Alpine HCE-C1100 High Dynamic Range (HDR) Rear View Camera
We are a Alpine authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
•Rear-view camera (with attached 20" cable terminated by a 4-pin connector)
• 23" Power/Ground/Signal harness (w/ 4-pin connector on one end and 6-pin connector on other end)
•32.5" Power/Video harness
•9.5" Power/Ground/Signal harness (w/ a 6-pin connector on one end and a male composite video RCA connector on other end along with power/ground signal wire)
• (2) Mounting bracket
•(4) Machine screws
• (4) Self-tapping screws
• Rubber sleeve
• Owner's Manual
High-quality Rearview Camera
The Alpine HCE-C1100 is a high-quality rearview camera designed to enhance driving safety and convenience. This camera provides a clear and wide-angle view of the area behind your vehicle, allowing you to navigate tight spaces, park, and prevent accidents easily.
Compact and Discreet Design
The HCE-C1100 features a compact and discreet design that can be easily installed on the rear of your vehicle. It offers a wide viewing angle, typically around 131 degrees, which provides a broad perspective of the rear surroundings.
Utilizes Advanced Image Sensor Technology
The camera utilizes advanced image sensor technology to deliver crisp, detailed video output, even in low-light conditions. It is designed to withstand various weather conditions and is built with durability in mind, ensuring long-lasting performance.
Alpine Multimedia Receivers
The HCE-C1100 is compatible with Alpine multimedia receivers, which can display the camera's video feed on the screen. Some models may offer additional features like distance guide lines, allowing for more precise maneuvering.
Color : Black
High Dynamic Range (HDR) Rear View Image
RCA Video Signal (NTSC) Output
Vehicle Reverse Signal Synchronization
Mirror Image Output
Color CMOS Image Sensor
Automatic Exposure Adjustment
Automatic White Balance Adjustment
Power Requirement: DC 9V to DC 15.6V
Ground Type: Negative Ground
Power Consumption: 1.2W (12V)
Operating Temperature (Box Unit): -30°C - +70°C
Camera (Excluding Projection On The Rear): 0.93" x 0.93" x 0.94"
Camera Cable Length: 0.5 Meter (1.64 Feet)
Camera Extension Cable Length: 7 Meter (23 Feet)
Reverse/ACC/Video/GND Cable Length: 3 Meter (9.9 Feet)
Output Image: Mirror Image, Composite Video NTSC, Aspect Ratio 4:3
Output Drive Capacity: 75 Ohms (1Vp-p)
Image Sensor: 1/3.7 inch CMOS image sensor
Effective Number of Pixels: 640 (H) x 480 (V), Approximately 0.3 Mega pixels
Lens Focal Length: f=1.34mm
Lens Brightness: F=1:2.0
Angle of Field: Horizontal = 131°, Vertical = 103°
S/N Ratio: 40.5 dB or more
Resolution (Horizontal. Center Area): 330 TV Lines
Operating Temperature: -30°C - +70°C
Illumination Range: Approximately 1.5 to 100klx
Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
