Orion  CBW104S

Cobalt Series 10" 1200W Peak Power Handling 4 Ohm, Single Voice Coil Component Car Subwoofer

Item #97097

Product Highlights

  • Cobalt Series
  • 10" Component Car Subwoofer
  • 1200W Peak Power Handling
  • 4 Ohm Impedance
  • Single Voice Coil Design

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping.
60 DAYS Price change protection.
Sorry, this product is no longer available.
Checkout other products listed below

Huge Saving on Other items:



Huge Saving on Other items:


Rockford Fosgate Banner

Orion CBW104S Cobalt Series 10" 300W RMS (1200W Peak Power Handling), 4 Ohm, Single Voice Coil Component Car Subwoofer


We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • 10" 1200W Peak Power Handling, 4 Ohm, Single Voice Coil Component Car Subwoofer
  • • Owner's Manual





PrCompact Power with Deep, Dynamic Bass

Experience powerful, heart-thumping sound with the Orion CBW104S 10-inch subwoofer—compact in size yet massive in performance. Delivering 300 Watts RMS and 1200 Watts peak power, it produces clean, distortion-free bass that energizes every beat. Built with a durable reinforced paper cone and foam surround, it ensures long-lasting reliability and crisp sound clarity, all in a compact, space-saving design that fits effortlessly into any setup.

Wide Frequency Range with Cool, Reliable Performance

Feel every note with a wide 30Hz–500Hz frequency response that delivers deep lows and sharp, detailed highs for a full, dynamic sound experience. The advanced heat dissipation system keeps the subwoofer cool even during intense sessions, ensuring long-lasting reliability, while the 4-ohm impedance offers excellent amplifier compatibility for flexible, high-performance installations.

Dynamic Sound, Easy Installation, and Reliable Performance

Turn every drive into an audio adventure with the Orion CBW104S, delivering deep, heart-pounding bass and crystal-clear sound that brings your music to life. Designed for any occasion—whether cruising, competing, or commuting—it offers a single voice coil (SVC) design for simple installation and hassle-free wiring. Combined with a wide frequency range and efficient cooling system, this subwoofer ensures consistent, reliable performance with every beat.


Frequently Asked Questions (FAQ)


  • • Why Does My CBW104S Not Hit as Hard as I Expected?
    Some customer feedback indicates that the CBW104S may not deliver the level of punch expected when paired with certain amplifiers. Proper amplifier matching and enclosure design are important because the subwoofer is rated for 300W RMS rather than its 1,200W peak figure.
  • • Could the Enclosure Be Limiting the CBW104S Bass Output?
    Yes. The CBW104S is designed for both sealed and ported enclosures, so an unsuitable box volume or poorly designed port can affect its low-frequency response and overall output.
  • • Why Does My CBW104S Sound Weak at Certain Bass Frequencies?
    A noticeable drop at particular frequencies can come from the enclosure, vehicle acoustics, or crossover settings rather than the woofer itself. The CBW104S is specified for a 20–300 Hz frequency range, so system tuning plays an important role in how its bass is perceived.
  • • Is the 4-Ohm Single Voice Coil Hard to Match With an Amplifier?
    The CBW104S uses a single 4-ohm voice coil, which keeps wiring simple but gives fewer impedance options than a dual-voice-coil design. The amplifier should be selected to provide appropriate power at a 4-ohm load.
  • • Why Does My CBW104S Have Less Bass After Changing the Box?
    Changing from one enclosure design to another can significantly alter the woofer's response. Orion specifically describes the CBW104S as suitable for both sealed and ported installations, but the enclosure type and design will affect how much low-end output you hear.
  • • Can the CBW104S Handle Daily Bass Without the Cone Becoming Noisy?
    The woofer uses a UV-coated paper/fiber blend cone, foam surround, and a 2-inch copper-clad aluminum voice coil on a Kapton former. These components are intended for everyday use and heat management, although excessive power or mechanical over-excursion can still cause damage.
  • • Why Does My CBW104S Sound Good at Moderate Volume but Lose Impact When Pushed?
    Running beyond the woofer's 300W RMS thermal rating can reduce clean output or introduce distortion, particularly if the amplifier is clipping. The 1,200W specification is peak handling, so it should not be treated as the continuous power target.
  • • Does the CBW104S Require a Large Amount of Installation Space?
    Not necessarily. Its mounting depth is approximately 4.57 inches, making it relatively suitable for compact installations compared with deeper subwoofers. However, the enclosure still needs enough internal volume for the selected design.
  • • Why Is My CBW104S Bass Punchy but Not Extremely Loud?
    The CBW104S is positioned by Orion as a compact daily-use subwoofer rather than an extreme SPL driver. Its 10-inch size, 300W RMS rating, and 85 dB sensitivity are better suited to adding controlled low-end output than replacing a high-power competition subwoofer.
  • • What Should I Check If the CBW104S Sounds Different After Installation?
    Start by checking speaker polarity, amplifier gain, crossover settings, enclosure construction, and wiring connections. Because the CBW104S is a single-voice-coil 4-ohm design, incorrect wiring or tuning can change its output even when the woofer itself is functioning normally.

SPECIFICATIONS


  • Diameter : 10 Inch
  • Sensitivity : 85 dB
  • Impedance : 4 Ohm
  • Frequency Response : 20-300 Hz
  • Peak Power Handling : 1200 Watts
  • Number of Voice Coils : Single
  • Mounting Depth : 4.57 Inches
  • RMS Power Handling : 300 Watts

FEATURES


Features:

  • Powerful 10-Inch Subwoofer: Compact yet mighty, the Orion CBW104S delivers deep, punchy bass that adds excitement and impact to your music.
  • Single Voice Coil (SVC) Design: Simplifies installation and wiring, making it easy for both beginners and experienced car audio enthusiasts to set up.
  • High Power Output: With 300 Watts RMS and 1200 Watts peak power, this subwoofer delivers powerful, distortion-free bass that brings your music to life.
  • Durable Reinforced Paper Cone with Foam Surround: Ensures long-lasting performance and clear, accurate sound even at high volumes.
  • Compact and Versatile Size: Perfect for smaller spaces, offering flexible installation without sacrificing performance or bass output.
  • Wide Frequency Response (30Hz – 500Hz): Captures every detail from the lowest rumbles to the sharpest beats for a rich and dynamic sound experience.
  • Advanced Heat Dissipation System: Keeps the subwoofer cool during long sessions or high-output performance, ensuring consistent reliability.
  • 4-Ohm Impedance: Provides excellent amplifier compatibility, allowing flexible setup options for a wide range of car audio systems.
  • Dynamic and Exciting Audio Performance: Delivers heart-pounding bass and crystal-clear sound, transforming every drive into a powerful audio adventure.
  • Ideal for Any Occasion: Whether cruising, competing, or commuting, the Orion CBW104S makes every journey sound better and feel more alive.



Specification:

  • Subwoofer Size: 10 (Inches)
  • Voice Coil Configuration: Single 4-ohm
  • Power Handling (Peak): 1200 Watts
  • Power Handling (RMS): 300 Watts
  • Sensitivity: 85 dB
  • Frequency Response: 2 0 Hz - 300 Hz
  • Voice Coil Diameter: 2 (Inches)
  • Cone Material: UV Coated Paper / Fiber Blend Cone
  • Surround Material: Foam Surround
  • Magnet Information: 40 Oz Ferrite
  • Dimensions (L x W x H): 12" x 6.5" x 12" (304.8 x 165.1 x 304.8mm)
  • Mounting Depth: 116mm / 4.57 (Inches)
  • Overall Depth: 135mm / 5.31
  • Cutout Diameter: 246mm / 9.69 (Inches)
  • Overall Diameter: 257mm / 10.12 (Inches)
  • UPC:
  • Weight: 7.1
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
