Kicker  46CSC654-Bundle8 New

46CSC654 CS Series 6.5" 300W Peak Power Handling 4 Ohms, 2-Way Shallow Mount Coaxial Car Speakers (Pair) + 46CSC6934 CS Series 6"x9" 450W Peak Power Handling at 4 Ohms, 3-Way Triaxial Car Speakers (pair) + 46CXA3604t CX Series 4-channel 90W RMS x 4 at 2 Ohms, Class A/B Full Range Car Amplifier

Item #99976

Condition:   Brand New

Product Highlights

  • Complete Kicker Speaker Upgrade Package
  • Includes 6.5" & 6x9" CS Series Speakers
  • Includes CX Series 4-Channel Amplifier
  • Ideal for Clear, Full-Range Sound
  • Compatible with Most Cars, Trucks, and SUVs

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping.
60 DAYS Price change protection.

$421.91

Reg. Price $699.97  Save $278.06
Add Extended Warranty
  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping.
60 DAYS Price change protection.

No Credit needed for acima logoLearn More

Kicker Authorized Dealer

Huge Saving on Other items:


Huge Saving on Other items:


Exclusive Bundle Banner for OCS

Onlinecarstereo Exclusive Bundle

This exclusive package is brought to you by Onlinecarstereo. We have put together this bundle to kickstart your vehicle to the path of excellent car audio.

Kicker 46CSC654 CS Series 6.5" 300W Peak Power Handling 4 Ohms, 2-Way Shallow Mount Coaxial Car Speakers (Pair) + Kicker 46CSC6934 CS Series 6"x9" 450W Peak Power Handling at 4 Ohms, 3-Way Triaxial Car Speakers (pair) + Kicker 46CXA3604t CX Series 4-channel 90W RMS x 4 at 2 Ohms, Class A/B Full Range Car Amplifier


Authorized Dealer Stamp

We are an authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • 46CSC654 (2) 2-way speakers
  • • 46CSC654 (2) Grilles
  • • 46CSC654 (2) 12" speaker leads, tinned & quick-slide ends
  • • 46CSC654 (4) Red plastic wire caps
  • • 46CSC654 (8) 1-1/8" Screws
  • • 46CSC654 (8) Speed clips
  • 46CSC654 Owner's Manual
  • • 46CSC6934 (2) 6"x9" CS Series 3-way speakers
  • • 46CSC6934 (2) Grilles
  • • 46CSC6934 (2) 12" speaker wires with tinned and quick-slide ends
  • • 46CSC6934 (4) Red plastic wire caps
  • • 46CSC6934 (8) 1" Screws
  • 46CSC6934 Owner's Manual
  • • 46CXA3604t 4-Channel Amplifier
  • • 46CXA3604t (2) Vertical mounting brackets
  • • 46CXA3604t (4) 3/4" screws
  • • 46CXA3604t Power chart
  • • 46CXA3604t Certified Power certificate
  • 46CXA3604t Owner's Manual





Kicker 46CSC654 Full Range Car Speakers Grille
2-Way Car Speaker

Are you getting tired of listening to your vehicle's stock speakers? The Kicker 46CSC654 is a two-way car speaker made to fit in your vehicle quickly and give you the high-quality audio you are looking for, making it an excellent choice for upgrading your car’s audio system and taking it to the next level.

Comes with Polypropylene Cone and Foam Surround

The Kicker 46CSC654 speaker comes with a polypropylene cone and a foam surround to give you an accurate mid and low-frequency performance with minimal distortion while giving you the toughness needed to withstand the rigors of constant use at high volume levels.

Kicker 46CSC654 Full Range Car Speakers Front View
Kicker 46CSC654 Full Range Car Speakers Left Angle View
Dome Tweeter

The Kicker 46CSC654 comes with a 0.5-inch polyetherimide balanced dome tweeter to give you crystal clear and bright highs with a minimal breakup at high volume levels. With its neodymium magnets, it won't have any problem going loud. It also has a zero-protrusion design, so it won't have any problem with its factory grille.

Power Handling

The Kicker 46CSC654 can deliver a continuous power output of 100 Watts at 4 ohms per pair and can reach up to 300 Watts of peak power. It has a frequency response of 40 Hz up to 20 kHz and a sensitivity rate of 90 dB, which means that it can produce an extensive full-range frequency performance while being able to go loud with minimal distortion.

 Kicker 46CSC654 Full Range Car Speakers Rear view
Polypropylene Cone and a Polyester Foam Surround

Renowned for its stylish speaker and subwoofer designs, Kicker has introduced a new 3-way coaxial speaker, the Kicker 46CSC6934, designed to fit most vehicles due to its unique shape and shallow depth. It features a durable polypropylene cone and polyester foam surround for precise sound and long-lasting performance at high volumes.

Accurate High-frequency Reproduction

It features a 2-inch midrange driver for low and mid-range tones, along with a 1/2-inch tweeter for highs. The tweeter has a precise balanced dome design using polyetherimide and neodymium magnets, ensuring clear high-frequency reproduction even at high volumes. Additionally, it has a steel basket with effective thermal venting and Kicker's Extended Voice Coil technology, delivering powerful and clean bass to enhance its overall sound performance.

Able to Produce a Wide Range of Frequencies With Clarity

The Kicker 46CSC6934 has a power output of 150 Watts RMS and can reach up to 450 Watts of peak power. Its frequency response of 30 Hz up to 20 kHz and a sensitivity rate of 92 dB only means that this 3-way speaker does not have any problem going at high volume levels without distorting, while it is also able to produce a wide range of frequencies with clarity.



Kicker 46CXA3604t 4-Channel Amplifier Top View
High-quality Full-range Sound

The 4-ohm impedance of the subwoofer offers installation flexibility and works with different amplifiers. It uses Kicker's UniPlate™ technology to manage heat and maximize power handling. With a single voice coil, you can customize your setup easily, and its frequency response (30Hz to 500Hz) guarantees impactful bass at different frequencies.

Produce a High-quality Full-range Sound

This Kicker product comes with a Class A/B amplifier, giving it enormous power and the ability to produce a high-quality full-range sound. With its compact size and horizontal and vertical mounting options, you won't have a hard time installing it on your car. The amplifier also has an excellent thermal management system, with its heat sinks keeping the amplifier at a minimum operating temperature level.



Kicker 46CXA3604t 4-Channel Amplifier Right Angle View
Kicker 46CXA3604t 4-Channel Amplifier Mounting Position
Seamlessly Producing a Full Range of Frequencies

The amplifier has a power output of 65 Watts RMS per channel at 4 ohms and 90 Watts RMS per channel at 2 ohms and can produce 180 Watts when bridged. It has a frequency response of 10 Hz up to 20 kHz and a signal-to-noise ratio of 95 dB, which only means it can go loud easily without distorting while seamlessly producing a full range of frequencies.

High/low Pass Filter

The Kicker 46CXA3604t also comes with other excellent features like a variable high/low pass filter and a bass boost to shape the sound quality you want to listen to. It is also equipped with Kicker's Fail-Safe Integration Technology Plus, enabling the amplifier to protect itself from interference and noise produced by other components in a car's audio system.



Kicker 46CXA3604t 4-Channel Amplifier Connection Panel

SPECIFICATIONS



FEATURES


46CSC654 CS Series 6.5" 300W Peak Power Handling 4 Ohms, 2-Way Shallow Mount Coaxial Car Speakers (Pair)



Features:

  • Factory Upgrade: A direct-fit replacement for factory speakers that enhances sound clarity and output.
  • Zero-Protrusion Tweeters: PEI-balanced dome tweeters ensure compatibility with nearly any factory depth.
  • EVC Technology: Extended Voice Coil design provides improved linear excursion and sonic accuracy.
  • UV-Treated Surround: Durable poly-foam surround resists damage from heat and sunlight for long-lasting reliability.
  • Heavy-Duty Motor: Large woofer magnet and reinforced motor structure deliver ultra-clean, impactful bass.
  • High-Frequency Clarity: PEI tweeter material with neodymium magnets produces detailed, high-end response.
  • Protective Grilles: Included steel mesh grilles provide added protection for the speaker components.
  • Universal Fit: Designed to fit nearly every vehicle application with minimal modification.



Specifications:

  • Speaker Design: 2-Way Coaxial
  • Woofer Size: 6-1/2" (160 mm)
  • Tweeter Size: 1/2" (13 mm)
  • DC Resistance: 3.3 Ohms
  • Peak Power Handling: 300 Watts (ANSI/CTA-2031-A)
  • Recommended RMS Power: 100 Watts
  • Sensitivity (SPL): 90 dB @ 1W, 1m
  • Frequency Response: 40 Hz – 20 kHz
  • Mounting Hole Diameter: 4-13/16" (123 mm)
  • Top Mount Depth: 1-11/16" (43 mm)
  • Bottom Mount Depth: 2-1/16" (52 mm)
  • Tweeter Protrusion: 0mm
  • Grilles Included: Yes
  • Tweeter Magnet Material: Neodymium
  • Tweeter Dome Material: PEI (Polyether Imide)
  • Tweeter Design: Balanced Dome
  • Woofer Cone Material: Polypropylene
  • Woofer Surround Material: Polyester Foam



46CSC6934 CS Series 6"x9" 450W Peak Power Handling at 4 Ohms, 3-Way Triaxial Car Speakers (pair)



Features:

  • Fits nearly every car made
  • Zero-protrusion tweeters to fit nearly any factory depth
  • Woofer EVC™ (Extended Voice Coil) tech assists with precise linear excursion
  • UV-treated poly-foam surround resists heat or direct sunlight
  • Large woofer magnet in a heavy-duty motor for ultra-clean bass
  • Integrated 2-inch (50mm) midrange drivers gives detailed attention to mid frequencies
  • PEI-tweeter construction provides superb clarity
  • Neodymium tweeter magnets allow for increased volume in high frequencies
  • Steel mesh grilles included for speaker protection



Specifications:

  • Speaker Design: 3-Way
  • Woofer Size | in [mm]: 6x9 [160x230]
  • Tweeter Size | in [mm]: 2 [50]
  • DC Resistance | ohm: 3.5
  • Peak Power | Watts: 450
  • Continuous Power | Watts, RMS: 150
  • Sensitivity [SPLo] | dB @ 1W, 1m: 92
  • Effective Frequency Range | Hz: 30-20k
  • Mounting Hole Diameter | in [mm]: 5 5/8 x 8 7/16 [143x215]
  • Top Mount Depth | in [mm]: 7/16 [12]
  • Bottom Mount Depth | in [mm]: 3 3/16 [81]
  • Tweeter Protrusion | in [mm]: 1/16 [1]
  • Grilles: Yes
  • Tweeter Magnet Material: Electric Crystal Motor
  • Tweeter Magnet Material: Neodymium
  • Tweeter Dome Material: PEI
  • Tweeter Design: Balanced dome
  • Woofer Cone Material: Polypropylene
  • Woofer Surround Material: Polyester foam



46CXA3604t CX Series 4-channel 90W RMS x 4 at 2 Ohms, Class A/B Full Range Car Amplifier



Features:

  • Clean & Powerful Full-Range Performance: Class A/B full-range channels deliver smooth, accurate, high-quality audio.
  • Noise-Free Start-Up: Three-second turn-on/off delay eliminates unwanted pops and interference.
  • Precision Audio Tuning: Variable 12dB crossovers let you fine-tune your sound exactly how you want it.
  • Boost Your Bass: KickEQ™ 6dB variable bass boost adds extra low-end punch when you need it.
  • Ultimate Radio Compatibility: FIT+™ technology ensures seamless integration with nearly any radio system.
  • Handles High Input Signals: Accepts up to 40-volt input for maximum flexibility and system matching.
  • Easy, Compact Installation: Small footprint makes mounting simple, even in tight spaces.
  • Stylish Vertical Mounting Option: Includes hardware for a unique vertical installation look.
  • Remote Bass Ready: Fully compatible with the CXARC Remote Bass Control for on-the-fly adjustments.




Specifications:

  • RMS Power Output: 65 W x 4
  • Peak Power Output: 180 W x 4
  • Power at 2 Ohms: 90 W x 4
  • Power at 1 Ohm: N/A
  • Bridged Power: 180 W x 2
  • Minimum Impedance Bridged: 4 Ω
  • Minimum Impedance Unbridged: 2 Ω
  • Frequency Response: 10–20,000 Hz
  • THD at Rated RMS Power: 1%
  • Signal-to-Noise Ratio: 75 dB
  • Input Voltage: 14.4 V
  • Amplifier Class: AB
  • Built-in DSP: No
  • Remote Control: Optional
  • Low-Pass Crossover: 50–200 Hz, 12 dB/octave
  • High-Pass Crossover: 50–200 Hz, 12 dB/octave
  • Bass Boost: 0–6 dB @ 40 Hz
  • Fan Cooled: No
  • Fuse Rating: 40 A
  • Speaker Level Inputs: Yes
  • Preamp Outputs: No
  • Dimensions (W x H x D): 12-7/8 × 2-3/8 × 6-3/4 inches
  • UPC:
  • Weight: 25
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
