Crunch PX1000.2

Item# 48753

PowerX Series 1000 Watt 2-channel Class AB Car Audio Amplifier

Sorry, this product is no longer available.

What other people bought after viewing this product.

Crunch is considered a common name among car audio gearheads. Their products are manufactured to high end specifications to provide excellent sound experience. Onlinecarstereo has been a long time partner of Crunch so you can be sure you get authentic products with warranties stright from the warehouse.

Specifications:

  • CLASS
    Class A/B
  • VARIABLE VOLTAGE
    11-15VDC
  • SIGNAL TO NOISE
    >98dB
  • FREQUENCY RESPONSE
    20Hz - 20KHz
  • CROSSOVER TYPE
    Variable Electronic 12dB Per Octave
  • HIGH PASS CROSSOVER:
    12DB PER OCTAVE:
    120HZ-3000Hz
  • LOW PASS CROSSOVER:
    12DB PER OCTAVE:
    50Hz-250Hz
  • TONE CONTROL
    Built-in bass control
  • BASS BOOST
    Switched 0-6-12dB
  • SUBSONIC FILTER
    N/A
  • POWER OUTPUT @ 1 OHM:
    N/A
  • POWER OUTPUT @ 2 OHMS:
    2 x 500W
  • POWER OUTPUT @ 4 OHMS
    2 x 250W
  • MONO BRIDGED @ 4-OHMS
    1000W
  • TOTAL CHANNELS
    2
  • AUDIO INPUTS:
    Unbalanced Inputs (RCA)
  • POWER TERMINAL:
    12V/GND
    8 ga
  • SPEAKER TERMINAL WIRE GAUGE
    8 ga
  • FUSING
    20A x 2
  • DIMENSIONS
    11.4 x 10.8 x 3.7 in
    28.9 x 27.4 x 9.3 cm
  • WEIGHT
    4.65 lbs (2.1 kg)

Features & Benefits



  • PRE-AMP CIRCUITRY Low Noise PreAmplifier
    Maximum low voltage signal from the source unit comes into the amplifier through a low voltage circuit which delivers minimal distortion through the amplification process
  • INPUTS Low voltage RCA Inputs
    Highest sound quality connection with quality RCA materials helps prevent interference and minimize distortion in the signal path
  • HIGH LEVEL INPUTS Yes
    Easily tie into OEM audio systems that do not offer RCA output to maximize after market amplifier power
  • OPERATION MODE 3
    Stereo, Bridged Mono or Stereo/Bridged Mono Simultaneously
  • CROSSOVER / SIGNAL SHAPING Versa-Cross Electronic Crossover
    Fully Adjustable 12dB Crossovers
  • EQUALIZER Electronic
    Control of amplifier output with on board electronic crossover to tailor specific frequencies to speakers and subwoofers.
  • CLASS / TOPOLOGY Class A/B
    High sound quality circuit that allows POWER DRIVE to develop high levels of power with minimal distortion
  • OUTPUT DEVICES TECHNOLOGY SPEED-FET
    Exclusive Crunch SPEED-FET MOSFET components maximize power efficiency while improving sound quality and minimizing distortion
  • HEAT SINK QTD Technology Aluminum
    Quick Thermal Dispersion Technology assures additional mass in the aluminum heat sink keeps the amplifier running cool with nearly undetectable distortions during normal music listening.
  • POWER SUPPLY PWM Power Supply
    High energy Pulse Width Modulated Power Supply delivers power with minimal impact on the electrical system
  • OUTPUT CONNECTIONS Nickel Plated
    Nickel Plated Brass Connection with terminals allow for secure connection while resisting corrosion
  • CONNECTIONS TYPE Screw Down Connectors
    Easy access for hand tool allowing a quick and secure connection
  • DIAGNOSTICS LED System Protection Circuitry
    Monitor overload and speaker short protection with lighted indicators on the amplifier end panel
  • UPC: 806576225331
  • Weight: 4.65
  • Authorized Internet Dealer
*Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.

Do you own this product?  Write a review

   Larry Day From Hopkinsville, Ky 42240
I’ve had my amp over a year n it’s been putting in the work I needed
