JL Audio  RD900/5

RD Series 5-Channel 100W RMS x 4 at 2-Ohms + 5th Channel 500W RMS x 1 at 2-Ohms, Class-D Car Amplifier with NextD™ switching amp technology

Item #45872

Condition:   Brand New

Product Highlights

  • RD Series
  • 5-Channel Amplifier
  • Class-D Power
  • NextD Technology
  • High Output

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping.
60 DAYS Price change protection.

$679.99

Reg. Price $799.99  Save $120.00
In Stock
In Stock

Limited Stocks left!
Add Extended Warranty
Getting Delivery Estimate...
  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping.
60 DAYS Price change protection.

No Credit needed for acima logoLearn More

JL Audio Authorized Dealer

JL Audio Banner for Onlinecarstereo

JL Audio RD900/5 - RD Series 5-Channel 100W RMS x 4 at 2-Ohms + 5th Channel 500W RMS x 1 at 2-Ohms, Class-D Car Amplifier with NextD™ switching amp technology


We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • RD Series 5-Channel Class-D Full Range Car Amplifier
  • • 2.5mm Allen wrench
  • • Self-adhesive JL Audio badge
  • • Safety & Product information
  • • Warranty information
  • Owner's Manual




Why Choose JL Audio RD900/5 5-Channel Amplifier?






JL Audio RD900/5 5-Channel Amplifier Top View
Experience High-Performance Sound with NexD™ Switching Technology

Unlock the full potential of your audio system with the RD900/5, featuring cutting-edge NexD™ Switching Technology for ultra-efficient, high-performance sound. Delivering 70W x 4 at 4Ω for your satellite speakers and 500W x 1 at 2Ω for deep, powerful bass, this compact amplifier ensures crystal-clear audio with minimal distortion. Plus, with bridgeable channels delivering 200W of full-range audio, it offers the versatility of a 3-channel powerhouse, all while maintaining the superior sound quality that NexD™ technology is known for.

Achieve Precision Sound Control

Enjoy precise control with the RD900/5's convenient top-mounted studio-grade signal processing, hidden beneath a removable protective cover. Fine-tune your sound with 12 dB/octave filters, featuring high-pass options for the main channels and a dedicated low-pass filter for the subwoofer, while variable frequency selection (50-500 Hz) ensures the perfect sound balance. With dual-range differential-balanced inputs that accept a wide range of input voltage levels, this amplifier delivers professional-grade performance and customization.



JL Audio RD900/5 5-Channel Amplifier Side Connection and Interface Panel Full Frontal View
JL Audio RD900/5 5-Channel Amplifier Outer Right Angled View with Control Cover Closed
Automatic Turn-On, LED Indicators, and Remote Compatibility for Effortless Audio Management

The RD900/5 amplifier offers ultimate convenience with automatic turn-on capability via signal or DC-offset sensing, and LED clipping indicators that make input sensitivity adjustments quick and easy without any special tools. Built to last with a sleek black powder-coated finish, it also features a dual-color LED light strip to indicate amplifier status at a glance. For added control, it’s compatible with the RBC-1 remote (sold separately), allowing you to adjust subwoofer output right from the driver’s seat.




Frequently Asked Questions (FAQ)


  • • Why is the subwoofer output very weak or lacking bass thump?
    This occurs when the gain is set using a 0dB test tone instead of a -10dB (50Hz) tone. A 0dB tone limits the real-world output; using a -10dB tone allows you to safely dial in the full 500W RMS capability.
  • • Why did my sub channel drop to 1/3 volume after a battery disconnect?
    A sudden battery disconnect often resets the head unit's factory menus, dropping the dedicated subwoofer output level back to zero or resetting the crossover points. Recheck your radio's internal audio settings.
  • • Should I reverse the subwoofer polarity due to the 12dB crossover slope?
    The 12dB/octave slope introduces a 180-degree phase shift at the cutoff point. Swapping the sub's positive and negative leads often fixes phase cancellation with the door speakers, yielding a noticeably punchier low end.
  • • Can I run a 1-ohm subwoofer load on the dedicated sub channel?
    No. The sub channel is strictly rated for a 2-ohm minimum load (500W RMS). Dropping below 2 ohms will overdraw current, cause excessive heat, and force the amplifier straight into protect mode.
  • • What size power and ground wire does the RD900/5 require?
    The amplifier requires a minimum of a true 4 AWG pure oxygen-free copper (OFC) wire kit. Avoid cheap copper-clad aluminum (CCA) wire, which drops voltage and starves the amplifier of current under heavy loads.
  • • Why does the top-mounted status light strip turn red?
    A solid red light strip indicates a fault protection event. This is usually caused by low voltage drops, an improper low-impedance speaker load, or stray copper strands on your speaker terminal wires touching the metal chassis.
  • • How do I use the built-in LED clipping indicators to set gains?
    Set your head unit to 3/4 volume, then slowly turn the amp gain up until the onboard LED flashes red. Back the dial off slightly until the light stays off to ensure a perfectly clean, distortion-free output.
  • • Do I need to buy Y-adapters to input a 2-channel signal into all 5 channels?
    No. The RD900/5 has an "Input Mode" toggle switch. Setting this switch to "2 Ch." automatically splits a single pair of front RCAs to drive all four door speaker channels and the subwoofer output internally.

SPECIFICATIONS


  • Maximum Power : 1800 Watts
  • Number of Channels : 5
  • Frequency Response : 12-22000 Hz
  • Amplifier Class : D
  • Fuse Rating : 80 A
  • Promo : Yes

FEATURES


Features:

  • High-Power Output: 70W x 4 @ 4Ω + 500W x 1 @ 2Ω (14.4V)
  • All-in-One System Solution: Designed to power a complete audio system with subwoofer and four satellites
  • NexD™ Switching Technology: Efficiently generates high-performance sound in a compact chassis
  • Bridgeable Main Channels: Each pair produces 200W of full-range audio (into 4Ω), creating an ultra-powerful 3-channel amplifier
  • Convenient Top-Mounted Controls: Studio-grade signal processing features hidden beneath a removable protective cover
  • 12 dB/Octave Filters: High-pass filter for main channels and dedicated low-pass filter for the subwoofer channel
  • Variable Frequency Selection: Continuously adjustable from 50-500 Hz for precise filtering
  • Dual-Range Differential-Balanced Inputs: Accepts a wide range of input voltage levels
  • Automatic Turn-On Capability: Signal sensing or DC-offset sensing for maximum versatility
  • LED Clipping Indicators: Easily set input sensitivity with no special equipment needed
  • Durable Construction: Black powder-coated finish for longevity and style
  • Dual-Color LED Light Strip: Top-mounted to indicate overall amplifier status and condition
  • Remote Level Control Compatible: RBC-1 remote (sold separately) allows for convenient subwoofer output control from the driver's seat



Specifications:

  • RMS Power Output (Watts x Channels): 70 x 4 / 500 x 1
  • Peak Power Output (Watts x Channels): N/A
  • Power at 2 Ohms (Watts x Channels): 100 x 4
  • Bridged Power (Watts x Channels): 200 x 2
  • Minimum Impedance Bridged: 4
  • Minimum Impedance Unbridged: 2
  • Minimum Impedance: 2
  • Best Frequency Response: 12-22k Hz
  • THD at Rated RMS Power: 1%
  • Signal to Noise Ratio: 84 dB
  • Input Voltage: 14.4v
  • Amplifier Class: D
  • Low-Pass Crossover Frequency: 50-500 Hz
  • Low-Pass Slope (dB/octave): 12 dB/octave
  • High-Pass Crossover Frequency: 50-500 Hz
  • High-Pass Slope (dB/octave): 12 dB/octave
  • Bass Boost: No
  • Fan Cooled: No
  • Fuse Rating: 80
  • Speaker Level Inputs: Yes
  • Preamp Outputs: No
  • Width (inches): 14-11/16
  • Height (inches): 2-3/16
  • Depth (inches): 7
  • UPC: 699440986427
  • Weight: 10
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.
