- Maximum Power : 1000 Watts
- Number of Channels : 5
- RMS Power Output : 90x4 Watts
- Amplifier Class : D
- Fuse Rating : 25x2 A
Features:
- Latest High Efficiency Class D Topology
- Compact Size with Ambient backlit logo
- RCA “Pass Thru” output for easy system expansion
- Fully Variable Crossovers (12dB per octave)
- Handles HI and LO level input to 12V
- 2 Ω Stable Stereo and 4Ω Mono (CH3/4) for 3 Ch mode
- Proprietary Vega Bass Boost EQ Up To 12dB
Specifications:
- Amplifier Power: 1000W MAX
- RMS Power(2Ω): 4 x 90W + 1 x 300W
- RMS Power (4Ω): 4 x 65W + 1 x 200W
- RMS Bridge (stereo 4Ω): 2 x 220W
- Types: Class D
- Power Supply: Full PWM
- Power Supply (Threshold): 10.0DVC – 16.0DVC
- Idle Current: (0.7A)
- Distortion - THD (1KHz@4Ω): <0.1%
- Distortion - S/N Ratio (A weight @ 1W): -85dBA
- Distortion - S/N Ratio (A weight @ FP): -101.1dBA
- Input Sensitivity - Hi/Low Input Level: N/A / 500mV – 12V
- Input Impedance - Low Input Level: 20 KΩ
- Input Impedance - High Input Level: 100 KΩ
- Output Impedance: 2 Ω
- Damping Factor (50Hz@4Ω): >70
- Bandwidth (-3dB): 10Hz-30KHz+10Hz-250Hz
- Crossover (-12 dB/ Oct) Variable High-Pass: 35Hz-250Hz
- Crossover (-12 dB/ Oct) Variable Low-Pass: 35Hz-250Hz
- Crossover (-12 dB/ Oct) Variable Sub-Sonic: N/A
- FUSE Ratings - ATC: 2 x 25A
- Dimension - Length x Width x Height - Inches(mm): 10.3 x 4.7 x 1.8 (260 x 120 x 46.5)
- UPC: 847169053740
- Weight: 10
