Kicker 46KMC3 KMC Series 2-DIN 3.5" Marine Media Center Receiver Gauge-Style with Bluetooth, AM/FM Tuner, and RCA outputs
We are a Kicker authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 3.5" KMC Series Marine Media Center Receiver
- • Marine digital media receiver (15A)
- • Wiring harness
- • (2) Trim-rings (chrome/black)
- • Mounting bracket
- • (4) Screws
- • (2) Threaded studs
- • (2) Hex-nuts
- • (2) Lock-washers
Information Sheet
- • Owner's Manual
Why Choose Kicker 46KMC3 Marine Receiver?
The Party Starts Here
Equipped with an easily readable screen, rotary encoder and over 200 watts of total peak power into four channels, the KMC3 comes equipped with plenty of power. Add even more bump to your boat by adding amplifiers to the included RCA outputs. Connect your Bluetooth to the KMC3, plug into the included USB or RCA inputs, or turn on the AM/FM radio. Add a wired KRC12 remote for even more control. This durable media center is ready for some fun on the water!
Compact Command Center for Unstoppable Sound
This gauge-style receiver drops perfectly into a standard 3-inch cutout, giving you a sleek, flush-mount appearance on your dash, complete with interchangeable black and chrome bezels to match your custom aesthetic.Beyond its rugged design, this versatile media source is ready for high-fidelity digital files, supporting USB playback for MP3, WMA, and lossless FLAC files, while doubling as a USB charger to keep your phone powered up.
Frequently Asked Questions (FAQ)
- • Why won't the marine receiver power on?
A blown fuse, loose power connection, poor ground, or low battery voltage is usually the cause. Verify the wiring and battery voltage before attempting additional troubleshooting.
- • Why can't I pair my smartphone through Bluetooth?
Make sure Bluetooth is enabled on your phone and remove any previous pairings that could interfere with the connection. Restart both devices and try pairing again.
- • Is this receiver designed for marine environments?
Yes. It features marine-grade construction that helps resist moisture, UV exposure, corrosion, and vibration when properly installed.
- • Why is there power but no sound from the speakers?
This is often caused by disconnected speaker wires, incorrect audio settings, or an external amplifier that is not receiving a remote turn-on signal. Check all wiring and verify the output configuration.
- • Can I connect an external amplifier to improve sound quality?
Yes. The receiver supports compatible external amplifiers for increased output and improved overall system performance.
- • Why does Bluetooth audio keep cutting out?
Wireless interference or excessive distance between the receiver and your phone can interrupt the connection. Keeping your device nearby and minimizing obstructions usually improves stability.
- • Can I play music from a USB drive?
Yes, if the USB drive uses a supported file system and contains compatible audio file formats. Refer to the owner's manual for supported media specifications.
- • Why doesn't the receiver recognize my USB device?
The drive may be formatted incorrectly or contain unsupported files. Reformatting the USB drive and using compatible audio formats often resolves the issue.
- • Is the display easy to read in bright sunlight?
Yes. The display is designed to remain visible in outdoor marine conditions, making it easier to read while boating during the day.
- • Why does the receiver lose my saved settings after I turn the boat off?
This usually happens when the constant power wire is disconnected or wired incorrectly. Verify that the memory wire has continuous battery power to retain your settings.
- Maximum Power : 200 Watts
- Frequency Response : 20-20000 Hz
- RMS Power Output : 4x25 Watts
- DIN : 2
- Preamp Voltage : 2.5 volts
- Bluetooth : Yes
- Aux Input : Yes
- MP3 Playback : Yes
- WMA Playback : Yes
- Preamp Outputs : 4
- Color : Black
Features:
- Fits in gauge opening
- IPX67 certification
- Uses USB, RCA, AM/FM and Bluetooth audio sources
- USB audio playback or charging
- RCA outputs
- Compatible with KRC12 Remote Commander
Specifications:
- Power Output @ 14.4V, 4Ω stereo, <10% THD+N: 25x4
- Frequency Response [Hz]: 20-20k
- Signal-to-Noise Ratio [dB]: 87
- RCA Outputs: 1 Set of Pre-amp Outputs
- Line-Out Level [V]: 2.5
- Outer Trim Ring Dimensions [in, cm]: 3.5 x 5.5, 8.89 x 13.97
- Protrusion From Mounting Surface [in, cm]: 1.25, 3.1
- Mounting Depth [in, cm]: 3.9, 10
- Mounting Hole Diameter [in, cm]
- 3, 7.62
- Mounting Panel Thickness Range [in, cm]: Any
- IP Rating: IP66
- AUX Input SensitivityAUX Input Sensitivity: 500 mV
- USB:Playback, Charging, Compatible File System: MP2, MP3, WMA, WAV16, FLAC16 DC 5V, 1 Amp, FAT32
- BT Range (feet): 30
- UPC: 713034013143
- Weight: 1.95
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
