- Diameter : 6.5 Inch
- Sensitivity : 97 dB
- Impedance : 4 Ohm
- Frequency Response : 110-10000 Hz
- Peak Power Handling : 800 Watts
- RMS Power Handling : 400 Watts
Features:
- 200W RMS Power Handling
- Frequency Response: 110 – 10kHz +/- 3dB
- Sensitivity: 97dB 1W/1M
- Manufactured to IP65 Marine Grade Compliant Specifications
- Shorting Ring Utilized In Motor Structure
- For Far-Field Performance
- Thermal Molded Waterproof Paper Cone
- UV-Treated Polycarbonate Cloth Surround
- Nominal Impedance: 4 ohm
- Sensitivity -100dB 1W/1M
- Mounting Depth: 2.4375”
- Cut-out Diameter: 5.625”
- Over-All Diameter: 6.5”
- Over-All Height: 2.625”
Specifications:
- SPL (dB-MidBass): 97
- Re(Ω)[series]: 3.1
- Qms: 4.896
- Qes: 1.050
- Qts: 0.856
- Fs(Hz): 137.4
- Vas(L): 3.62
- Cms(mm/N): 0.139
- Mms(g): 9.620
- Sd(m2): 0.0137
- BL(T*M): 4.95
- Xmax(mm): 1.3
- Pwr(W) NOM/MAX 200/**400
- Total Diameter: 6.5 (166.7) in. (mm)
- Mounting Diameter: 5.5625 (143.5) in. (mm)
- Mounting Depth: 2.375 (63.5) in. (mm)
- Total Depth: 2.5625 (67.5) in. (mm)l
- UPC: 0847169044762
- Weight: 7
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
Do you own this product?
Write a review!
-
These are great speakers. My only complaint is the speaker terminals feel cheaply made. For such a quality speaker, Diamond should have used push lock speaker connectors instead of the slide on type.
