Kicker 44L7S104 Solo-Baric L7S Series 10" 600W RMS (1200W Peak Power Handling) 4 Ohms, Dual Voice Coil Component Car Subwoofer
We are a Kicker authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 10" Solo-Baric L7S Series Dual Voice Coil Component Car Subwoofer
- • (2) Kicker decals
- • Template on box lid
- • Owner's Manual
Why Choose Kicker 44L7S104 Component Car Subwoofer?
Flexible, Durable, and Clear
Featuring dual four-ohm voice coils, this subwoofer allows flexible wiring for maximum system customization. The injection-molded polypropylene cone ensures durability and distortion-free sound, while patented corner ribs reinforce the cone to maintain clarity even at high output.
Reinforced for Precision and Durability
The SoloKon 360-degree back bracing strengthens the cone and eliminates unwanted flex, while the ribbed Santoprene surround with blue stitching enhances durability and ensures smooth, controlled cone excursion for consistent, high-quality bass.
Powerful, Precise, and Controlled Bass
The large ceramic magnet delivers a strong motor force that enhances cone control, producing tight, accurate bass with minimal distortion. Its robust magnetic structure ensures consistent performance at high volumes, allowing your subwoofer to maintain clarity and punch even during demanding tracks, giving your system a professional-grade low-end response.
Frequently Asked Questions (FAQ)
- • What amplifier is recommended for this subwoofer?
Choose an amplifier with an RMS output that closely matches the subwoofer's continuous power rating. Proper gain adjustment helps maximize performance while preventing distortion.
- • Can I install it in a sealed or ported enclosure?
Yes, it performs well in either enclosure when built to the recommended specifications. Sealed boxes offer tighter bass, while ported enclosures produce more output.
- • Why does my bass sound weak after installing the subwoofer?
This is often caused by incorrect enclosure volume, reversed polarity, or poor amplifier tuning. Double-checking your wiring and crossover settings usually improves bass response.
- • Can I wire two subwoofers to the same mono amplifier?
Yes, provided the final impedance matches the amplifier's supported load. Always calculate the wiring configuration before connecting multiple speakers.
- • Why does the bass distort at higher volumes?
Distortion is commonly caused by amplifier clipping or gain settings that are too high. Proper tuning delivers cleaner bass and protects the subwoofer from damage.
- • Does it need a break-in period?
Many users recommend several hours of moderate playback before using maximum power. This helps the suspension loosen naturally for more consistent performance.
- • Why is the cone making a popping or slapping sound?
This usually happens when the subwoofer exceeds its mechanical limits or receives clipped power. Lower the volume and inspect your amplifier and enclosure settings.
- • Is it suitable for high-output daily systems?
Yes, it is designed to deliver strong bass while remaining reliable for everyday listening. Pairing it with the correct enclosure and amplifier will maximize its performance.
- • Why does it get warm during long listening sessions?
Some heat is normal when handling continuous power over extended periods. Excessive heat may indicate overpowering or improper amplifier gain settings.
- • Can it reproduce both deep bass and punchy kick drums?
Yes, it delivers excellent low-frequency performance across many music genres when installed correctly. Proper enclosure design and tuning help produce both deep extension and fast, accurate bass.
- Diameter : 10 Inch
- Sensitivity : 86.8 dB
- Depth : 6.26 Inch
- Impedance : 4 Ohm
- Frequency Response : 24-100 Hz
- Peak Power Handling : 1200 Watts
- Top Mount Depth : 6-1/4 Inches
- Shallow Mount : No Inch
- Number of Voice Coils : Dual
- Suggested Sealed Box Volume : 1-1.25 Cubic ft.
- Suggested Ported Box Volume : 1.25-2.25 Cubic ft.
- Mounting Depth : 6-1/4 Inches
- RMS Power Handling : 600 Watts
Features:
- Dual Four-Ohm Voice Coils: Allow flexible wiring options for maximum system customization.
- Injection-Molded Polypropylene Cone: Provides a durable, rigid cone for distortion-free sound.
- Patented Corner Ribs Minimize Distortion: Reinforce the cone to maintain clarity at high output.
- SoloKon 360-Degree Back Bracing: Strengthens the cone and eliminates unwanted flex.
- Ribbed Santoprene Surround With Blue Surround Stitching: Enhances durability and maintains smooth cone excursion.
- UniPlate Back Plate and Pole Piece, Plus Perimeter Venting: Ensures superior thermal management for reliable, consistent performance.
- Thick Tinsel Leads: Handle high current without compromising performance.
- Large Ceramic Magnet: Provides strong motor force for tight, accurate bass.
- Cast Aluminum Basket: Maintains structural rigidity to prevent vibration and resonance.
- Satin-Nickel Plated, Spring-Loaded Speaker Terminals: Offer secure, corrosion-resistant connections.
Specifications:
- Size: 10" (25.4 cm)
- Impedance: 4 Ohm (DVC)
- Recommended Amplifier Power (RMS): 600 W
- Peak Power Handling: 1200 W
- Sensitivity (1W/1m): 86.8 dB
- Frequency Response: 24–100 Hz
- Mounting Depth: 6-1/4" (15.9 cm)
- Mounting Cutout, Square: 9-5/16" (23.7 cm)
- Minimum Sealed Box Volume: 1.0 cu. ft. (28.32 L)
- Maximum Sealed Box Volume: 1.25 cu. ft. (35.4 L)
- Minimum Vented Box Volume: 1.25 cu. ft. (35.4 L)
- Maximum Vented Box Volume: 2.25 cu. ft. (63.8 L)
- UPC: 713034081203
- Weight: 20.5
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
