Pioneer  TS-WX400DA Hot Deal

Compact Series 4" 250W Peak Power Handling, Sealed Enclosed Car Subwoofer

Item #52836

Condition:   Brand New

Product Highlights

  • Compact Series
  • 4" Enclosed Car Subwoofer
  • Sealed
  • 250W Peak Power Handling

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.

$469.99

Reg. Price $580.00  Save $110.01

Out of Stock Check out other products listed below
Pioneer Authorized Dealer

Huge Saving on Other items:



Huge Saving on Other items:


Pioneer Banner for Onlinecarstereo

Pioneer TS-WX400DA Compact Series 4" 250W Peak Power Handling, Sealed Enclosed Car Subwoofer


We are aPioneerauthorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • Powered subwoofer
  • • Wired remote control with attached 16.25' cable
  • • 16.5' Power harness w/ inline 10A mini fuse (62" ground lead / 8" RCA input plugs)
  • • (2) Mounting plates
  • • Cable strain-relief bar
  • • (2) 3/4" screws
  • • (2) 1/2" screws
  • • (2) 1/4" screws
  • • 1-1/2" Hook-and-loop fastener pad
  • • Warranty sheet
  • Owner's Manual
Big Bass in a Small Space

The Pioneer TS-WX400DA proves you don’t need a bulky box to get serious low-end impact. Built with a slim, underseat-friendly design and a down-firing rectangular driver, this compact subwoofer fits neatly into tight spaces while still delivering deep, satisfying bass. Whether you're working with a small cabin or just want a clean install, this setup keeps your system powerful without taking over your interior.



Smart Power and Sound Control

Inside, the efficient Class-D amplifier pushes out 100 watts RMS and 250 watts peak while staying cool and energy-efficient. You also get two bass personalities to match your vibe. Switch to Deep Mode for smooth and rich lows or go Dynamic Mode when you want harder hitting punch for hip-hop and EDM. The included wired remote puts full control within reach, letting you adjust gain, crossover from 50Hz to 125Hz, phase, and bass mode right from the driver seat.



Easy Setup with Flexible Integration

Installation is straightforward thanks to the single harness wiring system and included cables, making the process cleaner and faster. With both RCA and high-level input support, it works seamlessly with factory or aftermarket head units. Adjustable input sensitivity ensures proper signal matching, while the included mounting brackets let you secure it under seats, in the trunk, or on a seatback. It is a simple way to upgrade your system with powerful bass and a professional, space-saving finish.


























SPECIFICATIONS


  • Diameter : 4 Inch
  • Maximum Power : 250 Watts
  • Frequency Response : 20-100 Hz

FEATURES


Features:

  • Ultra-Compact Underseat Subwoofer Design: Engineered with a slim, space-saving enclosure and a down-firing rectangular driver, allowing installation under seats or in tight vehicle spaces without sacrificing bass performance.
  • Efficient Class-D Amplification System: Integrated Class-D amplifier delivers 100 watts RMS and 250 watts peak power while maintaining high efficiency, reduced heat generation, and consistent output performance.
  • Dual Selectable Bass Modes: Offers Deep Mode for smooth, low-end richness and Dynamic Mode for more aggressive, punchy bass, giving flexibility to match different music genres and listening preferences.
  • Driver Seat Wired Remote Control: Includes a dedicated remote with gain, crossover frequency adjustment from 50Hz to 125Hz, phase switch, and bass mode selector for real-time tuning convenience.
  • Flexible Input Configuration Options: Supports both RCA preamp inputs and high-level speaker inputs, making it compatible with a wide range of factory and aftermarket head units.
  • Single Harness Simplified Wiring System: Utilizes a 10-pin Molex connector with included power cable, inline fuse, ground wire, and remote turn-on lead for clean and straightforward installation.
  • Adjustable Input Sensitivity Settings: Features selectable gain modes optimized for high-voltage RCA signals or standard inputs, ensuring proper signal matching and balanced performance.
  • Secure Multi-Position Mounting Capability: Comes with mounting brackets designed for stable installation on floors, trunks, or seat backs, enhancing versatility across different vehicle layouts.



Specifications:

  • System Type: Powered
  • DEEP: 72 dB
  • DYNAMIC: 73 dB
  • DEEP: 20 Hz to 100 Hz
  • DYNAMIC: 20 Hz to 100 Hz
  • CTA-2031 Compliant: Yes
  • Warranty: 1 Year
  • Continuous Power Handling (RMS) - Watts: 100 Watts
  • Maximum Peak Power Handling - Watts: 250 Watts
  • Built-In Amp: Yes
  • Amp Max Power Output: 250 Watts
  • Amp RMS Output: 100 Watts
  • DEEP: 85 mV+85 mV/22 kOhm
  • DYNAMIC: 75 mV+75 mV/22kOhm
  • DEEP: 1.9 V+1.9 V/5 kOhm
  • DYNAMIC: 1.7 V+1.7 V/5kOhm
  • Power Source: DC 14.4V
  • Amp Max Current Consumption: 9.4 A
  • Amp Grounding: Negative
  • Shape: Special
  • Size: 9" x 5-1/2"
  • Cone Material: IMPP - Composite
  • Drive Cone Material: ABS
  • Surround Material: Urethane
  • Surround Type: Rolled
  • Basket Material: Stamped Metal
  • Magnet Material: Ferrite
  • Magnet Weight: 26.8 oz
  • Voice Coil Type: Single Voice
  • Voice Coil Bobbin: Kapton
  • Voice Coil Special Feature: Copper
  • Voice Coil Wire: Aramid
  • UPC: 884938416221
  • Weight: 11
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
