Infinity Kappa 693M Kappa Series 6x9” 120W RMS 3-Way Car Speakers
We are an authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- •(2) 2-way speakers
- •(2) Bottom mount adapter rings
- •(2) Grilles
- •(2) Grille frames
- •(8) 1-3/8" Screws
- •(8) Speed clips
- •(2) Adhesive backed foam gaskets
- •(2) Adhesive backed Infinity logo badges
- • Template on box
- •Installation instructions
Ability to Produce a Full-range Frequency Performance
With the Infinity Kappa 693M, you get a 3-way speaker where it has the ability to produce a full-range frequency performance which is perfect for your vehicle’s audio setup. Made for audiophiles, these speakers would be an excellent component for your dream car audio system setup.
Comes With Infinity's Renowned
The Infinity Kappa 693M comes with Infinity's renowned Plus One glass fiber woofer and hi-roll rubber surround, giving the speaker the capability to produce low and mid-frequencies accurately while being able to withstand the effects of using a speaker at very high volumes for a long time.
Made of Silk With a Dome Design
The Infinity Kappa 693M has a tweeter made of silk with a dome design and can produce a bright and clear high-frequency production with minimal distortion. It also has a one-of-a-kind super tweeter, giving the speaker a more extensive high-frequency response, which is really impressive for its size. It also comes with a level control button, so you can adjust the brightness to your preference.
Can Seriously Go Loud at High Volumes
The Infinity Kappa 693M can deliver a power output of 120 Watts RMS and can reach up to 360 Watts of peak power. Its frequency response of 35 Hz up to 40 kHz is awe-inspiring for a six-by-nine-inch speaker, as you rarely see these specifications from any other speakers. It also has a sensitivity of 94 dB, meaning it can seriously go loud at high volumes and with minimal distortion only.
- Diameter : 6x9 Inch
- Sensitivity : 94 dB
- Impedance : 3 Ohm
- Frequency Response : 35-40000 Hz
- Peak Power Handling : 360 Watts
- Design : 3 Way
- Top Mount Depth : 3-3/16 Inches
- RMS Power Handling : 120 Watts
Features:
- Plus One Woofer Cones: The Plus One speaker cones offer more surface area than other speakers that fit in the same size opening. This is accomplished by using a new basket design and hi-roll surround. The result is greater bass output and an increase in efficiency.
- Edge Driven Dome Tweeters: Each speaker has an edge-driven silk dome tweeter. Edge-driven tweeters have better dispersion characteristics and allow for a lower crossover frequency than typical tweeters of the same size, which improves imaging. The result is improved vocals and musical clarity. The tweeter also has an output level switch; choose +0 dB (flat) or -3 dB.
- Super Tweeters: The Kappa 693M adds super tweeters to reinforce the high frequencies and keep pace with the larger cone of the 6x9 woofers.
- Angled Tweeter: The tweeter/super tweeter platform is angled, allowing you to direct the tweeters toward the listeners.
- High-Output Design: The high output 3? voice coil design compensates for the high in-line resistance of small gauge factory wiring and extracts every watt from factory receivers, increasing overall system output and efficiency (relative to 4? speakers). The speakers also benefit from increased power when you upgrade the wire and add aftermarket amplifiers, designed to power a 3? load.
- Terminals: The input terminals are set screws that will accept up to 12 gauge bare wire.
Specifications:
- Peak: 360 watts per pair / 180 watts each
- RMS: 120 watts per pair / 60 watts each
- Plus One+ glass-fiber woofer cone
- hi-roll rubber surround
- edge-driven silk dome tweeter and supertweeter
- 3 ohms impedance
- Frequency Response: 35-40,000 Hz
- Top-mount Depth: 3-3/16"
- Sensitivity: 94dB
- Speaker Size: 6X9
- Design: 3-way
- Tweeter Design: Edge-Driven Dome
- Impedance (Ohms): 3
- Tweeter Composition: Silk
- Woofer Composition: Glass fiber
- Woofer Surround: Rubber
- Parts Warranty: 3 Years
- Labor Warranty: 3 Years
- Sensitivity (1W at 1 meter): N/A
- Sensitivity at 2.83 volts: 94
- Frequency Response: 35 - 40k Hz
- Minimum RMS Wattage: ---
- Maximum RMS Wattage: 120
- Peak Power Handling (Watts): 360
- Top-mount Depth (Inches): 3 3/16
- Bottom-mount Depth (Inches): 3 7/8
- Cutout Diameter or Length (inches): 0
- Mounting Height (Inches): 0.86
- UPC: 050667376994
- Weight: 10
