A Dual voice coil subwoofer provides more wiring configuration possibilities. If you add additional subwoofers, wiring configurations can be easily matched to optimize the amps power output. Power handling is also increased. Dual voice coil subwoofers are ideal for medium to high-power applications.
This subwoofer will thrive in well in a ported enclosure. A ported enclosure is easy to spot because of the vent (port). This enclosure will be bigger than a sealed enclosure and it also has greater SPL output, resulting in chest-thumping bass with authority. For proper tuning and optimum subwoofer performance in a ported enclosure, we recommend using an amplifier with a subsonic filter.
This subwoofer will operate well in a sealed enclosure that will yield solid, tight bass. You can either purchase a pre-fabricated enclosure or build one to suit your installation needs. Sealed enclosures are relatively easy to build and are the smallest enclosure the subwoofer is designed for.
Boss Audio audio electronics adhere to the highest standard of quality control and apply proprietary technology to ensure perfect sound in every model you are purchasing. This is the reason why throughout the years, Boss Audio has maintained it's place in the audiio industry as one of the best brands out there.
Onlinecarstereo has been along time authorized retailer of Boss Audio products. We source our inventory from accredited dealers that provide us with official warraties on every product. You can be sure that you are getting authentic and original items from the manufacturer's warehouse. We strive to achieve the highest customer satisfaction on every purchase and always make sure to deliver your items on-time.
Diameter : 10 Inch
Sensitivity : 85 dB
Depth : 4.825 Inch
Impedance : 4 Ohm
Peak Power Handling : 2200 Watts
Shallow Mount : No
Number of Voice Coils : Dual
Suggested Sealed Box Volume : .75 Cubic ft.
Suggested Ported Box Volume : 1 Cubic ft.
Mounting Depth : 4.875 Inches
RMS Power Handling : 1100 Watts
1100W RMS @ 4 Ohms
2200W Max Power
Frequency Response: 2-35 Hz
Dual Voice Coil
Voice Coil Size: 2
Color Chrome Treated Poly Injection
Sealed Enclosure: Small = 1 CuFt; Large = CuFt
Ported Enclosure: Small = 0.6 CuFt; Large = 1 CuFt
Port Diameter: Small = 3 "; Large = 3 "
Port Length: Small = 12 "; Large = 8.5 "
Port Frequency: Small = 47 Hz; Large = 42 Hz
Mounting Depth: 4.875"
