequency Response: 20 - 100 Hz
- Optimal ported box volume: 3 cubic feet
- Top-mount depth: 10-1/8"
- Cutout diameter: 11-1/16"
Specifications:
- Series: SoloXS L7XS Series
- Subwoofer Size: 12"
- RMS Power Handling: 3000 watts
- Voice Coil(s): Dual
- Impedance (Per Voice Coil): 2 ohm
- Voice Coil Diameter: 3"
- Frequency Response: 20 - 100 Hz
- Xmax (millimeters): 43.1 mm
- Subwoofer Design: Square
- Main Cone Color: Black
- Woofer Composition: Double-pressed pulp
- Woofer Surround: Nitrile Butadiene Rubber NBR
- Magnet Structure: Triple Stacked
- Magnet weight: 705 oz.
- Magnet Type: Ferrite
- Subwoofer Grille: No
Recommended Enclosure Specifications:
- Recommended Enclosure Type: Ported / Vented
- Optimum Ported Box Volume: 3 cubic feet
- Top-Mount Depth (Mounting Depth): 10-1/8"
- Cutout Diameter: 11-1/16"
- Shallow Mount Installation: No
- UPC: 713034092162
- Weight: 97.1
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
