Crunch is considered a common name among car audio gearheads. Their products are manufactured to high end specifications to provide excellent sound experience. Onlinecarstereo has been a long time partner of Crunch so you can be sure you get authentic products with warranties stright from the warehouse.
- Low Frequency Response : 50-250 Hz
- High Frequency Response : 120-3000 Hz
- Number of Channels : 2
- Frequency Response : 50-3000 Hz
- Built In Crossovers : Yes
- Channel Separation : Yes
- RMS Power Range : 1000 Watts
- Amplifier Class : A/B
Specifications:
- CLASS
Class A/B
- VARIABLE VOLTAGE
11-15VDC
- SIGNAL TO NOISE
>98dB
- FREQUENCY RESPONSE
20Hz - 20KHz
- CROSSOVER TYPE
Variable Electronic 12dB Per Octave
- HIGH PASS CROSSOVER:
12DB PER OCTAVE:
120HZ-3000Hz
- LOW PASS CROSSOVER:
12DB PER OCTAVE:
50Hz-250Hz
- TONE CONTROL
Built-in bass control
- BASS BOOST
Switched 0-6-12dB
- SUBSONIC FILTER
N/A
- POWER OUTPUT @ 1 OHM:
N/A
- POWER OUTPUT @ 2 OHMS:
2 x 500W
- POWER OUTPUT @ 4 OHMS
2 x 250W
- MONO BRIDGED @ 4-OHMS
1000W
- TOTAL CHANNELS
2
- AUDIO INPUTS:
Unbalanced Inputs (RCA)
- POWER TERMINAL:
12V/GND
8 ga
- SPEAKER TERMINAL WIRE GAUGE
8 ga
- FUSING
20A x 2
- DIMENSIONS
11.4 x 10.8 x 3.7 in
28.9 x 27.4 x 9.3 cm
- WEIGHT
4.65 lbs (2.1 kg)
Features & Benefits
- PRE-AMP CIRCUITRY Low Noise PreAmplifier
Maximum low voltage signal from the source unit comes into the amplifier through a low voltage circuit which delivers minimal distortion through the amplification process
- INPUTS Low voltage RCA Inputs
Highest sound quality connection with quality RCA materials helps prevent interference and minimize distortion in the signal path
- HIGH LEVEL INPUTS Yes
Easily tie into OEM audio systems that do not offer RCA output to maximize after market amplifier power
- OPERATION MODE 3
Stereo, Bridged Mono or Stereo/Bridged Mono Simultaneously
- CROSSOVER / SIGNAL SHAPING Versa-Cross Electronic Crossover
Fully Adjustable 12dB Crossovers
- EQUALIZER Electronic
Control of amplifier output with on board electronic crossover to tailor specific frequencies to speakers and subwoofers.
- CLASS / TOPOLOGY Class A/B
High sound quality circuit that allows POWER DRIVE to develop high levels of power with minimal distortion
- OUTPUT DEVICES TECHNOLOGY SPEED-FET
Exclusive Crunch SPEED-FET MOSFET components maximize power efficiency while improving sound quality and minimizing distortion
- HEAT SINK QTD Technology Aluminum
Quick Thermal Dispersion Technology assures additional mass in the aluminum heat sink keeps the amplifier running cool with nearly undetectable distortions during normal music listening.
- POWER SUPPLY PWM Power Supply
High energy Pulse Width Modulated Power Supply delivers power with minimal impact on the electrical system
- OUTPUT CONNECTIONS Nickel Plated
Nickel Plated Brass Connection with terminals allow for secure connection while resisting corrosion
- CONNECTIONS TYPE Screw Down Connectors
Easy access for hand tool allowing a quick and secure connection
- DIAGNOSTICS LED System Protection Circuitry
Monitor overload and speaker short protection with lighted indicators on the amplifier end panel
- UPC: 806576225331
- Weight: 4.65
- Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
