Pioneer TS-G6930F G-Series 6x9" 45W RMS (400W Peak Power Handling) 4 Ohms 3-Way Coaxial Speakers
We are a Pioneer authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • (2) Speakers
- • (2) Grilles (attached)
- • (8) Mounting Screws
- • (2) Speaker Connection Cables
- • User manual
Why Choose Pioneer TS-G6930F Full Range Car Speakers?
Immersive Audio Precision
The "3-way" indicates that the speaker is composed of three individual speaker drivers, each responsible for reproducing a specific range of frequencies. In this case, the TS-G6930F consists of a woofer, a midrange driver, and a tweeter.
Feel the Thunderous Bass
The woofer is the largest driver in the speaker and is responsible for reproducing low-frequency sounds, such as bass and mid-bass tones. It enhances the overall depth and impact of the audio.
Captivating Midrange Brilliance
The midrange driver handles the middle range of frequencies, including vocals, instruments, and other midrange sounds. It ensures clarity and detail in this frequency range.
Frequently Asked Questions (FAQ)
- • Will these work with my factory car stereo?
Yes. They are designed to work with most factory and aftermarket head units, although an external amplifier will provide better volume and sound quality.
- • Why do the speakers distort when I increase the volume?
Distortion is usually caused by amplifier clipping, excessive bass boost, or an underpowered head unit. Reducing the volume or powering the speakers with a properly matched amplifier can help eliminate distortion.
- • Why is the bass weaker than I expected after installation?
Weak bass is often caused by reversed speaker polarity or poor sealing between the speaker and the mounting surface. Verify the wiring polarity and ensure the speakers are securely mounted.
- • Will these fit my vehicle without modifications?
They fit many vehicles with factory 6"x9" speaker locations, but fitment depends on your vehicle's make and model. Some installations may require mounting brackets or wiring adapters.
- • Why does one speaker cut in and out while driving?
Intermittent audio is commonly caused by loose wiring, damaged speaker cables, or poor terminal connections. Inspect all wiring and connectors before replacing the speaker.
- • Can I connect these to an aftermarket amplifier?
Yes. They perform well with a properly matched aftermarket amplifier, delivering cleaner sound and increased output.
- • Why do my rear deck or door panels rattle after installing the speakers?
Higher-output speakers can expose vibrations in factory panels and trim pieces. Adding sound-deadening material and tightening loose hardware can significantly reduce rattles.
- • Do these speakers require a break-in period?
Yes. Playing music at moderate listening levels for several hours allows the suspension to loosen naturally and helps the speakers reach their best sound quality.
- • Why do I hear crackling or popping sounds during playback?
Crackling noises are typically caused by damaged wiring, clipped amplifier signals, or a faulty audio source. Check the wiring, amplifier settings, and source unit to determine the cause.
- • Are these suitable for different music genres?
Yes. Their full-range design delivers balanced performance for rock, pop, hip-hop, country, jazz, and electronic music.
- Diameter : 6x9 Inch
- Sensitivity : 90 dB
- Impedance : 4 Ohm
- Frequency Response : 32-32000 Hz
- Peak Power Handling : 400 Watts
- Design : 3 Way
- RMS Power Handling : 45 Watts
Features:
- 400 Watts Max. Power
- IMPP™ (Injection Molded Polypropylene) Composite Cone Woofer
- Patented Pioneer P.F.S.S Spider
- 2" Cone midrange and 3/8" Dome tweeter
Specifications:
- Size: 6" x 9"
- Design: Coaxial 3-Way
- Tweeter Design: 2" Cone midrange and 3/8" Dome tweeter
- Tweeter Composition: Polyethylene Terephthalate (PET)
- Woofer Composition: IMPP™ (Injection Molded Polypropylene) with MICA
- Woofer Surround: Rubber Coated Cloth
- Woofer Magnet Composition: Ferrite
- Warranty: 1 Year (must be purchased from an Authorized Pioneer Dealer)
- Max. Music Power (Nominal): 400W (45W)
- Frequency Response: 32 Hz to 32 kHz
- Sensitivity (1W/1 m): 90 dB
- Impedance: 4 Ohms
- Mounting Depth: 2-3/4" (in.)
- Cut-Out Dimensions: 6" x 8-3/4" (in.)
- UPC: 884938373579
- Weight: 6
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
