Diamond Audio  DMD250.1D

Diamond Series 250W Max Power, Monoblock Amplifier, Class-D

Item #80606

Product Highlights

  • 250W max power
  • Monoblock amplifier
  • Class-D design
  • Efficient power use
  • Compact and durable

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Sorry, this product is no longer available.
Checkout other products listed below

Huge Saving on Other items:



Huge Saving on Other items:


Diamond Audio DMD250.1D - Diamond Series 250W Max Power, Monoblock Amplifier, Class-D


We are a Diamond Audio authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • Monoblock Amplifier, Class-D
  • • Owner's Manual
Compact Power and Precision for Your Subwoofers

The Diamond Audio DMD250.1D 1 Channel 250-watt amplifier is an excellent choice for powering your subwoofers with high output. It features balanced differential inputs for noise-free operation, ensuring precise audio quality wherever you are. Its compact design simplifies installation, allowing for easy mounting in any location. The DMD Series, which includes five models—one 4-channel, three mono-channel, and one 6-channel amplifier—boasts advanced performance with the latest IR chipset and innovative SMD technology on 4-layer FR4 PC boards. This series offers features such as a subsonic filter, bass boost, and an LED-lit logo for power/protection status, all backed by rigorous audio precision quality control. Upgrade to the DMD Series Amplifiers from Diamond Audio for a blend of power, cutting-edge technology, and exceptional value, and transform your mobile audio system with superior performance.


SPECIFICATIONS


  • Number of Channels : 1
  • Frequency Response : 20-250 Hz
  • Amplifier Class : D
  • Fuse Rating : 40x3 A

FEATURES


Features:

  • 250Watts @ 2 ohms RMS Output
  • 160Watts @ 4 ohms RMS Output
  • Frequency Response: 20-250Hz
  • Signal To Noise Ratio: >90dB
  • Dampening Factor: > 250
  • Overall Operation Efficiency: >88%
  • Subsonic Filter:10-55Hz
  • LPF Filter:50-250Hz
  • Bass Boost:0-18dB
  • Level Input Range:0.2-10V
  • Hidden Led Lights under Logo Badge indicate working status: Power/Protection
  • Gain Input Sensitivity Clipping Indicators
  • Bass Level Remote Controller
  • Monoblock IR Chipset Digital Circuit Design
  • DirectFET power Mosfet Output Stage
  • Compact Size to easy Installation
  • SMD Technology on 4 Layers FR4 PC Board
  • Balanced Differential Inputs for Noise-Free Operation Regardless of the Source
  • Audio Precision Quality Control Verification



Specifications:

  • RMS Power (1Ω): N/A
  • RMS Power (2 Ω): 250 W
  • RMS Power (4 Ω): 160 W
  • Topology: Monoblock Class D
  • Power Supply: Full PWM
  • Power Supply Threshold: 10.0VDC – 17.0VDC
  • Idle Current: (0.7A)
  • THD (1KHz @4Ω): 0.07%
  • S/N Ratio (A weighted @1W): -77.4dBA
  • S/N Ratio (A weighted @ FP): -97.4dBA
  • Input Sensitivity – Low Input Level: 0.2mV – 10.0V
  • Input Sensitivity – High Input Level: YES – UP to 25 W RMS
  • Input Impedance – Low Input Level: 22 KΩ
  • Impedance – High Input Level: 22 KΩ
  • Output Impedance: 0.047Ω
  • Damping Factor (50Hz @ 4?): >250
  • Bandwidth (-3dB): 10Hz-350Hz
  • Crossover (-12 dB/ Oct) – Variable High Pass: N/A
  • Crossover (-12 dB/ Oct) – Variable Low Pass: 35Hz – 350Hz
  • Crossover (-12 dB/ Oct) – Variable Sub-Sonic: N/A
  • Fuse Rating (ATC): 3 X 40A
  • Dimensions- Length x Width x Height (inches): 6.42” x 6.85” x 1.9”
  • Dimensions- Length x Width x Height (mm): 163.1 x 174 x 48.4mm
  • UPC: 847169057434
  • Weight: 7
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
