- Diameter : 6.5 Inch
- Sensitivity : 101 dB
- Impedance : 2 Ohm
- Frequency Response : 110-18000 Hz
- Peak Power Handling : 500 Watts
- Design : 1 Way
- Top Mount Depth : 3.88 Inches
- Bottom Mount Depth : 3.33 Inches
- RMS Power Handling : 250 Watts
Features:
- 250W RMS/500 MAX Power Handling
- Ferrite Strontium High Temp Magnet structure
- Heavy Duty Die-cast Aluminum Basket
- Advanced Voice Coil Heat Sink Design for Better Heat Dissipation
- 1.5” Single Layer High Temp Voice Coil with Black Coated Voice Coil former for Woofer
- 1.0” Single Layer High Temp Voice Coil with Black Coated Voice Coil former for Tweeter
Specifications:
- Frequency Response: 110Hz -18,000Hz
- High Sensitivity 101 dB 1W/1M
- 12dB Crossover
- Mounting Depth: 3.33” / 84.6mm
- Mounting Diameter: 5.73” / 145.5mm
- Speaker Size: 6.5”
- RMS Power Rating: 250W RMS
- Max Power Rating: 500W MAX
- SPL (dB-MidBass): 94.5SPL (dB-Tweeter): 107Re (Ω)[series]: 1.8
- Qms: 6.46 Qes: 0.51
- Qts 0.34
- Fs-Free Air Resonance (Hz): 120
- Vas (Liter): 4.3
- Cms (mm/N): 0.13
- Mms (g): 10.4
- Sd (cm²): 134.8 BL (T*M):6.2
- Xmax - Inch(mm): 2
- Total Diameter: 6.52'' (165.5mm)
- Mounting Diameter (inch/mm): 5.73'' (145.5mm)
- Mounting Depth: 3.33'' (91.6mm)
- Total Depth: 3.88'' (98.6mm)Magnet Diameter (E)3.94'' (100mm)
- UPC:
- Weight: 5
