Kenwood Excelon DPX794BH CD Receiver with Bluetooth
We are a Kenwood Excelon authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • CD receiver (10A fuse)
- •2 Trim rings (one attached)
- •Sleeve (installed)
- • Wiring harness
- •Microphone w/ bracket (attached 10' cable terminated by a right-angle mono 3.5mm connector)
- •6 Pan-head ISO-mount screws
- •6 Flat-head ISO-mount screws
- •2 Removal tools
- •Quick Start Gude
- •Warranty Card
- •Software License Agreement
- •Owner's Manual
The Best Audio Experience
Sound quality enthusiasts will love the playback support of various types of music formats, including compatibility with FLAC files. Simple touch screen sound customization is also available with its built-in 13-Band EQ and Digital Time Alignment. Learn about exciting product features and highlights.
Smartphone Connectivity
Enjoy built-in Bluetooth for convenient access to hands-free calls and streaming music, as well as the ability to use your smartphone like a wireless remote control. Purchase KENWOOD Products ONLY from Authorized KENWOOD Retailers!
- Maximum Power : 40 Watts
- Satellite Radio Ready : Yes
- RMS Power Output : 22 Watts
- Subwoofer Preamp Outputs : Yes
- Built-in EQ : Yes
- DIN : 2
- Preamp Voltage : 5 volts
- Bluetooth : Yes
- Aux Input : Yes
- MP3 Playback : Yes
- WMA Playback : Yes
- HD Radio : Yes
- Front USB Input : 1
- Rear USB Input : 1
- Preamp Outputs : 6
- Apple CarPlay : No
- Android Auto : No
FM
- Frequency Range: 87.9MHz to 107.9MHz
- (Frequency step): (200kHz)
- Channel Space Selection
- Usable Sensitivity: 7.2dBf
- S/N 30dB: (0.63μV/75 ohms)
- Quieting Sensitivity: 15.2dBf
- DIN S/N:46dB: (1.580μV/75 ohms)
- Frequency Response (±3.0dB): 30Hz to 15kHz
- S/N: 68.0dB(MONO)
- Stereo Separation: 40dB(1kHz)
Digital FM
- Frequency Range: 87.9MHz - 107.9MHz
- (Frequency step): (200kHz)
- Frequency Response (±3.0dB): 20Hz-20kHz
- S/N: 75dB(STEREO)
AM
- Frequency Range: 530kHz to 1700kHz
- (Frequency step): (10kHz)
- Channel Space Selection
- Usable Sensitivity( S/N:20dB): 29dBμ (28.2μV)
Digital AM
- Frequency Range: 530kHz - 1700kHz
- (Frequency step): (10kHz)
- Frequency Response(±3.0dB): 40Hz-15kHz
- S/N 70dB(STEREO)
CD
- Laser Diode: GaAlAs
- Digital Filter(D/A): 8 Times OverSampling
- Spindle Speed: 500 to 200rpm (CLV)
- Wow & Flutter: Below Measurable Limit
- Frequency Response: 20Hz to 20kHz(±1dB)
- Total Harmonic Distortion: 0.01%(1kHz)
- S/N Ratio (dB): 96dB(1kHz)
- Dynamic Range: 91dB
- Channel Separation: 84dB
- MP3 Decode: Compliant with MPEG-1/2 Audio Layer-3
- WMA Decode: Compliant with WINDOWS MEDIA AUDIO
- AAC Decode: AAC-LC ".aac" files
- WAV Decode: -
Preout Level(mV)/Load -Unbalanced: 5000mV/10k ohms
Preout Impedance(Ω) =<600 ohms
Speaker Impedance(Ω): 4 to 8 ohms
USB I/F
- USB: USB 1.1 / 2.0 High Speed
- File System: FAT12 / 16 / 32
- Maximum Supply current: DC5V(DC logo) 1.5A
- MP3 Decode: Compliant with MPEG-1/2 Audio Layer-3
- WMA Decode: Compliant with Windows Media Audio
- AAC Decode: AAC-LC ".aac",".m4a" files
- WAV Decode: Linear-PCM
- FLAC Decode: FLAC file (Up to 24bit/96kHz)
AUX
- Frequency Response: 20Hz to 20kHz ±3dB
Input
- Input Maximum Voltage: 1000mV
- Input Impedance: 30k ohms
AMP
- Maximum Power: 50Wx4
- Full Bandwidth Power (at less than 1%THD): 22Wx4
TONE
- Band1: 62.5Hz ±9dB
- Band2: 100Hz ±9dB
- Band3: 160Hz ±9dB
- Band4: 250Hz ±9dB
- Band5: 400Hz ±9dB
- Band6: 630Hz ±9dB
- Band7: 1kHz ±9dB
- Band8: 1.6kHz ±9dB
- Band9: 2.5kHz ±9dB
- Band10: 4kHz ±9dB
- Band11: 6.3kHz ±9dB
- Band12: 10kHz ±9dB
- Band13: 16kHz ±9dB
Bluetooth
- Version: Bluetooth 4.2
- Frequency Range: 2.402 to 2.480GHz
- RF Output Power (E.I.R.P.): +4dBm (MAX), Power Class 2
- Maximum Communication range: Line of sight approx.10m(32.8ft)
- Profile:
- HFP 1.7.1 (Hands Free Profile)
- SPP(Serial Port Profile)
- PBAP(Phonebook Access Profile)
- A2DP(Advanced Audio Distribution Profile)
- AVRCP 1.6.1 (Audio/Video Remote Control Profile)
General
- Operating voltage: 12V DC car battery
- Installation Size
- (W): 182(mm) 7-3/16(in)
- (H): 111(mm) 4-3/8(in)
- (D): 156(mm) 6-1/8(in)
- Net Weight (Trim plate and Mounting sleeve: Included) 1.7(kg): 3.8(lbs)
- UPC: 019048229489
- Weight: 6.01
