Morel  Ultimo Pro 104D New

• Diameter : 10 Inch
• Sensitivity : 85 dB
• Impedance : 4 Ohm
• Frequency Response : 15-800 Hz
• Peak Power Handling : 3000 Watts
• Shallow Mount : No Inch
• Number of Voice Coils : Dual
• RMS Power Handling : 1000 Watts

Features:

• Next-Generation Ultimo Performance – The Ultimo Pro 104D continues Morel’s legendary Ultimo heritage, delivering audiophile-grade bass reproduction with exceptional clarity, control, and ultra-low distortion.
• Massive 5.1" Hexatech™ Voice Coil – One of the largest voice coils ever engineered for car audio, the advanced aluminum Hexatech™ design improves thermal efficiency, enhances power handling, and delivers highly controlled diaphragm motion.
• External Voice Coil (EVC™) Technology – Morel’s proprietary EVC™ motor topology maximizes magnetic efficiency, improves linearity, and minimizes distortion for cleaner, more accurate low-frequency performance.
• Hybrid Carbon Fiber/Pulp Cone – A seamless one-piece cone construction combines the rigidity of carbon fiber with the natural damping characteristics of pulp, reducing resonance and ensuring precise bass reproduction.
• Pure, Musical Bass Output – Engineered for tight, controlled low frequencies, the Ultimo Pro 104D produces deep and powerful bass while maintaining natural tonal balance and musical accuracy.
• Linear Double Suspension System – Newly engineered suspension architecture improves excursion capability, responsiveness, and reciprocal precision for enhanced cone stability under demanding conditions.
• Titanium Voice Coil Former – Lightweight and highly rigid titanium former technology improves heat transfer, reduces eddy currents, lowers distortion, and enhances transient response speed.
• High Excursion, Low Distortion Design – Optimized for long linear travel, the Ultimo Pro maintains precision and control at high output levels without sacrificing sound quality.
• Integrated Motor Cooling System – Advanced cooling architecture improves thermal management, ensuring reliable high-output performance and long-term durability.
• UniFlow™ Cast Alloy Chassis – Aerodynamically optimized basket design enhances airflow, minimizes mechanical vibration, and eliminates unwanted acoustic interference.
• Versatile Enclosure Compatibility – Designed for outstanding performance in both sealed and bass reflex enclosures, offering flexibility for a wide range of premium system designs.
• Precision Engineering for Audiophiles – Combining innovative materials, advanced motor technology, and meticulous craftsmanship, the Ultimo Pro 104D delivers exceptional detail, depth, and bass realism.
• Benchmark in High-End Car Audio – With cutting-edge engineering, superior dynamics, and uncompromising musicality, the Ultimo Pro 104D sets a new benchmark for premium subwoofer performance.

Specifications:

• Nominal configuration: Dual 4 Ohm 10″ subwoofer
• Continuous power handling: 1000 Watts
• Maximum power handling: 3000 Watts
• Voice coil diameter: 130 mm
• Frequency response: 15 Hz – 800 Hz
• Sensitivity: 85 dB
• DC resistance (Re): 3.9 Ohms
• Resonant frequency (Fs): 28 Hz
• Xmax: ±12.5 mm
• Compliance (Vas): 103 l
• Total Q (Qts): 0.46
• Mechanical Q (Qms): 6.53
• Electrical Q (Qes): 0.5

• UPC:
• Weight: 14.33
