Wet Sounds SYN-DX2.3hp SYN-DX Series 2-Channel 600W RMS x 2 at 2 Ohms, Class-D High Power Marine Amplifier
We are a Wet Sounds authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • SYN-DX Series 2-Channel Class-D High Power Marine Amplifier
- • (4) 20-amp ATO fuses (installed)
- • Wet Sounds badge
- • Specifications on box
- • Owner's Manual
Why Choose Wet Sounds SYN-DX2.3 HP Marine Amplifier?
SYN-DX Series Amplifier
The Wet Sounds SYN-DX2.3hp is a powerful and versatile amplifier designed specifically for marine audio applications. With its compact and durable design, it is built to withstand the harsh conditions of the marine environment. The SYN-DX2.3hp features a Class D amplifier topology, allowing it to deliver high-quality sound while maximizing efficiency and minimizing heat generation.
Protection Ensures the Longevity
It is capable of delivering up to 300 watts RMS per channel at 4 ohms, making it suitable for driving a wide range of marine speakers. One notable feature of the SYN-DX2.3hp is its 3-way protection circuitry, which safeguards the amplifier against short circuits, thermal overload, and DC offset. This protection ensures the longevity of the amplifier and prevents damage to the connected speakers.
Flexible Input Options
The amplifier also offers flexible input options, including RCA and speaker-level inputs, allowing for easy integration into various audio systems. Additionally, it has adjustable high-pass and low-pass crossovers, enabling precise tuning of the audio output to suit individual preferences. The Wet Sounds SYN-DX2.3hp is a high-performance marine amplifier that combines power, durability, and versatility. Whether you're looking to upgrade your boat's audio system or enhance your marine audio experience, this amplifier offers an excellent solution.
Frequently Asked Questions (FAQ)
- • Why won't the amplifier turn on?
Check the fuse, power cable, ground connection, remote wire, and battery voltage. A loose connection or insufficient voltage can prevent the amplifier from powering on.
- • Why does it enter protection mode?
Check for shorted speaker wires, incorrect impedance, overheating, or poor connections. Disconnect the speakers and inspect the wiring before reconnecting and testing the system.
- • Why does the amplifier shut down at high volume?
Check battery voltage, speaker impedance, gain settings, and ventilation. Excessive demand or insufficient airflow can trigger protection. Reduce volume and verify the electrical system.
- • Why is there no sound from one channel?
Check RCA connections, speaker wiring, source settings, and channel controls. Swap inputs or speakers between channels to determine whether the issue comes from the amplifier or wiring.
- • Why does the audio sound distorted?
Check gain, source level, and equalizer settings. Excessive gain can cause clipping. Lower the gain and adjust source volume until playback sounds clean.
- • Why does the amplifier become very hot?
Some heat is normal, but excessive temperature can indicate inadequate ventilation, heavy loading, or prolonged high output. Provide airflow and verify speaker impedance.
- • Why is the high-pass output weaker than expected?
Check the high-pass crossover settings, gain, source signal, and speaker wiring. Incorrect filtering or insufficient gain can reduce output from connected high-frequency speakers.
- • Why do I hear a humming or buzzing noise?
Check the ground connection, RCA cables, and cable routing. Keep signal cables away from power wiring and inspect connections for looseness or electrical interference.
- • Can it power multiple marine speakers?
Yes. Its multi-channel design can power several speakers when wired within the amplifier's rated impedance and power limits. Verify each speaker's requirements before installation.
- • Why does the sound cut out intermittently?
Inspect power, ground, RCA, and speaker connections for looseness. Also check for overheating or voltage drops, which can cause interruptions during demanding playback.
- Maximum Power : 1200 Watts
- Low Frequency Response : 50-500 Hz
- High Frequency Response : 50-500 Hz
- Number of Channels : 2
- Frequency Response : 20-20000 Hz
- Built In Crossovers : Yes
- RMS Power Output : 600x2 Watts
- Channel Separation : Yes
- Amplifier Class : D
- Promo : Yes
Features:
- Superior Performance Circuitry: Class-D power supplies for efficient and powerful performance.
- Extreme Power Output: High power output packed inside a small chassis.
- Thermal Overload Protection: Built-in protection to prevent overheating and ensure longevity.
- Flexible Crossovers: Adjustable crossovers for customizable sound tuning.
- Extended Inputs: Versatile input options for various audio sources.
- Well-Balanced Match: SYN-DX amplifiers are perfectly matched with all Wet Sounds products.
- Smart Microprocessor and Conformal Coated PCB Board: Ensures reliable power and great control.
Specifications:
- 4 Ohms: 300W x 2
- 2 Ohms: 600W x 2
- 4 Ohms - 1: 1200W x 1
- Input Sensitivity: 0.2 V - 6.0 V
- Crossover Range High Pass: 50 Hz - 500 KHz 12dB/Octave
- Crossover Range Low Pass: 50 Hz - 500 KHz 12dB/Octave
- Chassis Size: 14.63” x 8.52” x 3.08”
- Channels: 2
- Frequency Response: 20 Hz - 20 KHz
- Series: SYN-DX
- UPC: 814820024562
- Weight: 13
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
