Designed for Marine Use
Conformal coating PCB reduces the damaging effects of sun exposure and adverse weather conditions making the GM-ME400X4 ideal for marine use*
*Do not install the unit in areas that are exposed to direct sunlight, excessive heat or humidity. Also avoid places with dust or areas with a high level of water splashing.
- Maximum Power : 1200 Watts
- Low Frequency Response : 10 Hz
- High Frequency Response : 35000 Hz
- Number of Channels : 4
- Built In Crossovers : Yes
- RMS Power Output : 75x4 Watts
- Channel Separation : Yes
- Amplifier Class : D
GENERAL
- RCA Inputs: 4-CH
- Amplifer Class: CLASS-D
- High Quality Sound Parts: Yes
- Hi-Res Certified Yes
- Speaker Level Inputs Yes
- Crossover Type: Variable HPF/LPF
- Bridgeable Yes
- Warranty (must be purchased from an Authorized Pioneer Dealer): 1 Year
SPECIFICATIONS
- Continuous Power (RMS) Output at 1 Ohm: 150W RMS x 4
- Continuous Power (RMS) Output at 2 Ohms: 120W RMS x 4
- Continuous Power (RMS) Output at 4 Ohms: 75W RMS x 4
- Continuous Power (RMS) Output - Bridged at 4 Ohms: 240W RMS x 2
- Frequency Response: 10 Hz to 35 kHz
- Total Harmonic Distortion (THD): < 0.05% (1 kHz)
- Signal-to-Noise (SN) Ratio: 95 dB (IHF-A Network)
- Fuse Rating: 30 A x 2
- Low-Pass Crossover Frequency: 40 Hz to 500 Hz
- Low Pass Slope (dB/octave): -12 dB/oct.
- High-Pass Crossover Frequency: 40 Hz to 500 Hz
- Hi-Volt Input Level Control: 200 mV to 6.5 V
- Terminal Type: Block
- Load Impedance Allowance (Ohms): 1 to 8
- Protection Control System: Yes
- Dimensions: 10-38" x 2-3/8" x 7-7/8"
MARINE
- Rubber Covers Included: Side Panel Cover, RCA Terminal Cover, FUSE Cover
- UPC: 884938432115
- Weight: 15
