Orion CM6852 Pro Audio Cobalt Series 6x8" 1000W Peak Power Handling at 2-Ohms, Midrange Car Speakers (Pair)
We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • (2) 6x8" Midrange Car Speaker
- • Owner's Manual
Cobalt 2-Ohm Midrange: Crisp Sound
Experience unmatched clarity with our High-Efficiency 2-Ohm Midrange Speaker, delivering precise and accurate sound for any high-performance audio system. The innovative Bullet Phase Plug ensures crystal-clear audio, reducing distortion and keeping the voice coil cool. Enjoy consistent, high-quality sound that brings every note and detail to life.
Powerful, Durable Car Speakers
Built to endure, the heavy-gauged stamped steel frame provides exceptional strength and rigidity, reducing vibrations for crystal-clear sound. The high-temperature coating protects components during extended high-power use, ensuring reliable performance every time. With 250 Watts RMS and 1000 Watts peak power, this speaker delivers dynamic, powerful audio that commands attention in any environment.
Durable Speakers with Immersive Sound
Experience long-lasting performance with our durable speaker, featuring a non-pressed paper cone and treated cloth surround for precise, accurate sound. Its wide frequency range from 70 Hz to 20 kHz captures every midrange detail, delivering rich and immersive audio. Enjoy music the way it was meant to be heard, with stunning clarity and depth in every note.
Frequently Asked Questions (FAQ)
- • Why Does My CM6852 Sound Different From a Factory 6×8 Speaker?
The CM6852 is designed as a pro-audio midrange speaker, rather than a typical factory-style full-range replacement. Its bullet phase plug, paper cone, 2-ohm impedance, and high power handling can produce a noticeably different tonal balance from OEM speakers.
- • Why Is My CM6852 Not Producing the Deep Bass I Expected?
Although Orion lists a frequency response beginning at 70 Hz, the CM6852 is primarily intended for midrange output. Very low bass is better handled by a dedicated subwoofer, particularly in systems designed for high-output playback.
- • Could the 2-Ohm Rating Cause Problems With My Factory Radio?
It can if the factory source is not designed to operate safely at a 2-ohm speaker load. Before connecting the CM6852 directly, verify the head unit or amplifier's minimum supported impedance because Orion specifically lists this model as 2 ohms.
- • Why Does My CM6852 Become Distorted When I Turn the System Up?
Distortion can come from amplifier clipping, excessive gain, incorrect equalizer settings, or an amplifier being pushed beyond its clean operating range. The speaker's 250W RMS rating should not be confused with the amount of clean power every amplifier can safely deliver to it.
- • What If My Factory Speaker Opening Is Too Small for the CM6852?
The CM6852 is marketed for 5×7/6×8-inch applications, but the actual physical dimensions still matter. Orion lists approximately a 6.94-inch cutout diameter, 7.81-inch overall diameter, and 2.57-inch mounting depth, so an adapter or modified mounting panel may be necessary in some vehicles.
- • Why Does One CM6852 Seem Louder Than the Other?
Start by checking channel balance, speaker polarity, wiring resistance, amplifier outputs, and mounting conditions. Swapping the left and right speaker connections can help determine whether the difference follows the speaker or stays with the amplifier channel.
- • Can a Weak Mounting Surface Make the CM6852 Sound Worse?
Yes. A loose or flexible mounting surface can allow the speaker frame to vibrate and reduce the effectiveness of the installation. The CM6852 uses a heavy-gauge stamped-steel frame specifically intended to provide rigidity, so it should be securely mounted to a solid surface.
- • Why Does the CM6852 Sound Very Bright or Aggressive?
The CM6852 is designed for strong midrange projection and extends up to 20 kHz. Amplifier gain, EQ boosts, listening position, and the rest of the speaker system can make the upper portion of its response sound more prominent.
- • Do I Need an Amplifier to Get the Most From the CM6852?
The answer depends on the system. Its 250W RMS power-handling specification is intended for a higher-powered setup, while a factory radio may provide considerably less power. A properly matched amplifier can provide additional headroom, but the gain should still be configured correctly.
- • What Should I Inspect If My CM6852 Starts Rattling After Installation?
Check the mounting screws, adapter brackets, speaker terminals, surrounding trim, and door panel for looseness. Also inspect the treated cloth surround and paper cone for physical damage. Orion lists the CM6852 with a stamped-steel frame and treated cloth accordion surround, so unwanted rattling should not automatically be attributed to the speaker itself.
- Diameter : 6x8 Inch
- Sensitivity : 92 dB
- Impedance : 2 Ohm
- Frequency Response : 70-20000 Hz
- Peak Power Handling : 1000 Watts
- Top Mount Depth : 2.57 Inches
- RMS Power Handling : 250 Watts
Features:
- High-Efficiency 2-Ohm Midrange Speaker: Delivers precise and accurate sound reproduction, integrating seamlessly into any high-performance audio system.
- Bullet Phase Plug: Enhances sound clarity, reduces distortion, and cools the voice coil, providing consistent, high-quality audio.
- Heavy-Gauged Stamped Steel Frame: Offers exceptional strength and rigidity, minimizing vibrations and resonance for improved sound clarity.
- High-Temperature Coating: Protects the speaker components from heat during extended use at high power levels, ensuring consistent performance.
- High Power Handling: 250 Watts RMS and 1000 Watts peak power for dynamic, powerful sound performance in any environment.
- Durable Construction: Features a non-pressed paper cone and a treated cloth accordion surround for durability and accurate sound reproduction.
- Wide Frequency Range: From 70 Hz to 20 kHz, capturing detailed midrange frequencies for a rich, immersive audio experience.
Specifications:
- Speaker Size: 6x8" (Inches)
- Voice Coil Configuration: 2 ohm
- Power Handling (Peak): 1000 Watts
- Power Handling (RMS): 250 Watts
- Sensitivity: 92 dB
- Frequency Response: 70 Hz - 20 kHz
- Voice Coil Diameter: 1.5" (Inches)
- Midrange Speaker: 1 Pair (2 Speakers)
- Grill Included: No
- Cone Material: Non-Pressed Paper Cone
- Damper Material: Poly Cotton
- Surround Material: Accordion Treated Cloth
- Magnet Information: 21 Oz Ferrite
- Mounting Depth: 65.4mm / 2.57 (Inches)
- Overall Depth: 71.7mm / 2.82 (Inches)
- Cutout Diameter: 176.3mm / 6.94 (Inches)
- Overall Diameter: 198.4mm / 7.81 (Inches)
- UPC: 818550019263
- Weight: 7.06
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
