JL Audio  15W0v3-4

W0v3 Series 15" 800W Peak Power Handling 4 Ohm, Single Voice Coil Component Car Subwoofer

Item #38406

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Sorry, this product is no longer available.
Checkout other products listed below

Huge Saving on Other items:



Huge Saving on Other items:


JL Audio Banner for Onlinecarstereo

JL Audio 15W0v3-4 W0v3 Series 15" 500W RMS Single 4 Ohm Voice Coil Subwoofer


We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • •15" Single voice coil 4-ohm subwoofer
  • •Owner's manual
Polypropylene Cone and a Foam Surround

The biggest and loudest of the JL Audio W0v3 Subwoofer Series, the JL Audio 15W0v3-4 is a 15-inch car subwoofer that comes with a lot of power and is built with the latest and best technologies that JL Audio has to offer.

The subwoofer has a polypropylene cone and a foam surround, which enables it to produce an accurate and clean bass with reduced distortion, and gives added protection from the effects of long usage periods at maximum volume levels. The lead wire is also woven into the subwoofer's spider for additional strength.

Low-frequency Performance With Minimal Distortion

It uses a DMA-optimized motor design, allowing the subwoofer to produce a clean and accurate low-frequency performance with minimal distortion. It also employs JL Audio's elevated frame cooling design, which allows the air to flow directly to the voice coil, resulting in a highly efficient thermal system, allowing the subwoofer to withstand the rigors from long periods of usage at high volume levels.

The JL Audio 15W0v3-4 has a power output of 500 Watts RMS at 4 ohms. Its frequency response of 20 up to 200 Hz and its sensitivity rate of 88.2 dB are excellent indicators that this subwoofer can really go loud while producing an extensive low-range performance with minimal distortion only.

  • Diameter : 15 Inch
  • Sensitivity : 88.2 dB
  • Impedance : 4 Ohm
  • Frequency Response : 20-200 Hz
  • Peak Power Handling : 800 Watts
  • Shallow Mount : No Inch
  • Number of Voice Coils : Single
  • Suggested Sealed Box Volume : 1.875 Cubic ft.
  • Suggested Ported Box Volume : 2.75 Cubic ft.
  • Mounting Depth : 7.15 Inches
  • RMS Power Handling : 500 Watts

Features:

  • 15" 4-ohm subwoofer
  • polypropylene cone with foam surround
  • power range: 150-500 watts RMS
  • peak power handling: 800 watts
  • frequency response: 20-200 Hz
  • sensitivity: 88.2 dB
  • top-mount depth: 7-1/8"
  • sealed box volume: 1.875 cubic feet
  • ported box volume: 2.75 cubic feet



Specifications:

  • Size: 15 -inch
  • Impedance (Ohms): 4
  • Cone Material: Polypropylene
  • Surround Material: Foam
  • Port diameter (inches): 4
  • Port length (inches): 16.85
  • Free-Air: No
  • Dual Voice Coil: No
  • Sensitivity: 88.2 dB at 1 watt
  • Frequency Response: 20 - 200 Hz
  • Max RMS Power Handling: 500
  • Peak Power Handling (Watts): 800
  • Top Mount Depth (inches): 7 1/8
  • Bottom Mount Depth (inches): N/A
  • Cutout Diameter or Length (inches): 13 3/4
  • Vas (liters): 144.6
  • Fs (Hz): 24.43
  • Qts: 0.482
  • Xmax (millimeters): 12.7
  • UPC: 699440921671
  • Weight: 20.01
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.

Do you own this product?

Write a review!
  • Slam good sound wish I had the amp to go with

    Jason Ditmer
    6/18/2021

  • Quality sub from JL Audio. Great deep lows. Not sure if it can really go down to 20 Hz as advertised but the bass is still pretty great for my liking.

    Jered
    3/8/2024

  • Just recently bought a pair of Kicker speakers but I felt that the bass was a little bit lacking. Which is why I decided to buy this JL Audio sub and since then my bass needs have been fulfilled. Really a great addition to my setup.

    Mason
    4/25/2024
