Power Acoustik  BAMF-102

BAMF Series 10" 3200W Peak Power Handling 2 Ohm, Dual Voice Coil Component Car Subwoofer

Item #47944

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Sorry, this product is no longer available.
Checkout other products listed below

Huge Saving on Other items:


Available alternative products:


Huge Saving on Other items:


Brand Banner

Power Acoustik BAMF-102 BAMF Series 10" 3200W Peak Power Handling 2 Ohm, Dual Voice Coil Component Car Subwoofer


We are a Power Acoustik authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • 10" 3200W 2 Ohms, Dual Voice Coil Component Car Subwoofer
  • • Owner's Manual





Elevate Your Audio Experience

Experience unmatched bass performance with our top-of-the-line subwoofer, capable of handling a max power of 3,200 Watts and RMS power of 1,600 Watts. With an impressive efficiency rating of 83.80 (1w/1m), paired with a 3" dual 2Ω voice coil configuration and a substantial 272 oz motor volume, this subwoofer delivers exceptional power and precision. Its shallow mounting depth of 6.00" makes installation a breeze, while our recommended sealed enclosure of 0.75 ft³ or ported enclosure of 1.25 ft³ ensures optimal sound quality. Elevate your audio experience with our premium subwoofer today!

High-Temperature Tolerance

Upgrade your sound system with our advanced subwoofer, featuring an overcompensating motor structure for enhanced magnetic strength. Enjoy improved low-frequency dynamics with a 12mm T-Yoke & Top Plate, while a vented T-Yoke & Frame reduces heat build-up for sustained performance. Crafted with a non-magnetic, non-resonate die-cast aluminum frame for optimal sound quality. Plus, experience increased power handling with a 3” 4-Layer Voice Coil and Direct Connect Wire. Backed by high-temperature tolerance adhesives, our subwoofer ensures reliability even under intense conditions.

Prolonged Performance

Elevate your sound with our meticulously crafted subwoofer. Featuring a durable non-transfer spruce pulp cone, stitched and glued joints, extended excursion foam surround, dual poly-cotton suspension, stitched voice coil leads, and included gasket/trim ring for easy installation.


SPECIFICATIONS


  • Diameter : 10 Inch
  • Sensitivity : 83.8 dB
  • Impedance : 2 Ohm
  • Peak Power Handling : 3200 Watts
  • Shallow Mount : No Inch
  • Number of Voice Coils : Dual
  • Suggested Sealed Box Volume : 0.75 Cubic ft.
  • Suggested Ported Box Volume : 1.25 Cubic ft.
  • Mounting Depth : 6 Inches
  • RMS Power Handling : 1600 Watts

FEATURES


Features:

  • Overcompensating Motor Structure for Increased Magnetic Strength
  • 12mm T-Yoke & Top Plate Improve Low-Frequency Dynamics
  • Vented T-Yoke & Frame Reduces Voice Coil Heat Build-up
  • Non-Magnetic Non-Resonate Die-Cast Aluminum Frame
  • 3” 4-Layer Voice Coil w/ Direct Connect Wire Increases Power Handling
  • High-Temperature Tolerance Adhesives Resist Thermal Failure
  • Non-Transfer Spruce Pulp Cone w/ UV & Chemical Protection
  • Stitched and Glued Surround/Cone Joints for Strongest Bonding
  • Extended Excursion Polyether Foam Surround w/ UV Protection
  • Dual Poly-Cotton Suspension Dampen Violent Accelerations
  • Stitched Voice Coil Leads Prevent Potential Damage
  • 1-pc Gasket/Trim Ring w/ Concealed Mounting Holes Included



Specifications:

  • Max Power Handling: 3,200 Watts
  • RMS Power Handling: 1,600 Watts
  • Efficiency (1w/1m): 83.80
  • Voice Coil Configuration: 3" Dual 2Ω
  • Motor Volume: 272 oz
  • Mounting Depth: 6.00"
  • Optimum Sealed Enclosure ft³: 0.75
  • Optimum Ported Enclosure ft³: 1.25



Recommended Enclosure Specifications:

  • Recommended Enclosure Type: Ported / Vented, Sealed
  • Minimum Sealed Box Volume: 0.5 cubic feet
  • Optimum Sealed Box Volume: 0.75 cubic feet
  • Maximum Sealed Box Volume: 1 cubic feet
  • Minimum Ported Box Volume: 1 cubic feet
  • Optimum Ported Box Volume: 1.25 cubic feet
  • Maximum Ported Box Volume: 1.5 cubic feet
  • Top-Mount Depth (Mounting Depth): 6"
  • Cutout Diameter: 9.125"
  • Shallow Mount Installation: No



Electromechanical Parameters:

  • Free-Air Resonance (Fs): 39.8 Hz
  • Equivalent Compliance (Vas): 0.406 liters
  • Total Speaker Q Value (Qts): 0.56
  • Electrical Q Value (Qes): 0.64
  • Electrical Resistance of Voice Coil (Re): 3.6 ohms
  • Mechanical Q Value (Qms): 4.54
  • UPC: 709483055766
  • Weight: 18
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
