Crunch CS525CX
alternate product image 1alternate product image 2alternate product image 3
Item# 37011 / Condition:  Brand New

Crunch CS525CX

CS525CX
5-1/4" 2-way 250 Watts V-Drive Series Full Range Automotive Speakers
$31.99

FREE Shipping in US 48!

Save 9% | Reg. Price $35.19 In Stock
Add Extended Warranty

Crunch is considered a common name among car audio gearheads. Their products are manufactured to high end specifications to provide excellent sound experience. Onlinecarstereo has been a long time partner of Crunch so you can be sure you get authentic products with warranties stright from the warehouse.

Specifications

  • RMS POWER HANDLING(CEA426B)
    125 watts
  • PEAK POWER HANDLING (CEA426B)
    250 watts
  • SPEAKER IMPEDANCE
    4 ?
  • FREQUENCY RESPONSE +/- 10DB
  • FREQUENCY RESPONSE +/- 3DB
    60Hz-20kHz
  • SENSITIVITY (1 WATT/1 METER)
    88dB
  • CROSSOVER POINT
    4K Hz
  • CROSSOVER SLOPE
    12dB
  • MOUNTING DIAMETER/CUT OUT
    4.48
  • OUTSIDE DIAMETER
    6.26
  • MOUNTING DEPTH/CHASSIS DEPTH
    2
  • PRODUCT DIMENSIONS
    12.19 x 6.88 x 3.88 in
    30.9 x 17.4 x 9.8 cm
  • PRODUCT WEIGHT
    3.1 lbs (1.4 kg)

Features & Benefits

  • TWEETER DOME MATERIAL: Neo-Mylar Soft Dome Tweeter Impact Resistant Tweeter Elements
  • SURROUND: UV Resistant Rubber Surround
    Moisture Resistant Rubber Surround with high Mid-Bass Impact
  • CONE: Silver Alpha-Cellulose Poly Cones
    Produces musical midrange and bass tones while remaining light weight
  • SURROUND / CONE COUPLING: High Temperature Adhesive
    The cone/surround connection utilizes a high temp adhesive which assure the cone and surround do not separate in high power uses or extremes of weather
  • GASKET: Textured ABS
    Assures a ridged linear seal to the mounting surface
  • TINSEL LEADS: Braided
    Highly conductive while remain flexible during high power applications
  • VOICE COIL: Pure Copper
    Creates strong magnetic field with a very thin extrusion
  • VOICE COIL FORMER: Kapton
    Lightweight and efficiently dissipates heat
  • SPIDER: Epoxy infused Natural Fiber
    Natural fiber allows flexibility while the epoxy which gives strength during the manufacturing process.
  • COOLING SYSTEM: Over-Coil
    Air is exchanged over the voice coil through the spider
  • CROSSOVER TYPE: Passive Butterworth
    Smooth transition of frequencies from midrange/midbass to the tweeter element
  • CROSSOVER SPECIAL: 6dB Internal
    Integrated into the design to assure smooth midrange to tweeter frequency transitions
  • FRAME: Anti-Resonant Stamped Steel Basket
    Very strong with minimal harmonics or distortions from flex or ringing
  • MOTOR: Ferrite Magnet
    Creates a strong magnetic field while remaining small enough to fit nearly every application
  • CONNECTORS: Spade
    Use spade connectors or solder direct for the best connection
  • GRILLS: Yes
    Protects the speaker from accidental damage. Not used if speaker is mounted behind vehicle panel
  • TWEETER MATERIAL: Neo-Mylar Soft Dome
    Great sound quality and increased reliability
  • TWEETER SIZE: 1 inch
    Clear highs while handling plenty of power without sound harsh
  • TWEETER SURROUND MATERIAL: Kapton
    Lightweight and efficiently dissipates heat
  • Car speakers are usually sold as a pair unless otherwise noted.
  • UPC: 806576222125
  • Weight: 3
  • Authorized Internet Dealer
*Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.

Do you own this product?  Write a review

   TJD From Safford, AZ
I got 4 of these for my wife's chevy suburban to replace the factory speakers. They're running off of a 4ch mtx thunder amp and they're crystal clear and loud. They were very inexpensive and I was truly surprised at the sound quality, it's on par with some of the component sets that I have owned before.
